Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance,

please register your appliance on

www.whirlpool.eu/register

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more detailed

instructions on how to remove them, see the Installation Guide.

PROGRAMME CHART

1. “ON/OFF” button

2. Programme selector

3. “Temperature” button

4. “Spin” button

5. “Start delay” button

6. “Start/Pause” button

7. Option buttons

8. “Key lock“button

INDICATORS

Door can be opened

Washing phase

Indicates washing phase of the cycle

Failure: Call Service

Refer to Troubleshooting section

Failure: Water lter clogged

Water cannot be drained; water lter

might be blocked

Failure: Water tap closed

No or not sucient inlet water. “Beep”

sound every 5 seconds.

In the event of any failures, refer to the

Troubleshooting section in USER MANUAL

CONTROL PANEL

2.1. 6.3. 4. 5.

8.7. 7.

PRODUCT DESCRIPTION

1. Worktop

2. Detergent dispenser

3. Control panel

4. Door handle

5. Door

6. Water lter - behind plinth

7. Plinth (removable)

8. Adjustable feet (4)

DETERGENT DISPENSER

Main wash compartment

Detergent for the main wash, stain remover

or water softener. For a liquid detergent it is

recommended to use removable plastic partition

A (supplied) for a proper dosage. If powder

detergent is used, place the partition into slot B.

Prewash compartment

Detergent for the prewash.

Softener compartment

Fabric softener. Liquid starch.

Pour in softener or starch solution only up to the “max” mark.

Release button 

Press to remove tray for cleaning.



This data may dier in your home due to changing conditions in inlet water temperature,

water pressure etc. Approximate programme duration values refer to the default setting of the

programmes, without options.

** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

*** The duration of the programme is shown on the display.

6th Sense - the sensor technology adapts water, energy and programme duration to your wash

load.

1) Test wash cycle according to UAE.S 5010-2 : 2019 regulations:

Set WHITE wash program at a temperature of 60°C for the Standard Cotton 60°C.

Cotton Eco - Test wash cycles in compliance with regulations 1061/2010

These are the reference programs for the energy label. Set this wash cycles with a

temperature of 40°C or 60°C. They are the most ecient programmes in terms of energy

and water consumption for washing normally soiled cotton laundry. The actual water

temperature may dier from the declared one.

For all Test Institutes:

Long wash cycle for cottons: set wash cycle with a temperature of 40°C.Cotton

Synthetic program along: set wash cycle Synthetics

with a temperature of 40°C.

Max load 9 Kg

Power consumption in o -mode 0.5 W / in left-on mode 8 W Detergents and additives Recommended

detergent

Residual

dampness % (**)

Energy

consumption kWh

Total water lt

Programme Temperatures Max.

spin

speed

(rpm

Max

load

(kg

Duration

(Minutes Prewash Main

wash Softener Powder Liquid

Default Range

Mixed 40°C - 40°C 9.0 –

1000 ***   –– – –

White (1) 60°C - 90°C 9.0

1400 ***     (90°) – – –

Cotton 40°C - 60°C 9.0 255 –

1400     49 1,10 97

Cotton

60°C 60°C 9.0 260 –

1400     53 0,70 56

40°C 9.0 255 –1400     49 1,10 97

Bed linen 60°C - 60°C 9.0 –1400 ***     – – –

Sport 40°C - 40°C 4.0 –

600 ***   –– – –

Duvet 30°C - 30°C 3.5 –

1000 ***   –– – –

Steam Refresh – – - 2.0 – – – – – – – –***

Spin & Drain – – 9.0 – – – – – – – –

1400 ***

Rinse & Spin – – 9.0 – –1400 *** – – – – –

Rapid 30’ 30°C - 30°C 4.5 –

800 ***   –– – –

Colours 15° 15°C 15°C 4.5 – 1000 ***   –– – –

Silk 30°C - 30°C 1.0 –

- ***   – – – –

Wool 40°C - 40°C 800 2.0 –

***   –– – –

Delicates 30°C - 30°C - 1.0 –

***   –– – –

Synthetics 40°C - 60°C 1200 4.5 –

175     35 0,80 55

 Dosing required Dosing optional

PROGRAMMES

For choosing the appropriate programme for your kind of

laundry, always respect the instructions on the care labels of

the laundry. The value given in the tub symbol is the maximum

temperature possible for washing the garment.

Mixed

For washing lightly to normally soiled resilient garments in cotton, linen,

synthetic bres and mixed bres.

White

For washing normally to heavily soiled towels, underwear, table and bed

linen, etc in resilient cotton and linen. Only when the temperature is

selected at 90°C the cycle is provided with a prewash phase before main

washing phase. In this case it is recommended to add detergent both, in the

prewash and main wash section.

Cotton

Normally to heavily soiled and robust cottons .

