LOCATION OF CONTROLS:
1.
5V/AUX (In) PORT (For Charge and Aux/Line In)
2. USB Port
3. Micro SD Card Slot
4. LED Display
5. MODE Button
6. Button
7. Button
8. Button
9. (Power On-Off/Decorative Light On-Off )
Button
POWER SOURCE:
The unit has a built-in Li-ion rechargeable battery, charge it
before first time use or when it is drained as follows:
1. Connect the Micro USB Plug from supplied Connection
Cable to the 5V/AUX (In) Port on the top of unit.
2. Connect the full size USB Plug from supplied Connection
Cable to the USB Port on the Personal Computer or USB
Charger (Computer and USB Charger not included).
To Computer or
any USB Charger
3. When charging, the Red Charge Indicator inside the
5V/AUX (In) PORT will illuminate. When charging is
complete, it will turn off.
4. During charging, you can also play and listening music at
the same time.
Notes:
Your battery will last longer if you following these simple
guidelines for caring and storing:
A. Before first time use, recharge the unit approximately 4
hours until the unit is fully charged.
B. Charge and store the unit within the temperature range of
5°C - 35°C (40°F - 95°F).
SIZE: 70x158mm
FCC NOTICE:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and
receiver.
● Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV
technician for help.
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
C. Do not overcharge (longer than 24 hours). Excessive
charging or running the unit until battery fully drains will
damage battery. Battery life will be extended if you keep
the battery fully charged.
D. Battery life naturally shortens slowly over time.
E. The rechargeable battery incorporated in this product is
not user replaceable.
OPERATION:
General Operation:
1.
Recharged the built-in Li-ion battery as previously instructed.
2. Press and hold the (Power On-Off/Decorative Light
On-Off ) Button until the LED Display illuminate to power
on the unit.
3. Press the MODE Button repeatedly to switch to desired
playback mode. The unit will display with your selection
(see list below):
Note:
If the Micro SD Card and/or USB Device had NOT
inserted/installed into the unit, the correspondence
selection will not available.
4. During playback, press and release the or
buttons repeatedly to adjust volume level as desired.
5. Press the (Power On-Off/Decorative Light On-Off )
Button to turn off the Decorative LED Lights; press again
to turn it back.
6. When finished listening, press and hold the (Power
On-Off/Decorative Light On-Off ) Button to shut off the
unit.
BT Mode:
BT (Bluetooth) pairing:
First time use or re-pairing the unit to a new BT Device, pair
as follows:
1. Power on the unit and enter to BT mode as previously
instructed. The “bLUE” will appear on the display and
blink.
TROUBLE SHOOTING GUIDE:
Check the following before requesting service:
SPECIFICATIONS:
PACKAGE INCLUDES:
1 x Owner's Manual
1 x Connection Cable (For charge and Aux/Line In)
1 x Detachable shoulder strap
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT
TO CHANGE WITHOUT NOTICE.
POSSIBLE SOLUTION
Recharge the built-in battery as
page 2.
Increase the volume level by
press and release the
Button repeatedly
POSSIBLE CAUSE
Built in battery drained
Volume of the unit was
set to minimum position
SYMPTOM
Can’t power on
No sound or
sound weak
Sound
distortion
Power Source
Impedance of Speakers
Audio Power
BT Version
BT Operation Distance
Built-in DC 3.7V, 1200 mAH (4.44WH)
rechargeable Li-ion battery;
Recharge by
DC 5V through the 5V/AUX (In) Port
5 W; 3 Ω
3 W RMS（ ）
4.2
≧ 32 Feet in open area
BT (Bluetooth)
TF (Micro SD) Card
Showing on Display:Playback Modes:
“bLUE” will appear on the display
“Sd” will appear on the display and
indicator “SD” on display will illuminate;
music in the card will be playback
automatically
“USb” will appear on the display and
indicator “USB” on display will illuminate;
music in the USB Device will be playback
automatically
“LlnE” will appear on the display Line In (AUX In)
USB
2. Power on the external BT Device and enter to BT
searching mode. Start pairing following the on screen
instructions from the external BT Device. When paired,
the unit will sound a prompt voice "bLUE" appeared on
the display will stop blinking.
3. If pairing is complete you may now play music with your
external BT Device.
4. During playback:
● Press the Button to pause, press again to resume
normal playback.
● Press and hold the or Buttons to skip tracks.
● Press and release the or Buttons repeatedly
to adjust volume level as desired.
5. When finished listening, press and hold the (Power
On-Off/Decorative Light On-Off ) Button to shut off the
unit.
Notes:
● When the external BT Device searched the unit, our
model number “MMA3685” will appear on the display of
external BT Device.
● If while pairing you are asked for a code please try
"0000" or "1234".
Normal operation after pairing:
1. Power on the external BT Device and enter to BT
playback mode.
2. Power on the unit and enter to BT mode as previously
instructed. “bLUE” will appear on the Display.
3. Wait a few seconds until the unit is automatically paired
to the external BT Device. The unit will sound a prompt
voice.
4. After pairing is complete you may now play music with
your external BT Device.
Micro SD Card:
To play the music in Micro SD Card:
1. In power off mode, insert the Micro SD Card (not
included) into the Micro SD Card Slot on the top of
unit with contacts facing up as illustrated below:
2. Power on the unit and enter to Micro SD Card mode as
previously instructed:
● “Sd” will appear on the display.
● Indicator “SD” on the display will illuminate.
● Music in the card will be playback automatically.
4
3. During playback:
● Press the Button to pause, press again to resume
normal playback.
