32 BUTTON REMOTE CONTROL

PANEL

MKS-R3210

16 BUTTON LCD REMOTE

CONTROL PANEL

MKS-R1620

UNIVERSAL 16 LCD REMOTE

CONTROL PANEL

MKS-R1630

Operating Instructions

4-733-749-14 (1)

Table of Contents

Overview.................................................................... 3

Features ..........................................................................3

Button Function Settings .................................................3

System Connection Example ..........................................4

Locations and Functions of Parts........................... 5

Front Panel ......................................................................5

Rear Panel ......................................................................7

Status Display Window (MKS-R1630) ............................8

Preparations............................................................ 13

Notes on Installation ......................................................13

Setting Up the Unit ........................................................13

Connections with System Controllers ...........................13

Key Label Indications ....................................................13

Configuring Using the Buttons ......................................15

Operations............................................................... 16

Configuring Using a System Controller and Web

Menu ..........................................................................16

Pinned Buttons, Selection Buttons, and Function

Buttons .......................................................................16

Switching Between Source Selection Mode and

Destination Selection Mode .......................................17

Switching Crosspoints ...................................................17

Assigning a Source/Destination to a Selection

Button (Assign) ..........................................................18

Switching a Different Source for Each Level

(Breakaway) ...............................................................19

Switching Multiple Crosspoints Simultaneously

(Salvo) .......................................................................21

Take Mode ....................................................................21

Pages and Page Groups ...............................................22

Switching and Monitoring Two Sources (Chop) ............22

Preventing Source Switching for Destinations

(Protect) .....................................................................23

Preventing Accidental Operation (Lock) ........................23

Monitoring Destinations .................................................23

Level Control .................................................................24

Retrace Function ...........................................................24

Linkage Function ...........................................................24

Web Menu................................................................ 25

Displaying the Web Menu .............................................25

Screen Configuration ....................................................25

Panel Table Page ..........................................................26

Source Reentry Lists Page ...........................................26

Salvo Table Page ..........................................................27

Available Src/Dest Page ...............................................27

Control Area Page .........................................................27

Alias Name Lists Page ..................................................28

Default Controls Page ...................................................28

Operation Settings Page ...............................................28

Display Settings Page ...................................................29

Retrace Settings Page ..................................................30

Linkage Settings Page ..................................................31

Page Group Settings Page ...........................................31

Network Settings Page ..................................................32

Remote Maintenance Page ...........................................32

Time Settings Page .......................................................33

System Page .................................................................33

CSV ...............................................................................34

Usage Precautions ................................................. 35

Error/Warning Messages ....................................... 36

Specifications ......................................................... 38

Overview

The MKS-R3210/R1620/R1630 is a remote control panel that

connects to a PWS-100NM1/110NM1 running IP Live

System Manager (system controller) to switch the routing of

video signals and audio signals. You can use the selection

buttons on this unit to switch the source/destination of signals

of Networked Media Interface devices or to switch the

source/destination of a routing switcher.

Features

Large buttons that display functions in different

colors

Employs large selection buttons on the front panel designed

for easy operation. Selection buttons light up green or amber,

dimly or brightly to show their functions and the currently

selected source and destination.

You can set the button color and brightness in the web menu

to suit the operating environment to make the buttons more

visible.

Buttons to select sources and destinations

All selection buttons on the front panel can be used as source

selection buttons or destination selection buttons according

to settings in the web menu. The current setting can be easily

discerned by the color of the button when lit.

Display of switch names using key labels

The source or destination name, set using the web menu, can

be shown on a key label on each button. Key labels are

interchangeable.

Controllable up to 128 levels 1)

Up to 128-level (128 signals) control is supported using

settings configured using the web menu.

1) Levels

To handle different kinds of signals simultaneously, it is necessary

to use a routing switcher for each type of signal. For example, a

recording to be made on a VTR requires the use of five signal

levels: video, audio 1, audio 2, timecode and remote control

signals. These are collectively referred to as levels.

Different sources for each level are selectable

(breakaway function)

You can select and display different sources for each level

using the breakaway function.

Monitor function to watch the selection status or

other outputs

When a destination you wish to monitor is set as a monitor

destination, the source automatically switches to the same

source as the monitor destination when the monitor function

is set to ON.

Switching between two sources alternately (chop

function)

The chop function switches between two sources alternately

at a specified interval automatically.

Switching of multiple crosspoints using a single

operation (salvo function)

When multiple crosspoints have been selected and a salvo is

defined beforehand using the web menu, all the crosspoints

set for the salvo can be switched by pressing one button.

Self-diagnostics function

The unit automatically performs self-diagnostics, such as

communications status checks. The diagnostics results

appear in the display window.

System redundancy support

The unit features dual power supplies and networks to

support system redundancy.

Display window for each selection button

(MKS-R1620/R1630)

On the MKS-R1620, a display window is assigned to each

selection button. On the MKS-R1630, the selection buttons

themselves are display windows. Each selection button has a

2-line, 6-character (3 full-width character) display window.

The source name is displayed in the display window of source

selection buttons, and the destination name is displayed in

the display window of destination selection buttons.

Status display function (MKS-R3210/R1620)

The currently selected source name, destination name, and

any error messages are displayed.

Status display function using a 2-inch color LCD

(MKS-R1630)

A large LCD display shows source names, destination

names, errors, levels, and other information.

Button Function Settings

The selection buttons can be used as either source selection

buttons or destination selection buttons. You can define the

function of each button using the web menu. The settings are

made for each button. A source selection button can select

the input signal assigned to a button upon your merely

pressing that button.
