Pagina 1/4

Connection

Installation Guide

5/6/16-Port Gigabit Desktop PoE Switch

LED Explanation

Note: For simplicity, we will take TL-SG1005P for example throughout this Guide.

Note:

1. PoE ports can also connect to non-PoE devices, but only transmit data.

2. TL-SG1005LP can supply up to 30 W for each PoE port and 40 W for all PoE ports.

3. TL-SG1005P can supply up to 30 W for each PoE port and 65 W for all PoE ports.

4. TL-SG1006PP can supply up to 60 W for port 1, 30W for other single PoE port, and 64 W

for all PoE ports.

5. TL-SG116P can supply up to 30 W for each PoE port and 120 W for all PoE ports.

DC Power Adapter

AC Power Cord

IP Camera AP IP Phone

Router

LAN Port WAN Port

Internet

Ethernet Ports (1-5)

PoE Ports (1-4)

Power

On: Power on

O: Power o

Power

Link/Act and PoE Status

On: Providing PoE power

Flashing: Current-overload/Short-circuit

O: Not providing PoE power

On (Green): Connected to a 1000 Mbps

device

On (Yellow): Connected to a 10/100

Mbps device

Flashing: Transmitting/receiving data

O: No device is connected to the

corresponding port.

PoE MAX

PoE Max

TL-SG1005LP

On: 33 W ≤ Total power supply < 40 W

Flashing: Total power supply ≥ 40 W

O: Total power supply < 33 W

TL-SG1005P

On: 58 W ≤ Total power supply < 65 W

Flashing: Total power supply ≥ 65 W

O: Total power supply < 58W

TL-SG116P

On: Total power supply ≥ 113 W

Flashing: Total power supply ≥ 113 W and

lasts for more than 2 minutes

O: Total power supply < 113W

PoE Devices

Switches Explanation

Priority (for TL-SG116P)

O: All the ports transmit data with the same priority.

On: The corresponding ports transmit data with a higher priority than other ports. When congestion

occurs, packets which are transmitted by the ports with a higher priority occupy the whole bandwidth.

Isolation (for TL-SG116P)

O: Ports can transmit data with each other.

On: The corresponding ports cannot transmit data with other downlink ports. They can transmit data

only with the uplink ports (ports 15-16 of TL-SG116P).

Extend (for TL-SG1005P/TL-SG1006PP/TL-SG116P)

O: The corresponding ports run at 10/100/1000 Mbps and support PoE power supply up to 100 m away.

On: The corresponding ports run at 10 Mbps and support PoE power supply up to 250 m away.

Recovery (for TL-SG1005P/TL-SG1006PP/TL-SG116P)

O: The PoE Auto Recovery function is disabled.

On: The switch will constantly detect the working status of a PoE powered device (PD). When the switch

nds that the PD works abnormally, the switch will reboot it.

Note: The numbers in brackets indicate the ports where the feature takes eect. For example, when Extend(1-4) is toggled to On, the Extend mode will be enabled for ports 1-4.

TL-SG1006PP

On: 57 W ≤ Total power supply < 64 W

Flashing: Total power supply ≥ 64 W

O: Total power supply < 57W

Frequently Asked Questions (FAQ)

The Power LED should be lit when the power system is working normally. If the Power LED is

not lit, please try the following:

A1:

Make sure the AC power cord is connected to the switch with power source properly.

A2:

Make sure the voltage of the power supply meets the requirements of the input voltage

of the switch.

A3: Make sure the power source is on.

Q1. Why is the Power LED not lit?

It is recommended that you check the following items:

A1: Make sure that the cable connectors are rmly plugged into the switch and the device.

A2: Make sure the connected device is turned on and works normally.

A3: The cable must be less than 100 meters long (328 feet). If Extend Mode is enabled, it

should be less than 250 meters (820 feet).

Q2. Why is the Link/Act LED not lit while a device is connected to

the corresponding port?

Q3. Why are PoE ports not supplying power for PoE devices?

When the total power consumption of connected PoE devices exceeds the maximum, the

PoE port with a smaller port number has higher priority. The system will cut o power to the

ports with larger port numbers to ensure supplying to other ports.

Take TL-SG1005P as an example. If port 1, 2 and 4 are consuming 15.4 W respectively, and

an additional PoE device with 19 W is connected to port 3, the system will cut o the power

of port 4 to compensate for the overload.

TP-Link hereby declares that the device is in compliance with the essential requirements

and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and

(EU)2015/863.

The original EU declaration of conformity may be found at

https://www.tp-link.com/en/support/ce/

EU declaration of conformity

UK declaration of conformity

TP-Link hereby declares that the device is in compliance with the essential requirements

and other relevant provisions of the Electromagnetic Compatibility Regulations 2016 and

Electrical Equipment (Safety) Regulations 2016.