● Press and hold the or Buttons to skip tracks.
● Press and release the or Buttons repeatedly
to adjust volume level as desired.
4. When finished listening, press and hold the (Power
On-Off/Decorative Light On-Off ) Button to shut off the
unit.
USB:
To play the music in USB Device:
1. In power off mode, connect the USB Device into the USB
Port on the top of unit as illustrated below:
2. Power on the unit and enter to USB mode as previously
instructed:
● “USb” will appear on the display.
● Indicator “USB” on the display will illuminate.
● Music in the USB will be playback automatically.
3. During playback:
● Press the Button to pause, press again to resume
normal playback.
● Press and hold the or Buttons to skip tracks.
● Press and release the or Buttons repeatedly
to adjust volume level as desired.
4. When finished listening, press and hold the (Power
On-Off/Decorative Light On-Off ) Button to shut off the
unit.
Notes:
● Up to 16 GB Micro SD Card/USB Device the unit
supports to play.
● When inserting the Micro SD Card/USB Device, make
sure the direction you selected is correct. Never insert
violently to avoid damaging the Micro SD Card/USB
Device or the unit. If it doesn’t work, please check if the
direction is correct.
● Before replacing Micro SD Card/USB Device, make sure
the unit has been powered off.
● You also need to download the desired music in MP3
format into the Micro SD Card/USB Device before insert
into the unit.
AUX/LINE IN:
To listen from an external Audio Player such as MP3
Player, Discman…etc.
1. In power off mode, connect the Round Plug from
supplied Connection Cable to the AUX Out/Line
Out/Phone Jack on the external Audio Player.
2. Connect the Micro USB Plug from the supplied
Connection Cable to the 5V/AUX (In) Port on the top of
unit as illustrated below:
3. Power on the unit and enter to AUX/LINE IN mode as
previously instructed. “LlnE” will appear on the Display.
4. Play the music on the connected Player as usual. (Make
sure the volume level of the connected Audio Player is
turned to high level.)
5. During playback:
● Press the Button to mute, press again to turn the
sound back.
● Press and release the or Buttons repeatedly
to adjust volume level as desired.
6. When finished listening, press and hold the (Power
On-Off/Decorative Light On-Off ) Button to shut off the
unit.
Detachable Shoulder Strap:
Buckle up 2 sides of the strap to the hole on the unit , then
you can put the strap on your shoulder.
To AUX Out/Line Out/
Phone Jack on the
external Audio Player
To 5V/AUX Jack
Press and hold the (Power
On-Off/Decorative Light On-Off )
Button until the LED Display
illuminate to power on the unit.
The unit in power off
mode
Rise the volume level of the
paired BT device
Volume level of paired/
connected device is in
low level
Volume level too high
Reduce the volume level by press
and release the Button
repeatedly
Volume level of the
paired/connected
device too high
Reduce the volume level of the
paired/connected device
BT not
functioning
The external BT device
had NOT paired to the
unit
Pair the external BT device to the
unit as page 3-4
The external BT device
too far from the unit
Place the external BT device
close to the unit
5 6 7
Craig Electronics warrants this product to be free from
manufacturing defects in material and workmanship
under normal use for a period of 180 days from date of
purchase. If service is required, please return the product
to the store where it was purchased for exchange; or,
pack the unit in the original packing material with all
accessories if applicable, a copy of your sales receipt and
a Cashier’s check or Money Order for $12 (to cover
shipping and handling costs) payable to Craig Electronics
Inc. For consumers in Canada, please make sure that the
cashier check or money order is redeemable through a
U.S. bank. Ship your product freight pre-paid. Your unit
will be repaired, replaced or if the unit cannot be repaired
or replaced, a refund will be forwarded to you within four
weeks of receipt of your unit. Please ship your unit to:
Craig Electronics Inc.
1160 NW 163 Drive
Miami, Fl 33169
This warranty is void if the product has been: a) Used in a
commercial application or rental. b) Damaged through
misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d)
Damaged because it is improperly connected to any other
equipment.
Note: This warranty does not cover: a) Ordinary
adjustments as outlined in the Owner’s Manual which can
be performed by the customer. b) Damage to equipment
not properly connected to the product. c) Any cost
incurred in shipping the product for repair. d) Damage to
the product not used in the USA.
This warranty is not transferable and only applies to the
original purchase. Any implied warranties, including the
warranty of merchantability, are limited in duration to the
period of this expressed warranty and no warranty
whether expressed or implied shall apply to the product
thereafter.
Under no circumstance shall Craig be liable for any loss or
consequential damage arising out of the use of this
product. This warranty gives specific legal rights.
However, you may have other rights which may vary from
state to state. Some states do not allow limitations on
implied warranties or exclusion of consequential damage.
Therefore, these restrictions may not apply to you.
This product has been manufactured by and is sold under
the responsibility of Craig Electronics Inc, and Craig
Electronics Inc is the warrantor in relation to this product.
MAGNAVOX and SMART. VERY SMART are registered
trademarks of Koninklijke Philips N.V. and are used under
license from Koninklijke Philips N.V.
To Obtain Service on your Product
email:service@craigelectronics.com
Printed in China MMA3685_WC_E0FK1_B0US
LIMITED WARRANTY
2 1
5V AUX
5V AU X
5V AU X
5V A UX

