SIZE: 70x158mm

FCC NOTICE:

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interfer-

ence to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more

of the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the equipment and

receiver.

● Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV

technician for help.

FCC STATEMENT

1. This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received,

including interference that may cause undesired

operation.

2. Changes or modifications not expressly approved by the

party responsible for compliance could void the user's

authority to operate the equipment.

FCC WARNING:

To assure continued operation, follow the attached

installation instructions and use only shield cables when

connecting to other devices. Changes or modifications not

expressly approved by the party responsible for

compliance could void the user's authority to operate the

equipment.

POSSIBLE SOLUTION

Recharge the battery as page2

Turn the Power On-Off/Volume

Control Knob clockwise until “Click”

sound was heard to power on the

unit. The Blue Indicator on the front

of unit will illuminate

Increase the volume level by turn

the Power On-Off/Volume Control

Knob clockwise

Rise the volume level of the

paired/connected device

Reduce the volume level by turn the

Power On-Off/Volume Control Knob

counterclockwise

Reduce the volume level of the

paired/connected device

Pair the external BT device to the

unit as page 3-4

Place the external BT device close

to the unit

Reassemble the other direction/

location to improve reception.

Search and store the available FM

station into the unit and play the

desired stored FM station as page 6

POSSIBLE CAUSE

Built-in battery drained

The unit in power off

mode

Volume of the unit was

set to minimum

position

Volume level of

paired/connected

device is in low level

Volume level too high

Volume level of the

paired/connected

device too high

The external BT device

had NOT paired to the

unit

The external BT device

too far from the unit

The location not good

for radio reception

The available FM

stations had not stored

into the unit

SYMPTOM

Can’t power on

No sound or

sound weak

Sound

distortion

BT not

functioning

Radio reception

not good

No radio station

received

damage battery. Battery life will be extended if you keep

the battery fully charged.

Battery life naturally shortens slowly over time.

E. The rechargeable battery incorporated in this product is

not user replaceable.

OPERATION:

General Operation:

1. Recharge the built-in Li-ion battery as previously

instructed.

2. Turn the Power On-Off/Volume Control Knob clockwise

to power on the unit and set the volume level as desired.

The Blue Power On Indicator on the front of unit will

illuminate.

3. Press the MODE Button repeatedly to switch to desired

playback mode. The unit will display and sound the

prompt with your selection (see list below):

Note:

If the TF (Micro SD) Card; USB Device and/or Line In

Plug had NOT inserted/installed into the unit, the

corresponding selection will not available.

4. During playback, turn the Power On-Off/Volume Control

Knob to adjust volume level as desired.

5. Press the Light (On/Off) Button to turn off the Decorative

LED Lights; press again to turn it back.

6. When finished listening, turn the Power On-Off/Volume

Control Knob counterclockwise until “Click” sound was

heard to shut off the unit. The Blue Indicator on the front

of unit will not light.

BT Mode:

BT (Bluetooth) pairing:

First time use or re-pairing the unit to a new BT Device,

pairas follows:

1. Power on the unit and enter to BT mode as previously

instructed. The Blue BT Indicator on front of the unit will

illuminate and blink. (“bLUE” will appear on the Display

and you will hear an audible prompt say “Bluetooth ready

for connection”.)

2. Power on the external BT Device and enter to BT

searching mode. Start pairing following the on screen

instructions from the external BT Device. When paired,

the unit will sound a prompt “Bluetooth connected” and

the Blue BT Indicator will stop blinking.

3. If pairing is complete you may now play music with your

external BT Device.

4. During playback:

● Turn the Power On-Off/Volume Control Knob to adjust

volume level as desired.

● Press the Button on the unit to pause, press again to

resume normal playback.

● Press and release the or Buttons repeatedly to

skip tracks.

5. When finished listening, turn the Power On-Off/Volume

Control Knob counterclockwise until “Click” sound was

heard to shut off the unit. The Blue Indicator on the front

of unit will not light.

Notes:

● When the external BT Device searched the unit, our

model number “MMA3683n” will appear on the display of

external BT Device.

● If while pairing you are asked for a code please try "0000"

or "1234".

Normal operation after pairing:

1. Power on the external BT Device and enter to BT

playback mode.