Cotton

For washing normally soiled cotton garments. At 40°c and 60°C, this is the

standard cotton programme and the most ecient in terms of water and

energy consumption.

Bed linen

Use this programme to wash bed linen an towels in one single cycle. It

optimises softner performance and helps you save time and energy. We

recommend to use powder detergent.

Sport

For washing lightly soiled sports clothing (tracksuits, shorts, etc.). For best

results, we recommend not exceeding the maximum load indicated in the

‚‘‘‘PROGRAMME CHART‘‘. We recommend using liquid detergent , and adding

the amount suitable for half-load.

Duvet

Designed for washing eiderdown padded items such as double or single

duvets, cushions and anoraks. It is recommended to load such padded

items in the drum with the edges folded inwards and not to exceed ¾ of

the drum’s volume. For optimal washing, we recommend using a liquid

detergent.

Steam Refresh

This programme refreshes garments by removing bad odours and relaxing

the bres (2 kg, roughly 3 items). Insert dry items only (that are not dirty)

and select programme “Steam Refresh”. Garments will be a little damp

at the end of the cycle and can be worn after a few minutes. The “Steam

Refresh” programme makes ironing easier.

! Not recommended for wool or silk garments.

! Do not add softeners or detergents.

Spin & Drain

Spins the load then empties the water. For resilient garments. If you exclude

the spin cycle, the machine will drain only

Rinse & Spin

Rinses and the spins. For resilient garments.

Rapid 30’

For washing lightly soiled garments quickly. This cycle lasts only 30 minutes,

saving time and energy.

Colours 15°

This cycle helps protect colours by washing in cold water (15°C) and uses

less energy to heat the water while still oering satisfactory wash results.

Suitable for lightly soiled, ustained garments. This cycle oers wash results

comparable to 40°c mixed at just 15°C.

Silk

Use this cycle to wash all silk garments. We recommend the use of special

detergent which has been designed to wash delicate clothes.

Wool

All wool garments can be washed using programme ‚“Wool“ even those

carryng the “hand-wash only “ label. For best results, use special detergents

and do not exceed max kg declaration of laundry.

Delicates

For washing particularly delicate garments. Preferably turn garments inside

out before washing.

Synthetics

For washing soiled garments made from synthetic bres (such as polyester,

polyacrylic, viscose, etc.) or cotton/synthetic blends.

FIRST TIME USE

The rst time the machine is switched on, you will be asked to select the

language and the display will automatically show the language selection

menu.

To select the desired language press the “Temperature” button or “Start

delay” button; to conrm the selection press the “Spin” button.

To change the language switch o the washing machine and press buttons

“Key lock” , “Intensive rinse” and “ ” simultaneously until an

alarm is heard: the language-selection menu will be displayed again.

To remove any residues from the manufacturing process. Select the

“Cotton” programme at a temperature of 60°C. Add a small amount of

heavy duty detergent to the main wash compartment of the detergent

dispenser (maximum 1/3 of the quantity recommended by the detergent

manufacturer for lightly soiled laundry). Start the programme without

adding any laundry.

DAILY USE

Prepare your laundry according to the recommendations in the “HINTS

AND TIPS” section. Load the laundry, close the door, open the water tap

and press the “ON/OFF” button to switch the washing machine on,

the “Start/Pause” button ashes. Turn the programme selector to the

desired programme and select any option if needed. The temperature

and spin speed shown on the display can be changed by pressing the

“Temperature” button or the “Spin” button. Pull out the detergent

dispenser and add the detergent (and additives/softener) now. Observe the

dosing recommendations on the detergent pack. Then close the detergent

dispenser.

STARTING CYCLE

Press the “Start/Pause” button.

The machine will lock the door ( symbol o) and the drum will start to

rotate; the door will be unlocked ( symbol on) and then locked again

( symbol o) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum and

start the washing phase once the door is locked.

PAUSE A RUNNING PROGRAMME

To pause the wash cycle, press the button “Start/Pause” again; the

indicator light will ash. If the symbol is illuminated, the door may be

opened. To start the wash cycle from the point at which it was interrupted,

press the button again.

OPEN THE DOOR, IF REQUIRED

Before starting and after end of a programme, the “Door open” symbol

lights to show the the door can be opened. As long as a wash programme is

running, the door remains locked. To open the door while a programme is

in progress, press the “Start/Pause” button. Provided the water level and/

or temperature is/are not too high, the “door open” indicator lights up

and you can open the door. For example to add/ remove laundry. Press the

“Start/Pause” button again to continue the programme.

PROGRAMME END

The “Door open” indicator lights up, and the display shows “Cycle end”.

To switch o the washing machine after programme end press the “

ON/OFF” button, the lights go o. If you do not press “ON/OFF”

button, the washing machine will switch o automatically after about a

10 minutes. Close the water tap. Open the door and unload the machine.