Product specificaties

Merk: Magnavox
Categorie: Speaker
Model: MMA3685

Heb je hulp nodig?

Als je hulp nodig hebt met Magnavox MMA3685 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden


Handleiding Speaker Magnavox

Magnavox

Magnavox MD6924 Handleiding

7 Januari 2025
Magnavox

Magnavox MD6920 Handleiding

7 Januari 2025
Magnavox

Magnavox MSH315V Handleiding

7 Januari 2025
Magnavox

Magnavox MSH317 Handleiding

7 Januari 2025
Magnavox

Magnavox MMA3626 Handleiding

7 Januari 2025
Magnavox

Magnavox MD6972 Handleiding

7 Januari 2025
Magnavox

Magnavox MD6923 Handleiding

7 Januari 2025
Magnavox

Magnavox MMA3628 Handleiding

7 Januari 2025
Magnavox

Magnavox MHT833 Handleiding

7 Januari 2025
Magnavox

Magnavox MHT913R Handleiding

7 Januari 2025

Handleiding Speaker

Nieuwste handleidingen voor Speaker

Electro-Voice

Electro-Voice Sx600 Handleiding

8 Januari 2025
Electro-Voice

Electro-Voice XLE191-FG Handleiding

8 Januari 2025
Sonance

Sonance MAG6R Handleiding

8 Januari 2025
Sonance

Sonance MAG5.1R Handleiding

8 Januari 2025
Duronic

Duronic BX48 Handleiding

8 Januari 2025
Sonance

Sonance Visual Performance VP38R Handleiding

8 Januari 2025
Sonance

Sonance Visual Performance Extreme VPXT8R Handleiding

8 Januari 2025
Definitive Technology

Definitive Technology Dymension LS-80 Handleiding

7 Januari 2025
Definitive Technology

Definitive Technology Dymension Outdoor LS- Handleiding

7 Januari 2025
Definitive Technology

Definitive Technology Dymension LS-400 Handleiding

7 Januari 2025
