Pagina 1/7
VIV60V2 | COAXIAL SPEAKERS
designed and developed in the united states.
Woofer Technical Information
Specifications
Features
Nominal Diameter 6.49 in // 165mm
Driver mounting depth 2.91 in // 74mm
Speaker weight 1520 g
Basket Material ALUMINUM
Magnet height .71in // 18 mm
3.93 x 1.77 x 7.1 in // 100 x 45 x 18 mm
Size 6.5
RMS/PEAK (w)
Sensitivity (dB)
75/150
90
Magnet Size (oz) 20
Mounting Depth (in) 2.95
Magnet diameter
Magnet weight 20 OZ
Woofer Technical Information
Voice Coil Diameter 1.18 in // 30 mm
Voice Coil Former Material KSV
Voice Coil Nominal Impedance 2 OHM
Cone Material Fiberglass & Foam Composite
Surround Material Rubber
Tweeter Technical Information
Dome Material Silk
Dome Diameter 1.45 in // 37 mm
Voice Coil Diameter .98 in // 25 mm
Crossover Technical Information
Crossover Type 2WAY
Tweeter Settings
Tweeter Crossover Slope 12dB
Tweeter Crossover F quenc re 4800Hz
Woofer Crossover Slope
Woofer Crossover Frequenc
6dB/12dB
4800 Hz
Cast Aluminum Basket
Silk Dome Tweeter
VIV60V2 | COAXIAL SPEAKERS
• Cast aluminum Six Five Series basket
• Dual layer composite fiber cone
• Tuned surround for extra flat response
• Versatile crossover settings
• Audiophile grade features and performance
• Silk tweeter
• Grill included
+3dB/0dB/-3dB
VIV60V2 | COAXIAL SPEAKERS
SIXFIVE SERIES WARRANTY
Length of Warranty
What Is Covered
Who Is Covered
What Is Not Covered
Limit on Implied Warranties
EU Warranty
How To Obtain Service
SixFive Series Component Speakers – 2 Year
Ask your installing dealer about warranty extensions that may be available.
Memphis Car Audio offers a limited warranty on Memphis Car Audio products on the following terms:
This warranty applies only to Memphis Car Audio products sold to consumers by Authorized Memphis Car Audio
Dealers in the United States of America or its possessions.
This warranty covers only the original purchaser of Memphis Car Audio product purchased from an Authorized
Memphis Car Audio Dealer in the United States. In order to receive service, the purchaser must provide Memphis
Car Audio with a copy of the receipt stating the consumer name, dealer name, product purchased, and date of
purchase. Products found to be defective during the warranty period will be repaired or replaced (with a product
deemed to be equivalent) at Memphis Car Audio’s discretion.
1. Damage caused by accident, abuse, improper operation or installation, water, theft, shipping.
2. Any cost or expense related to the removal or re installation of product.
3. Service performed by anyone other than Memphis Car Audio.
4. Any product which has had the serial number defaced, altered, or removed.
5. Subsequent damage to other components.
6. Any product purchased outside the US.
7. Any product not purchased from an authorized Memphis Car Audio Dealer.
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the
period of the express warranty set forth above. Some states do not allow limitations on the length of an implied
warranty, so this limitation may not apply. No person is authorized to assume for Memphis Car Audio any other
liability in connection with the sale of the product.
This product meets the current EU warranty requirements. See your Authorized dealer for details.
Contact the Authorized Memphis Car Audio Dealer you purchased this product from.
If you need further assistance, call 1-800-489-2300 for Memphis Car Audio’s Customer Service.
YOU MUST OBTAIN A RETURN AUTHORIZATION (RA#) TO RETURN ANY PRODUCT TO MEMPHIS CAR AUDIO’S
WARRANTY FACILITY. NO PRODUCT WILL BE ACCEPTED WITHOUT THIS RETURN AUTHORIZATION!
You are responsible for shipment of product to Memphis Car Audio. Repaired and replaced product will be
returned freight prepaid.
FOR MORE INFORMATION, PLEASE VISIT: WWW.MEMPHISCARAUDIO.COM