Leave the door ajar to allow the drum to dry.

OPTIONS

! If the selected function is incompatible with the set programme, the

incompatibility will be signalled by a buzzer (3 beeps) and the wording

“No Selection” will appear on the display.

! If the selected function is incompatible with another previously set

function, the wording will appear on the display and the “No Selection”

function will not be enabled.

Clean+

Clean+ is an option working on 3 dierent levels (Intensive, Daily and Fast)

that are specially designed to set the right washing action, depending on

your cleaning needs:

Intensive: this option is designed for high levels of dirtiness, removing most

stubborn stains.

Daily: this option is designed to remove everyday stains.

Fast: this option is designed to remove lightly soiled stains.

Intensive rinse

By selecting this option, the eciency of the rinse is increased and optimal

detergent removal is guaranteed. It is particularly useful for sensitive skin.

Press the button once, two or three times to select an additional 1, 2 or 3

rinses after the standard cycle rinse and remove all traces of detergent.

Press the button again to go back to the “Normal rinse” rinse type.

Delay Timer

To set the selected programme to start at a later time , press the button

to set the desired delay time. or “Waiting” “Starts in” is indicated on the

display when this option is enabled. To cancel the delayed start, press the

button again until the value ‚‘‘--:--‘‘ is shown on the display.

This option enhances washing performance by generating steam to inhibit

the proliferation of the main bad odour sources inside the machine. After

steam phase, the washing machine will perform gentle tumbling through

slow rotations of the drum. option starts after the cycle ends for a

maximum duration of 6h and you can interrupt at any time by pressing any

button on control panel or turning the knob.

(*) Wait around 5’ before open the door.

Steam Hygiene

This option enhances washing performance by generating steam during

the wash cycle that eliminates any bacteria from bres while treating them

at the same time. Place the laundry in the drum, choose a compatible

programme and select option “ “.

! The steam generated during washing machine operation may cause the

porthole door to become hazy.

Easy Iron

By selecting this function, the wash and the spin cycles will be modied in

order to reduce the formation of creases.

Temperature

Every programme has a predened temperature. If you want to change the

temperature, press the “Temperature” button. The value appears on the

display.

Spin

Every programme has a predened spin speed. If you want to change the

spin speed, press the “Spin” button. The value appears on the display.

Demo mode

To deactivate this function, switch the washing machine OFF. Than press

and hold “Start/Pause” button, within 5 seconds press also

“ON/OFF” button and hold both buttons for 2 seconds.

KEY LOCK

To lock the control panel, press and hold the “KEY LOCK” button for

approximately 3 seconds. When the display visualises “KEY LOCK ON” the

control panel is locked (with the exception of the ON/OFF button). This

prevents unintentional changes to programmes, especially with children

near the machine. To unlock the control panel, press and hold the “KEY LOCK”

button for approximately 3 seconds.

BLEACHING

If you wish to bleach the laundry, load the washing machine and set the

“Rinse & Spin” programme.

Start the machine and wait for it to complete the rst water lling cycle

(roughly 2 minutes). Put the machine in pause mode by pressing the

“Start/Pause” button , open the detergent drawer and pour the bleach

(observe the recommended doses indicated on the package) into the

main wash compartment where the partition was previously mounted.

Restart the cycle by pressing the “Start/Pause” button .

If desired, it is possible to add fabric softener into the appropriate

compartment of the detergent drawer.

HINTS AND TIPS

Sort your laundry according to

Type of fabric/care label (cotton, mixed bres, synthetics, wool, handwash

items). Colour (separate coloured and white items, wash new coloured

items separately). Delicates (wash small items – like nylon stockings – and

items with hooks – like bras – in a cloth bag or pillow case with zip).

Empty all pockets

Objects like coins or lighters can damage your laundry as well as the drum.

Follow the dosage recommendation / additives

It optimizes the cleaning result, it avoids irritating residues of surplus

detergent in your laundry and it saves money by avoiding waste of surplus

detergent

Use low temperature and longer duration

The most ecient programmes in terms of energy consumption are

generally those that perform at lower temperatures and longer duration.

Observe the load sizes

Load your washing machine up to the capacity indicated in the

“PROGRAMME CHART” table to save water and energy.

Noise and remaining moisture content

They are inuenced by the spinning speed: the higher the spinning speed

in the spinning phase, the higher the noise and the lower the remaining

moisture content.

DESCALE AND CLEAN PROCEDURE

A message on the display will regularly (roughly every 50 cycles) advise the

user to run an automatic cleaning cycle to clean the washing machine and

combat limescale build-up and bad odours.

For optimal maintenance we suggest using WPRO Limescale and grease

remover, according to the instructions shown on the package. The product

can be purchased by contacting the technical assistance service or through

the website www.whirlpool.eu.

Whirlpool declines all liability for any damages to the appliance caused by the

use of other cleaning products for washing machines available on the market.

