Pagina 1/29
www.radialeng.com
True to the Musicâ„¢
®
User Guide
CATAPULT RACK
TX & RX
CAT 5 ANALOG AUDIO SNAKE
Radial Engineering Ltd.
1165-1845 Kingsway Ave, Port Coquitlam
British Columbia, Canada, V3C 0H3
Tel: 604-942-1001 • www.radialeng.com
Email: info@radialeng.com
Table of Contents Page
Overview.......................................................................................1
Features 2-3 ...................................................................................
Making Connections 4 .....................................................................
Lifting the Ground 5 .........................................................................
Using the Catapult TX and RX as a Pair 5 ......................................
The Radial Catapult Family 6 ..........................................................
Additional Applications.............................................................. 7-8
Speciîš¿cations ...............................................................................9
Warranty Back cover .......................................................................
Thank you for purchasing the Radial Catapultâ„¢ Rack modular
snake, a Cat 5 analog audio snake system that is designed
to simplify stage setups, take advantage of pre-existing wire
infrastructure, and work in combination with other Catapult
modules.
We recommend you take a few minutes to read this short manual
before you begin using the Catapult Rack TX or RX, as it covers
the various features of these devices and tips for setup and
use. Should you have any questions about the Catapult Rack or
any other Radial Catapult modules, please visit our website at
www.radialeng.com for additional resources and frequently asked
questions.
Radial® Reamp Station User Guide
True to the Music
Radial Engineering Ltd. Catapult Rackâ„¢
OVERVIEW
The Catapult Rack TX and RX both act like typical multi-channel analog
audio snakes; they allow you to send balanced mic or line-level signals
from one location to another without signal loss, noise, or interference,
and without any digital audio conversion needed. However, unlike typical
analog snakes that require bulky and expensive multi-channel audio
cables, the Catapult system makes use of Cat 5 Ethernet cabling, which
is widely available, lightweight, and economical.
Simply connect one shielded Cat 5 cable for every four channels of audio
and deliver it to any other Radial Catapult module – it will utilize the
analog conductors in the cable to deliver four balanced audio lines to any
destination. As many buildings are already pre-wired for Cat 5, you can
take advantage of this to transmit audio between distant rooms without
the need to install or supply new cable. And since the Catapult system is
modular, you can mix and match di󰀨erent transmit and receive boxes to
best suit your application.
Each Catapult Rack unit operates like three separate Catapult modules in
one chassis. The 12 XLRs on the chassis are split into three banks, each
with their own noise-eliminating ground lift switch and RJ45 Ethernet
jacks on the rear panel. You can use three Ethernet cables to connect
all 12 channels to a single location, or split them o󰀨 to any of the Radial
Catapult stage boxes, providing you with a fully customizable audio snake
system that can connect to multiple destinations at once. The Catapult
Rack TX features all female XLR connectors, while the Catapult Rack RX
has 12 male XLR connectors.
1
The Catapult Rack RX
The Catapult Rack TX