2. Power on the unit and enter to BT mode as previously

instructed. The Blue BT Indicator on the front of unit will

illuminate and blink. (You will also hear an audible prompt

say “Bluetooth ready for connection”.)

3. Wait a few seconds until the unit is automatically paired to

the external BT Device. The unit will sound a prompt

“Bluetooth connected” and the Blue BT Indicator will stop

blinking.

4. After pairing is complete you may now play music with

your external BT Device.

TF Micro SD Card:( )

To play the music in TF (Micro SD) Card:

1. In power off mode, insert the TF (Micro SD) Card (not

included) into the TF (Micro SD) Card Slot on the top of

unit with contacts facing to front as illustrated below:

on the Display and the current track will be playback

repeatedly until the unit was shut off.

● Press the REP (Repeat) Button twice on the front of

unit to activate repeat all function. “ALL” will appear

on the Display and the all the tracks in the USD

Device will be playback repeatedly until the unit was

shut off.

4. When finished listening, turn the Power On-Off/Volume

Control Knob counterclockwise until “Click” sound was

heard to shut off the unit. The Blue Indicator on the front

of unit will not light.

Notes:

● Up to 16 GB TF (Micro SD) Card/USB Device the unit

supports to play.

● When inserting the TF (Micro SD) Card/USB Device,

make sure the direction you selected is correct. Never

insert violently to avoid damaging the TF (Micro SD)

Card/USB Device or the unit. If it doesn’t work, please

check if the direction is correct.

● Before replacing TF (Micro SD) Card/USB Device, make

sure the unit has been powered off.

● You also need to download the desired music in MP3

format into the TF (Micro SD) Card/USB Device before

insert into the unit.

FM Radio:

1. Power on the unit and enter to radio mode as previously

instructed. “FM” Indicator on the Display will illuminate

and the unit will sound a prompt “Radio".

2. In first time use (or removed the unit to a new location),

search and store the available FM stations by press the

Button once. The unit will automatically to search and

store all available FM radio stations then play the first

stored FM station.

3. After settings, press the or Buttons repeatedly to

select and plays the desired stored radio station.

4. During playback, turn the Power On-Off/Volume Control

Knob to adjust volume level as desired.

5. When finished listening, turn the Power On-Off/Volume

Control Knob counterclockwise until “Click” sound was

heard to shut off the unit. The Blue Indicator on the front

of unit will not light.

Antennas:

This unit has a built-in FM antenna, which provides

adequate reception in most areas. If reception is weak,

reassemble the other direction/location to improve

reception.

LINE IN:

To listen from an external Audio Player such as MP3 Player,

Discman…etc.

1. In power off mode, connect one end of the supplied

Audio Connection Cable to the AUX Out / Line Out /

Phone Jack on the external Audio Player.

2. Connect the other end of the cable to the LINE IN Jack

on the top of unit as illustrated below:

To AUX Out/Line Out/

Phone Jack on the

external Audio Player

To LINE IN Jack

3. Power on the unit and enter to LINE IN mode as

previously instructed. “LlnE” will appear on the Display

and you will hear an audible prompt say “Line in”.

4. Play the music on the connected Player as usual.

(Make sure the volume level of the connected Audio

Player is turned to high level.)

5. During playback:

● Turn the Power On-Off/Volume Control Knob to adjust

volume level as desired.

● Press the Button on the unit to mute, press again

to turn the sound back.

6. When finished listening, turn the Power On-Off/Volume

Control Knob counterclockwise until “Click” sound was

heard to shut off the unit. The Blue Indicator on the front

of unit will not light.

Microphone:

To sing with the playing music:

1. Power on the unit and plays music in any modes as

instructed earlier.

2. Connect the plug from the Microphone (Not included) to

the MIC (Microphone) Jack on the top of unit.

3. Turn the Power On-Off/ Volume Control Knob to adjust

the sound level.

Note:

If feedback noise (high audio frequency noise) is hearing

from the speakers, turn the Power On-Off/ Volume Control

Knob counterclockwise to reduce the volume level or

moving the Microphone away from the speakers.

