MUSIC Group IP Ltd.
Trident Chambers, Wickhams
Cay, P.O. Box 146, Road Town,
Tortola, British Virgin Islands
t: +44 (0)1403 711447
f: +44 (0)1403 710155
e: CARE@music-group.com
w: www.turbosound.com
Milan
series
Milan M18B
2200-Watt 18” Powered Subwoofer
The Milan M18B is powered 18” bandpass subwoofer that extends the frequency range and
increases the overall loudness of any Milan system.
The bandpass design produces high bass energy within the pass band, which is tuned to
reinforce bass instrument frequencies, and the steep cut-off slopes ensure an effective
acoustic transition to Milan full-range loudspeakers.
The onboard Class-D amplifier provides over 2,200 watts of maximum output power with
plenty of headroom to power the long-excursion bass driver, allowing short term
transients to be reproduced with wide dynamic range. Two discrete balanced XLR inputs
plus corresponding thru connections on balanced male XLR allow a stereo system
comprising of two Milan full-range loudspeakers to be operated with only one subwoofer
if required, the sub-bass frequencies being filtered and summed to the subwoofer drive
unit. A switchable 6dB boost is available at a centre frequency between 40Hz and 90Hz,
while an overall level control allows the sub-bass frequencies to be balanced with the
system. A polarity switch is provided for optimum subwoofer integration. Rear panel LEDs
indicate power on, signal present, and the onset of limiting action.
The birch plywopod cabinet is equipped with heavy duty wheels to aid handling and
transportation, while the pole mount socket allows Milan full range loudspeakers to be
mounted on top of the subwoofer with a minimal footprint.
High-performance 2,200-Watt
band-pass subwoofer for PA
applications
Powerful long-excursion 18” bass
driver delivers extreme low
frequency energy
Advanced processor dynamically
optimises sound quality at all
levels and protects driver
Sophisticated Class-D amplifier
with comprehensive over-
excursion, thermal and clip limit
protection
Lightweight birch plywood
cabinet, screwed and glued for
absolute rigidity
Comfortable rear handles and
heavy duty wheels for easy
handling and transportation
LF boost control with variable
frequency allows stereo EQ to be
tuned to sound great in any venue
Left and right stereo inputs and
outputs enable two mid-highs to
be used with one subwoofer
Power, signal and limit LEDs for
comprehensive system monitoring
Pole mount socket for mounting
loudspeakers at the correct height
above the subwoofer
Designed and engineered by
TURBOSOUND in England
590 x 640 x 530 mm (23.2 x 25.2 x 20.9”)
48kg (105.6lbs)
1 x 18” (457mm) LF driver
40Hz–100Hz ±3dB, 30Hz–150Hz -10dB
134dB peak (half space)
+6dB @ 40Hz–90Hz, Q=1
Birch plywood, screwed and glued
Input: 2 x female XLR wired pin 2 hot; Thru: 2 x male XLR wired pin 2 hot;
IEC mains connector with integrated fuseholder
Level, Polarity, Boost, Boost Frequency
Power LED (blue), SIG LED (green), LIMIT LED (red)
Type: Class-D
Max Output Power: 2200 W
Input Sensitivity: +4dBu @ centre position for full rated power
Input Impedance: 10k unbalanced, 20k balancedΩ Ω
Amplifier Protection: Full short circuit, thermal, overcurrent, DC
USA / CAN: 100–120 V~ (T 12 A H 250 V)
UK / AUS / EUR: 220–240 V~ (T 6.3 A H 250 V)
CN: 220–240 V~ (T 6.3 A H 250 V)
JP: 100–120 V~ (T 12 A H 250 V)
280 W @ 1/8 max power
LS-1819 Low frequency driver
RC-1819 Recone kit
AMP-M15BM18B Replacement amplifier assembly
More information can be found on our website: www.turbosound.com
DIMENSIONS (HxWxD)
NET WEIGHT
COMPONENTS
FREQUENCY RESPONSE
MAXIMUM SPL
BOOST FREQUENCY
CONSTRUCTION
CONNECTORS
CONTROLS
INDICATORS
AMPLIFIER
MAINS VOLTAGE
POWER CONSUMPTION
SPARES & ACCESSORIES
MORE INFO
Milan M18B
2200-Watt 18” Powered Subwoofer
Frequency
Response
100
1
0
0
1
0
2
0
3
0
4
0
(dB) Level, Sound Pressure SPL
Frequency (Hz)
20 30 40 50 60 70 200 300 400 500
Milan M18B
2200-Watt 18” Powered Subwoofer