The original UK declaration of conformity may be found at

https://www.tp-link.com/support/ukca

IEEE802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3x,IEEE802.3af,

IEEE802.3at, IEEE802.3bt (for TL-SG1006PP only), IEEE802.1p

For TL-SG1005LP/TL-SG1005P:

5 10/100/1000 Mbps RJ45 Ports

Auto-Negotiation MDI/MDIX

PoE Ports: Port 1-Port 4

For TL-SG1006PP:

6 10/100/1000 Mbps RJ45 Ports

Auto-Negotiation MDI/MDIX

PoE Ports: Port 1-Port 4

For TL-SG116P:

16 10/100/1000 Mbps RJ45 Ports

Auto-Negotiation MDI/MDIX

PoE Ports: Port 1-Port 16

Total Power Supply:

40 W (TL-SG1005LP)/65 W (TL-SG1005P)/64W (TL-SG1006PP)/

120 W (TL-SG116P)

10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m);

EIA/TIA-568 100Ω STP (maximum 100 m)

100BASE-TX: UTP category 5, 5e cable (maximum 100 m);

EIA/TIA-568 100Ω STP (maximum 100 m)

1000BASE-T: UTP category 5e cable or above (maximum 100 m);

EIA/TIA-568 100Ω STP (maximum 100 m)

10 Gbps (TL-SG1005LP/TL-SG1005P)/12Gbps (TL-SG1006PP)/

32 Gbps (TL-SG116P)

Store-and-Forward

Automatically learning, automatically aging

External Power Adapter

Input: 100-240 VAC, 50/60 Hz

Output:

53.5 VDC /0.81 A (TL-SG1005LP)

53.5 VDC /1.31 A (TL-SG1005P/TL-SG1006PP)

53.5 VDC /2.43 A (TL-SG116P)

Yes

39 mm (TL-SG1005LP/TL-SG1005P)/94mm (TL-SG1006PP)/

200 mm (TL-SG116P)

Standard

General Specications

Operating Temperature

Storage Temperature

Operating Humidity

Storage Humidity

0 C to 40 C (32 F to 104 ˚ ˚ ˚ ˚F)

-40 C to 70 C (-40 F to 158 ˚ ˚ ˚ ˚F)

10% to 90%RH non-condensing

5% to 90%RH non-condensing

Environmental and Physical Specications

Specications

For technical support and other information, please visit

https://www.tp-link.com/support, or simply scan the QR code.

To ask questions, find answers, and communicate with TP-Link

users or engineers, please visit https://community.tp-link.com

to join TP-Link Community.

Interface

Safety Information

Keep the device away from water, re, humidity or hot environments.

Do not attempt to disassemble, repair, or modify the device. If you need service, please

Place the device with its bottom surface downward.

Do not use damaged charger or USB cable to charge the device.

Do not use any other chargers than those recommended.

Adapter shall be installed near the equipment and shall be easily accessible.

Wall Mountable

Distance Between

Mounting Holes

Network Media (Cable)

Switching Capacity

Power Supply

Transfer Method

MAC Address Learning

The plug on the power supply cord is used as the disconnect device, the

socket-outlet shall be easily accessible.

A1: Before upgrading a connected PoE powered device (PD), disable PoE Auto Recovery to

avoid the PD’s damage.

A2: When a PD does not send data packets to the switch for a long period in certain

scenarios (e.g. an IPC in sleep mode), disable PoE Auto Recovery to avoid the PD

repeatedly rebooting.

Q4. What should I notice before using the PoE Auto Recovery

feature?

Product specificaties

Merk:	TP Link
Categorie:	Schakelaar
Model:	TL-SG116P
Kleur van het product:	Zwart
Breedte:	286 mm
Diepte:	111.7 mm
Hoogte:	25.4 mm
Materiaal behuizing:	Metaal
LED-indicatoren:	Ja
Stroom:	0.6 A
Meegeleverde kabels:	AC
Snelstartgids:	Ja
Vermogensverbruik (max):	144.28 W
DC voltage input:	9 V
Netwerkstandaard:	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Temperatuur bij opslag:	-40 - 70 °C
Luchtvochtigheid bij opslag:	5 - 90 procent
Vermogenstoevoer inclusief:	Ja
Ophangsysteem voor aan de muur:	Ja
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Auto MDI/MDI-X:	Ja
Virtuele LAN-functies:	Protocol-based VLAN, Tagged VLAN
Power over Ethernet (PoE):	Nee
Stapelbaar:	Ja
Switchingcapaciteit:	32 Gbit/s
MAC-adrestabel:	8000 entries
Datastroombeheer:	Ja
Rate limiting:	Ja
Aantal VLANs:	32
IGMP snooping:	Ja
Switch type:	Unmanaged
Aantal basis-switching RJ-45 Ethernet-poorten:	16
Aantal Gigabit Ethernet (koper)-poorten:	16
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Packet buffergeheugen:	4.1 MB
Jumbo Frames ondersteuning:	Ja
Port mirroring:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
Koperen ethernetbekabelingstechnologie:	10BASE-T, 100BASE-TX, 1000BASE-T
Warmtedissipatie:	490.55 BTU/h
Auto-negotiation:	Ja
AC-ingangsspanning:	220 V
AC-ingangsfrequentie:	50 Hz
Stroomverbruik (typisch):	11.72 W
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
Verzending snelheid:	23.81 Mpps
Jumbo frames:	9000
Broadcast stormbeheer:	Ja
Bescherming lus:	Ja
Store-and-forward:	Ja
Ondersteundende kabel types:	Cat3, Cat4, Cat5, Cat5e, Cat6
Aantal wachtrijen:	4
Kabellengtedetectie:	Ja
