User Manual

IDS-3315 Series

15" Industrial Front IP65 Monitor

IDS-3315 User Manual ii

The documentation and the software included with this product are copyrighted 2018

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to improve the products described in this manual at any time without notice. No part

of this manual may be reproduced, copied, translated, or transmitted in any form, or

by any means, without the prior written permission of Advantech Co., Ltd. The infor-

mation provided in this manual is intended to be accurate and reliable. However,

Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements

of the rights of third parties that may result from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants the original purchaser that all of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products that have been repaired or altered by

persons other than repair personnel authorized by Advantech, or products that have

been subject to misuse, abuse, accident, or improper installation. Under the terms of

this warranty, Advantech assumes no liability for the consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most

customers never need to use our repair service. If an Advantech product is defective,

it will be repaired or replaced free of charge during the warranty period. For out-of-

warranty repairs, customers will be billed according to the cost of the replacement

materials, service time, and freight. Please consult your dealer for more details.

If you suspect that your product is defective, follow the steps outlined below.

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages displayed when the prob-

lem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and all relevant information readily available.

3. If your product is diagnosed as defective, obtain a return merchandize authori-

zation (RMA) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a completed Repair and Replacement

Order Card, and a proof of purchase date (such as a photocopy of your sales

receipt) in a shippable container. Products returned without a proof of purchase

date are not eligible for warranty service.

5. Write the RMA number clearly on the outside of the package and ship it prepaid

to your dealer.

Part Number: 2006331500 Edition 1

Printed in Taiwan June 2018

iii IDS-3315 User Manual

Declaration of Conformity

This product has passed the CE test for environmental specifications. Test conditions

for passing included the equipment being operated within an industrial enclosure. In

order to protect the product from damage due to electrostatic discharge (ESD) or

electromagnetic interference (EMI) leakage, we strongly recommend the use of CE-

compliant industrial enclosure products.

FCC Class A

This equipment has been tested and found to comply with the limits for a Class A dig-

ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-

vide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Opera-

tion of this equipment in a residential area is likely to cause harmful interference. In

such cases, users are required to correct the interference at their own expense.

Technical Support and Assistance

1. Visit the Advantech website at http://support.advantech.com to obtain the latest

product information.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support or additional assistance. Please have the following

information ready before calling:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software,

etc.)

–Comprehensive description of the problem

–The exact wording of any error messages

Product specificaties

Merk:	Advantech
Categorie:	Monitor
Model:	IDS-3315R-50XGA1
Kleur van het product:	Zwart
Internationale veiligheidscode (IP):	IP65
Beeldschermdiagonaal:	15 "
Resolutie:	1024 x 768 Pixels
Touchscreen:	Ja
Ethernet LAN:	Nee
Kijkhoek, horizontaal:	176 °
Kijkhoek, verticaal:	176 °
Beeldscherm vorm:	Flat
Typische contrastverhouding:	2500:1
Touch technologie:	Multi-touch
Helderheid:	500 cd/m²
Touch screen type:	Kiosk
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	1
DVI-poort:	Ja
Certificering:	FCC, CE
HD type:	XGA
RS-232 port:	1
HDMI:	Ja
Display technologie:	LED
Responstijd:	23 ms
VESA-montage:	Ja
DVI-D poorten:	1
Diepte ( zonder voet ):	46 mm
Hoogte (zonder voet ):	291 mm
Breedte ( zonder voet ):	365 mm
Gewicht (zonder voet):	4500 g
AMD FreeSync:	Nee
NVIDIA G-SYNC:	Nee
Soort voeding:	AC
Temperatuur bij opslag:	-30 - 70 °C
Ingebouwde USB-hub:	Nee
Aantal upstream-poorten:	1
Ophangsysteem voor aan de muur:	Ja
Touchscreen technologie:	Resistief
Bedrijfstemperatuur (T-T):	-20 - 60 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