TROUBLESHOOTING:

Check the following before requesting service:

SPECIFICATIONS:

PACKAGE INCLUDES:

1 x Owner’s Manual

1 x USB Connection Cable (For Charging only)

1 x Audio Connection Cable with 3.5 mm plugs

SPECIFICATIONS AND ACCESSORIES ARE SUBJECT

TO CHANGE WITHOUT NOTICE

LOCATION OF CONTROLS::

1. MIC (Microphone Input) Jack

2. USB Port

3. DC 5V Jack (Micro USB Port,

for charging only)

4. LINE IN Jack

5. TF (Micro SD) Card Slot

6. LED Display

7. MODE Button

8. REP ( Repeat ) Button

9. Light (On/Off) Button

10. Power On-Off/Volume

Control Knob

11. Buttton

12.

Button

13. Button

14. Red Charge Indicator

15. Blue Power On Indicator

16. Blue BT (Bluetooth) Indicator

17. Decorative LED Lights

POWER SOURCE:

The unit has a built-in Li-ion rechargeable battery, charge it

before first time use or when it is drained as follows:

1. Connect the small plug from the supplied USB Connection

Cable to the DC 5V Jack (Micro USB Port) on the top of unit.

2. Connect the full size USB Plug from the supplied USB

Connection Cable to the USB Port on the Personal

Computer or USB Charger (Computer and USB Charger

not included).

3. When charging, the Red Charge Indicator on the top of

unit will illuminate. When charging is complete, it will turn

off.

To Computer or any

USB Charger

To DC 5V Jack (Micro USB Port)

Notes:

Your battery will last longer if you following these simple

guidelines for caring and storing:

Before first time use, recharge the unit approximately 4

hours until the unit is fully charged.

Charge and store the unit within the temperature range of

5°C~35° (40°F~95°F).

Do not overcharge (longer than 24 hours). Excessive

charging or running the unit until battery fully drains will

Showing on Display: Voice Prompt:Playback Modes:

bLUE

“SD” Indicator on the

Display will illuminate

“USB” Indicator on the

Display will illuminate

“FM” Indicator on the

Display will illuminate

LlnE

BT (Bluetooth)

TF (Micro SD) Card

USB

FM Radio

Line In (AUX In)

Bluetooth ready

for connection

Memory Card

USB

Radio

Line in

Built-in DC 3.7V, 1200 mAH (4.44WH) rechargeable

Li-ion battery; Recharge by DC 5V through DC 5V

Jack (Micro USB Port)

5 W; 3 Ω

3 W (RMS)

87.5 - 108 MHz

4.1

≧ 32 Feet in open area

Power Source

Impedance of Speakers

Audio Power

FM Radio Frequency:

BT Version

BT Operation Distance

2. Power on the unit and enter to TF (Micro SD) Card

mode as previously instructed. “SD” Indicator on the

Display will illuminate and the unit will sound a prompt

“Memory Card" then automatically play the music stored

in the card.

3. During playback:

● Turn the Power On-Off/Volume Control Knob to adjust

volume level as desired.

● Press the Button on the unit to pause, “ ” will

appear on the Display. Press again to resume normal

playback, “ ” on Display will disappear.

● Press and release the or Buttons repeatedly to

skip tracks.

● Press the REP (Repeat) Button once on the front of

unit to activate repeat one function. “ONE” will appear

on the Display and the current track will be playback

repeatedly until the unit was shut off.

● Press the REP (Repeat) Button twice on the front of

unit to activate repeat all function. “ALL” will appear

on the Display and the all the tracks in the card will

be playback repeatedly until the unit was shut off.

4. When finished listening, turn the Power On-Off/Volume

Control Knob counterclockwise until “Click” sound was

heard to shut off the unit. The Blue Indicator on the front

of unit will not light.

USB:

To play the music in USB Device:

1. In power off mode, connect the USB Device into the

USB Port on the top of unit as illustrated below:

2. Power on the unit and enter to USB mode as previously

instructed. “USB” Indicator on the Display will illuminate

and the unit will sound a prompt “USB" then automati-

cally play the music stored on the USB Device.

3. During playback:

● Turn the Power On-Off/Volume Control Knob to adjust

volume level as desired.