CLEANING & MAINTENANCE

For any cleaning and maintenance, switch o and unplug the washing

machine. Do not use ammable uids to clean the washing machine.

Clean and maintain your washing machine periodically (at least 4 times per

year).

Cleaning the outside of the washing machine

Use a soft damp cloth to clean the outer parts of the washing machine. Do

not use glass or general purpose cleaners, scouring powder or similar to

clean the control panel – these substances might damage the printing

Checking the water supply hose

Check the inlet hose regularly for brittleness and cracks. If damaged, replace

it by a new hose available through our After-Sales Service or your specialist

dealer. Depending on the hose type:

If the inlet hose has a transparent coating, periodically check if the colour

intensies locally. If yes, the hose may have a leak and should be replaced.

Cleaning the water lter / draining residual water

If you used a hot wash programme, wait until the water has cooled down before

draining any water. Clean the water lter regularly, to avoid that the water

cannot drain after the wash due to obstruction of the lter. If the water cannot

drain, the display indicates that the water lter may be clogged.

Remove the plinth by using the removable plastic partition of the detergent

dispenser: push downwards one side of the plinth with your hand, then

push the removable plastic partition into the gap between plinth and front

panel and pry open the plinth. Place a broad, at container beneath the

water lter, to collect the drain water. Slowly turn the lter counterclockwise

until water ows out. Let the water ow out, without removing the lter.

When the container is full, close the water lter by turning it in clockwise.

Empty the container. Repeat this procedure until all the water has drained.

Lay a cotton cloth beneath the water lter, which can absorb a small

amount of rest water. Then remove the water lter by turning it out anti

clockwise. Clean the water lter: remove residues in the lter and clean it

under running water. Insert the water lter and reinstall the plinth: Reinsert

the water lter again by turning it in clockwise direction. Make sure to turn

it in as far as it goes; the lter handle must be in vertical position. To test

water tightness of the water lter, you can pour about 1 liter of water into

the detergent dispenser. Then reinstall the plinth.

Cleaning the detergent dispenser

Remove the detergent dispenser by pressing on the release button and at

the same time pulling out the detergent dispenser. Remove the insert from

the detergent dispenser, as well as the insert of the softener compartment.

Clean all parts under running water, removing all detergent or softener

residues. Wipe the parts dry with a soft cloth. Reinstall the detergent

dispenser and push it back into the detergent compartment.

ACCESSORIES

Contact our After-Sales Service to check if the following accessories are

available for your washing machine model.

Stacking kit shelf

By which your dryer can be xed on top of your washing machine to save

space and to facilitate loading and unloading your washing machine in the

higher position.

TRANSPORT AND HANDLING

Never lift the washing machine by holding it at the worktop.

Pull out the mains plug, and close the water tap. Make sure that door and

detergent dispenser are properly closed. Disconnect the inlet hose from the

water tap, and remove the drain hose from your draining point. Remove all

rest water from the hoses, and x them so that they cannot get damaged

during transport. Ret the transport bolts. Follow the instructions for

removing the transport bolts in the INSTALLATION GUIDE in reverse order.

Product specificaties

Merk:	Whirlpool
Categorie:	Wasmachine
Model:	FFD 9469 CV GCC

Heb je hulp nodig?

Als je hulp nodig hebt met Whirlpool FFD 9469 CV GCC stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Wasmachine Whirlpool

Whirlpool FFWDB 964489 WV EE Handleiding

20 December 2024

Whirlpool BI WMWG 81485 Handleiding

3 December 2024

Whirlpool W6 88 SILENCE IT Handleiding

3 December 2024

Whirlpool W8 09ADS SILENCE IT Handleiding

3 December 2024

Whirlpool TDLR 6251BS PL Handleiding

3 December 2024

Whirlpool WRBSS 6249 S EU Handleiding

3 December 2024

Whirlpool FFB R849 BSV IT Handleiding

3 December 2024

Whirlpool FFB 116 SILVER IT Handleiding

3 December 2024

Whirlpool FFB 848 BSV IT Handleiding

3 December 2024

Whirlpool BI WMWG 91485 EU Handleiding

3 December 2024

Handleiding Wasmachine

Nieuwste handleidingen voor Wasmachine

Asko w 6362 l tit Handleiding

5 December 2024

Asko W2084.W-2 Handleiding

5 December 2024

Bauknecht BPW 1014 A Handleiding

21 December 2024

Asko w 6362lt Handleiding

5 December 2024

Svan SL8201DD Handleiding

21 December 2024

Svan SLI8200D Handleiding

21 December 2024

Svan SL9401AIDB Handleiding

21 December 2024

Svan SL7201DD Handleiding

21 December 2024

Electrolux EWD8462OBI Handleiding

20 December 2024

Svan SL6001DD Handleiding

20 December 2024
