[en] Instructions for installation and use

Extractor hood

Ú Table of contents

[en]Instructions for installation and use

INSTRUCTION MANUAL.......................................................... 2

8Intended use................................................................... 2

(Important safety information........................................ 3

7Environmental protection ............................................. 5

ÇOperating modes ........................................................... 5

1Operating the appliance................................................ 6

2Cleaning and maintenance ........................................... 7

3Trouble shooting ........................................................... 9

4Customer service .......................................................... 9

INSTALLATION INSTRUCTIONS .......................................... 11

(Important safety information...................................... 12

KGeneral information .................................................... 14

5Installation ................................................................... 15

INSTRUCTION MANUAL

Produktinfo

Additional information on products, accessories,

replacement parts and services can be found at

www.neff-international.com and in the online shop

www.neff-eshop.com

8Intended use

Intended use

Read these instructions carefully. Only then

will you be able to operate your appliance

safely and correctly. Retain the instruction

manual and installation instructions for future

use or for subsequent owners.

The appliance can only be used safely if it is

correctly installed according to the safety

instructions. The installer is responsible for

ensuring that the appliance works perfectly at

its installation location.

This appliance is intended for domestic use

and the household environment only. The

appliance is not intended for use outside. Do

not leave the appliance unattended during

operation. The manufacturer is not liable for

damage which is caused by improper use or

incorrect operation.

This appliance is intended for use up to a

maximum height of 2000 metres above sea

level.

This appliance may be used by children over

the age of 8 years old and by persons with

reduced physical, sensory or mental capacity

or by persons with a lack of experience or

knowledge if they are supervised by someone

who is responsible for their safety, or have

been instructed in how to use the appliance

safely and have understood the risks involved

in not using it properly.

Children must not play with the

appliance.Cleaning and user maintenance

must not be performed by children unless they

are over 15 years of age and are supervised.

Keep children below the age of 8 years old at

a safe distance from the appliance and power

cable.

Check the appliance for damage after

unpacking it. Do not connect the appliance if it

has been damaged in transport.

This appliance is not intended for operation

with an external clock timer or a remote

control.

Important safety information en

(Important safety

information

Important safety information

:Warning

Danger of suffocation!

Packaging material is dangerous to children.

Never allow children to play with packaging

material.

:Warning

Danger of death!

Risk of poisoning from flue gases that are

drawn back in.

Always ensure adequate fresh air in the room

if the appliance is being operated in exhaust

air mode at the same time as room air-

dependent heat-producing appliance is being

operated.

Room air-dependent heat-producing

appliances (e.g. gas, oil, wood or coal-

operated heaters, continuous flow heaters or

water heaters) obtain combustion air from the

room in which they are installed and discharge

the exhaust gases into the open air through an

exhaust gas system (e.g. a chimney).

In combination with an activated vapour

extractor hood, room air is extracted from the

kitchen and neighbouring rooms - a partial

vacuum is produced if not enough fresh air is

supplied. Toxic gases from the chimney or the

extraction shaft are sucked back into the living

space.

■Adequate incoming air must therefore

always be ensured.

■An incoming/exhaust air wall box alone will

not ensure compliance with the limit.

Safe operation is possible only when the

partial vacuum in the place where the heat-

producing appliance is installed does not

exceed 4 Pa (0.04 mbar). This can be

achieved when the air needed for combustion

is able to enter through openings that cannot

be sealed, for example in doors, windows,

incoming/exhaust air wall boxes or by other

technical means.

In any case, consult your responsible Master

Chimney Sweep. He is able to assess the

house's entire ventilation setup and will

suggest the suitable ventilation measures to

you.

Unrestricted operation is possible if the vapour

extractor hood is operated exclusively in the

circulating-air mode.

:Warning

Risk of fire!

■Fatty deposits in the grease filter may catch

fire. Regularly clean the grease filter. Never

operate the appliance without a grease

filter.

Risk of fire!

■Grease deposits in the grease filter may

catch fire. Never work with naked flames

close to the appliance (e.g. flambéing). Do

not install the appliance near a heat-

producing appliance for solid fuel (e.g.

wood or coal) unless a closed, non-

removable cover is available. There must

be no flying sparks.

Risk of fire!

■Hot oil and fat can ignite very quickly. Never

leave hot fat or oil unattended. Never use

water to put out burning oil or fat. Switch off

the hotplate. Extinguish flames carefully

using a lid, fire blanket or something similar.

Risk of fire!

■When gas burners are in operation without

any cookware placed on them, they can

build up a lot of heat. A ventilation

appliance installed above the cooker may

become damaged or catch fire. Only

operate the gas burners with cookware on

them.

Risk of fire!

■Operating several gas burners at the same

time gives rise to a great deal of heat. A

ventilation appliance installed above the

cooker may become damaged or catch fire.

Never operate two gas burners

simultaneously on the highest flame for

longer than 15 minutes. One large burner of

more than 5 kW (wok) is equivalent to the

power of two gas burners.

Product specificaties

Merk:	Neff
Categorie:	Afzuigkap
Model:	DMK651IHM2
Soort bediening:	Touch
Kleur van het product:	Zwart
Ingebouwd display:	Ja
Gewicht:	20500 g
Breedte:	590 mm
Diepte:	499 mm
Netbelasting:	263 W
Snoerlengte:	1.3 m
Geluidsniveau:	58 dB
Energie-efficiëntieklasse:	B
Jaarlijks energieverbruik:	57 kWu
Soort:	Muurmontage
Motor vermogen:	260 W
Uitlaat aansluiting diameter:	150 mm
Illuminance:	100 Lux
Maximale afzuigcapaciteit:	700 m³/uur
Afzuigmethode:	Afvoerend/recirculerend
Fluid dynamic efficiency class:	B
Verlichtingefficiëntieklasse:	B
Vetfilterefficiëntieklasse:	C
Geluidsniveau (lage snelheid):	48 dB
Minimale afstand van electrische hob:	450 mm
Minimale afstand van gas hob:	650 mm
Aantal lampen:	2 gloeilamp(en)
Type lamp:	LED
Soort vetfilter:	Aluminium
Wasbaar filter:	Ja
Hoogte (min):	928 mm
Hoogte (max):	1258 mm
Vermogen lamp:	1.5 W
Geluidsniveau (hoge snelheid:	58 dB
Maximum hercirculeringsvermogen:	367 m³/uur
Aantal snelheden:	4
Stroom:	10 A
Intensieve stand:	Ja
Geluidsniveau (intensieve snelheid):	67 dB
Luchtkanaalslang inbegrepen:	Ja
Certificering:	CE, EAC-Eurasian, VDE
AC-ingangsspanning:	220 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Type beeldscherm:	LED
Energie-efficiëntieschaal:	A+++ tot D
