Pagina 1/143

C9X299-PGF

C9X299-RPGF

USER’S MANUAL

Revision 1.0b

The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The

vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes

no commitment to update or to keep current the information in this manual, or to notify any person

or organization of the updates. Please Note: For the most up-to-date version of this manual,

please see our website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product de-

scribed in this manual at any time and without notice. This product, including software and documenta-

tion, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or

reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDEN-

TAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY

TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall be

the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all claims

will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class B

digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a consumer environment

or residential installation. This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the manufacturer’s instruction manual, may cause

harmful interference with radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference, in which case you will be required to correct the interference

at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning

applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-

special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

Manual Revision: 1.0b

Release Date: July 28 ,2020

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

iii

Preface

This manual is written for system integrators, PC technicians and

knowledgeable PC users. It provides information for the installation and

use of the C9X299-PGF/-RPGF motherboard.

Manual Organization

Chapter 1 describes the features, specications and performance of

the motherboard, and provides detailed information on the Intel X299

chipset.

Chapter 2 provides hardware installation instructions. Read this chap-

ter when installing the processor, memory modules and other hardware

components into the system.

Chapter 3 describes troubleshooting procedures for video, memory and

system setup stored in the CMOS.

Chapter 4 includes an introduction to the BIOS, and provides detailed

information on running the CMOS Setup utility.

Appendix A provides BIOS Error Beep Codes.

Appendix B lists software program installation instructions.

Appendix C contains UEFI BIOS Recovery instructions.

Preface

Product specificaties

Merk:	Supermicro
Categorie:	Moederbord
Model:	C9X299-PGF
Breedte:	243.8 mm
Diepte:	304.8 mm
Ethernet LAN:	Ja
Type stroombron:	ATX
VGA (D-Sub)poort(en):	1
Aantal Ethernet LAN (RJ-45)-poorten:	2
Duurzaamheidscertificaten:	RoHS
Meegeleverde software:	SuperDoctor® 5, Watchdog
Ondersteunt Windows:	Ja
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Processor socket:	LGA 2066 (Socket R4)
Thermal Design Power (TDP):	165 W
Processorfabrikant:	Intel
Maximum intern geheugen:	128 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	- kanalen
Ondersteunt Linux:	Ja
Ethernet interface type:	5 Gigabit Ethernet, Gigabit Ethernet
Chipset moederbord:	Intel® X299
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	3
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC1220
RAID support:	Ja
PCI Express x16 (Gen 3.x) slots:	4
PCI Express x1 (Gen 3.x) slots:	1
Ondersteunde opslagstationinterfaces:	M.2, SATA III
Component voor:	Server
Geheugen voltage:	1.2 V
LAN controller:	Intel® I210-AT
Soorten RAID:	0, 1,5, 10
Aantal SATA III connectors:	6
Non-ECC:	Ja
Compatibele processors:	Intel Core i9 Extreme Edition, Intel Core i5, Intel Core i7, Intel Core i9
Maximum UDIMM geheugen:	128 GB
Aantal DIMM sloten:	8
Ondersteunende RDIMM klok snelheden:	1600,1866,2133,2400 MHz
Ondersteunend DIMM module capaciteiten:	4GB, 8GB, 16GB
Ondersteunde geheugen types:	DDR4-SDRAM
Moederbord chipset familie:	Intel
Moederbord form factor:	ATX
Aantal geheugenslots:	8
Supported memory clock speeds:	1600,1866,2133,2400,2666 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	128 Mbit
COM aansluitingen:	1
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	4
PC gezondheids monitor:	FAN, Power supply, Voltage
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	2
Processor thermaal vermogen (max):	165 W
Aantal M.2 (M) slots:	1
USB 3.2-connectoren (3.1 Gen 2):	4
Intelligent Platform Management Interface (IPMI) support:	Ja
Waakhondfunctie:	Ja