● Press the Button on the unit to pause, “ ” will

appear on the Display. Press again to resume normal

playback, “ ” on Display will disappear.

● Press and release the or Buttons repeatedly to

skip tracks.

● Press the REP (Repeat) Button once on the front of

unit to activate repeat one function. “ONE” will appear

Craig Electronics warrants this product to be free from

manufacturing defects in material and workmanship under

normal use for a period of 180 days from date of purchase. If

service is required, please return the product to the store

where it was purchased for exchange; or, pack the unit in the

original packing material with all accessories if applicable, a

copy of your sales receipt and a Cashier’s check or Money

Order for $10 (to cover shipping and handling costs) payable

to Craig Electronics Inc. For consumers in Canada, please

make sure that the cashier check or money order is

redeemable through a U.S. bank. Ship your product freight

pre-paid. Your unit will be repaired, replaced or if the unit

cannot be repaired or replaced, a refund will be forwarded to

you within four weeks of receipt of your unit. Please ship your

unit to:

Craig Electronics Inc.

1160 NW 163 Drive

Miami, Fl 33169

This warranty is void if the product has been: a) Used in a

commercial application or rental. b) Damaged through

misuse, negligence, or abuse. c) Modified or repaired by

anyone other than an authorized Craig service center. d)

Damaged because it is improperly connected to any other

equipment.

Note: This warranty does not cover: a) Ordinary adjustments

as outlined in the Owner’s Manual which can be performed

by the customer. b) Damage to equipment not properly

connected to the product. c) Any cost incurred in shipping the

product for repair. d) Damage to the product not used in the

USA.

This warranty is not transferable and only applies to the

original purchase. Any implied warranties, including the

warranty of merchantability, are limited in duration to the

period of this expressed warranty and no warranty whether

expressed or implied shall apply to the product thereafter.

Under no circumstance shall Craig be liable for any loss or

consequential damage arising out of the use of this product.

This warranty gives specific legal rights. However, you may

have other rights which may vary from state to state. Some

states do not allow limitations on implied warranties or

exclusion of consequential damage. Therefore, these

restrictions may not apply to you.

This product has been manufactured by and is sold under

the responsibility of Craig Electronics Inc, and Craig

Electronics Inc is the warrantor in relation to this product.

MAGNAVOX and SMART. VERY SMART are registered

trademarks of Koninklijke Philips N.V. and are used under

license from Koninklijke Philips N.V.

To Obtain Service on your Product

email:service@craigelectronics.com

Printed in China MMA3683n_WC_E0FK1_B0US

LIMITED WARRANTY

Product specificaties

Merk:	Magnavox
Categorie:	Speaker
Model:	MMA3683n

Heb je hulp nodig?

Als je hulp nodig hebt met Magnavox MMA3683n stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Speaker Magnavox

Magnavox MD6924 Handleiding

7 Januari 2025

Magnavox MD6920 Handleiding

7 Januari 2025

Magnavox MSH315V Handleiding

7 Januari 2025

Magnavox MSH317 Handleiding

7 Januari 2025

Magnavox MMA3626 Handleiding

7 Januari 2025

Magnavox MD6972 Handleiding

7 Januari 2025

Magnavox MD6923 Handleiding

7 Januari 2025

Magnavox MMA3628 Handleiding

7 Januari 2025

Magnavox MHT833 Handleiding

7 Januari 2025

Magnavox MHT913R Handleiding

7 Januari 2025

Handleiding Speaker

Nieuwste handleidingen voor Speaker

Electro-Voice Sx600 Handleiding

8 Januari 2025

Electro-Voice XLE191-FG Handleiding

8 Januari 2025

Sonance MAG6R Handleiding

8 Januari 2025

Sonance MAG5.1R Handleiding

8 Januari 2025

Duronic BX48 Handleiding

8 Januari 2025

Sonance Visual Performance VP38R Handleiding

8 Januari 2025

Sonance Visual Performance Extreme VPXT8R Handleiding

8 Januari 2025

Definitive Technology Dymension LS-80 Handleiding

7 Januari 2025

Definitive Technology Dymension Outdoor LS- Handleiding

7 Januari 2025

Definitive Technology Dymension LS-400 Handleiding

7 Januari 2025
