Safety instructions

Intended use

This device is used to receive radio signals and transform them into acoustic signals.

Any other use or use under other operating conditions is considered to be improper

and may result in personal injury or property damage. No liability will be assumed

for damages resulting from improper use.

Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and are

not within reach of babies and young children. Choking hazard! Ensure

that children do not detach any small parts (e.g. knobs or the like) from

the unit. They could swallow the pieces and choke! Never let unattended children

use electrical devices.

Where to use the product

Never use the product

• in direct sunlight

• in conditions of extreme temperature or humidity

• in extremely dusty or dirty areas

• at locations where the unit can become wet

• near magnetic elds

Tour Guide Mini Receiver

User manual

This manual contains important information on the safe operation of the device.

Read and follow the safety advice and instructions given. Retain the manual for

future reference. If you pass the device on to others please include this manual.

Interference with other electrical equipment

Using the device near radios or TV sets may cause interference. Then increase the

distance between the devices.

General handling

• To prevent damage, never use force when operating the switches and controls.

• Never immerse the appliance in water. Just wipe it with a clean dry cloth. Do not

use liquid cleaners such as benzene, thinners or ammable cleaning agents.

Keep foreign substances from the unit!

Keep the device away from containers with liquids. Should any liquid get into the

unit, this could lead to its destruction or re. Be sure not to let any metal objects

into the unit.

Possible hearing damage

With earphones connected, the device can produce volume levels that

may cause temporary or permanent hearing impairment. Do not operate

the device permanently at high volume. Decrease the volume level

immediately if you experience ringing in your ears or hearing impairment.

Features

• 16 transmission channels selectable

• Automatic synchronization of the transmission channel at channel change on

transmitter

• 3.5mm mini phone headphones output socket

• Service coverage: 50m (indoor) / 90m (outdoor)

• Fixed built-in rechargeable lithium polymer battery (3.7V • 600mAh)

• Micro USB charging connector

• 16 hours operating time per battery charge

Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • info@thomann.de DocID: 386330_25.11.2019

Using the device

1. Use an appropriate USB charging station to charge the device. A full charge of

the built-in battery takes about 6 hours.

2. Connect the headset cable to the 3.5 mm mini phone socket (5).

3. Keep the on / o button (3) pressed for two seconds to turn the unit on. The

display (1) lights up and indicates the current transmission channel.

4. To select another channel keep the +/–buttons (4, 2) simultaneously pressed

for two seconds. The CH indicator ashes on the display and the icon

disappears. Use the +/–buttons to select the desired channel.

5. To conrm the selection, briey press the on / o button (3) or wait ve seconds

for the unit to save the new channel automatically. The CH indicator stops ash-

ing and the icon appears again. Make sure that transmitter and receiver are

always set to the same transmission channel. The display will ash continuously

when the device is not receiving a signal.

6. Eight dierent volume levels between (mute) and (full) are adjusta-

ble. To increase the volume press the +button (4), to reduce it press the –button

(2).

7. When the battery is fully charged, the display shows icon is . When this

ashing, only 10% battery power are remaining and you need to charge the

battery. During charging, this icon appears:

8. The unit turns o during charging. To use it during charging, keep the on / o

button (3) pressed for two seconds to turn the unit on.

9. The unit automatically turns o after 20 minutes without signal reception. To turn

the device o manually, keep the on / o button (3) pressed for two seconds.

10. The minimum distance between receiver and transmitter is 30 cm.

For the transport and protective packaging, environmentally friendly materials

have been chosen that can be supplied to normal recycling. Ensure that plastic

bags, packaging, etc. are properly disposed of. Do not just dispose of these ma-

terials with your normal household waste, but make sure that they are collected for recy-

cling. Please follow the notes and markings on the packaging.

This product is subject to the European Waste Electrical and Electronic Equip-

ment Directive (WEEE) in its currently valid version. Do not dispose of your old

device with your normal household waste. Dispose of this product through an

approved waste disposal rm or through your local waste facility. Comply with

the rules and regulations that apply in your country. If in doubt, consult your local waste

disposal facility.

Operating elements

1. LCD

2. Channel selection / volume down

3. On / o switch | calling up setting parameters

4. Channel selection / volume up

5. Head set connection

6. Eyelet for lanyard

7. Micro USB charging

connector

Channel / frequency chart

863~865MHz

Cha. Cha. Cha. Cha.Freq. Freq. Freq. Freq.

01 863.060 05 863.185 09 863.310 13 863.435

02 863.560 06 863.685 10 863.810 14 863.935

03 864.060 07 864.185 11 864.310 15 864.435

04 864.560 08 864.685 12 864.810 16 864.935

To reset the software, press the + / –buttons four times simultaneously and then

hold them down until "01" and "02" ash in the display. When "01" ashes, press the

–button and then conrm with the On / o switch. Now try to connect transmitter

and receiver.

Technical specications

NF transmission range: 40Hz – 18kHz

Audio sampling rate: 8kHz 16bit

Dynamic range: >70dB

Signal-to-noise: >65dB

Modulation: GFSK

Latency: 22ms

Carrier frequency range: 794 – 937,5MHz

Charging source: 5V Micro-USB

Charging time: <6Stunden

Dimensions (W×H×D): 40×69×12mm

Weight: 32g
