BT (Bluetooth) pairing:
First time use or re-pairing the unit to a new BT Device, pair
as follows:
1. Power on the unit and enter to BT mode as previously
instructed. “bLUE” will appear on the display and indicator
“BT” on the display will illuminate and blink.
2. Power on the external BT Device and enter to BT
search mode. Start pairing following the on screen
instructions from the external BT Device. When paired,
the indicator BT on the display will stop blinking.
3. If pairing is complete you may now play music with your
external BT Device.
4. During playback:
● Turn the Power On-Off/Volume Control Knob to adjust
volume level as desired.
● Press the Button on the unit to pause, press again to
resume normal playback.
● Press and release the or Buttons repeatedly to
skip tracks.
5. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound is heard
to shut off the unit.The blue lights inside the knob will not
illuminate.
2. Power on the unit and enter to TF (Micro SD) Card
mode as previously instructed:
● “Sd” will appear on the display.
● Indicator “SD” on the display will illuminate.
● Music in the TF (Micro SD) Card will start playback
automatically.
3. During playback:
● Turn the Power On-Off/Volume Control Knob to adjust
volume level as desired.
● Press the Button on the unit to pause, press again
to resume normal playback.
● Press the or Buttons repeatedly to skip tracks.
4. Repeat playback, during playback:
● Press the REP/ Button once on the front of unit to
activate repeat all function. “ALL” will appear on the
display and the all the tracks on the USB Device will
be playback repeatedly until the unit was shut off.
● Press the REP/ Button twice to activate repeat one
function. “ONE” will appear on the display then the
current track will be playback repeatedly until the unit
was shut off.
● Press the REP/ Button three times. “NOr” will
appear on the display then the repeat function will be
cancelled.
5. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound is
heard to shut off the unit. The blue lights inside the knob
will not illuminate.
Notes:
● Up to 16 GB TF (Micro SD) Card/USB Device supported.
● When inserting the TF (Micro SD) Card/USB Device,
make sure the direction you selected is correct. Never
insert violently to avoid damaging the TF (Micro SD)
Card/USB Device or the unit. If it doesn’t work, please
check if the direction is correct.
● Before replacing TF (Micro SD) Card/USB Device, make
sure the unit has been powered off.
● You also need to download the desired music in MP3
format into the TF (Micro SD) Card/USB Device before
insert into the unit.
LOCATION OF CONTROLS::
1. LED Display
2. Power On-Off/Volume
Control Knob
3. Buttton
4. Button
5. Button
6. MODE Button
7. REP/ (Repeat/Decorative
LED Lights On-Off) Button
8. EQ (Equalizer) Button
9. MIC (Microphone Input) Jack
10. DC 5V (Micro USB) Port
(For charging only)
11. TF (Micro SD) Card Slot
12. USB Port
13. Red Charge Indicator
14. LINE IN (AUX IN) Jack
POWER SOURCE:
The unit has a built-in Li-ion rechargeable battery, charge it
before first time use or when it is drained as follows:
1. Connect the small plug from the supplied USB Connection
Cable to the DC 5V (Micro USB) Port on the front of unit.
2. Connect the full size USB Plug from the supplied USB
Connection Cable to the USB Port on the Personal
Computer or USB Charger (Computer and USB Charger
not included).
3. When charging, the Red Charging Indicator on the front of
unit will illuminate. When charging is complete, it will turn
off.
4. When charging, you can also play and listening music at
the same time.
Notes:
Your battery will last longer if you’re following these simple
guidelines for caring and storing:
A.
Before first time use, recharge the unit approximately 5
hours until the unit is fully charged.
B.
Charge and store the unit within the temperature range of
5°C~35° (40°F~95°F).
C.
Do not overcharge (longer than 24 hours). Excessive
charging or running the unit until battery fully drains will
2
FCC NOTICE:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and
receiver.
● Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV
technician for help.
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
FCC WARNING:
To assure continued operation, follow the attached
installation instructions and use only shield cables when
connecting to other devices. Changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate the
equipment.
1
Can’t power on
No sound or
sound weak
Sound
distortion
BT not
functioning
damage battery. Battery life will be extended if you keep
the battery fully charged.
D.
Battery life naturally shortens slowly over time.
E. The rechargeable battery incorporated in this product is
not user replaceable.
OPERATION:
General Operation:
1. Recharge the built-in Li-ion battery as previously
instructed.
2. Turn the Power On-Off/Volume Control Knob clockwise
to power on the unit and set the volume level as desired.
The Blue LED lights inside the knob will illuminate.
3. Press the MODE Button repeatedly to switch to desired
playback mode. The unit will display with your selection
(see list below):
Note:
If the TF (Micro SD) Card or USB Device had NOT
been inserted into the unit, the correspondence
selection will not available.
4. During playback:
Turn the Power On-Off/Volume Control Knob to adjust ●
volume level as desired.
● Press the EQ (Equalizer) Button repeatedly to activate
and set the sound effect mode as desired as below:
Note: EQ is not available in Line In Mode.
5. Press and hold the REP/ Button to turn off the
Decorative LED Lights; press and hold again to turn it on.
6. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound is
heard to shut off the unit. The blue lights inside the knob
will not illuminate.
BT Mode ：
6. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound is
heard to shut off the unit. The blue lights inside the knob
will not illuminate.
USB:
To play the music in USB Device:
1. In power off mode, connect the USB Device (not
included) into the USB Port on the front of unit as
illustrated below:
2. Power on the unit and enter to USB mode as previously
instructed:
● “USb” will appear on the display.
● Indicator “USB” on the display will illuminate.
● Music in the USB Device will start playback
automatically.
3. During playback:
● Turn the Power On-Off/Volume Control Knob to adjust
volume level as desired.
● Press the Button on the unit to pause, press again
to resume normal playback.
● Press the or buttons repeatedly to skip tracks.
4. Repeat playback, during playback:
● Press the REP/ Button once on the front of unit to
activate repeat all function. “ALL” will appear on the
display and all the tracks on the USB Device will be
playback repeatedly until the unit was shut off.
● Press the REP/ Button twice to activate repeat one
function. “ONE” will appear on the display then the
current track will be playback repeatedly until the unit
was shut off.
● Press the REP/ Button three times. “NOr” will
appear on the display then the repeat function will be
cancelled.
5. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound is
heard to shut off the unit. The blue lights inside the knob
will not illuminate.
TF (Micro SD) Card:
To play the music in TF (Micro SD) Card:
1. In power off mode, insert the TF (Micro SD) Card (not
included) into the TF (Micro SD) Card Slot on the front
of unit with contacts facing up as illustrated follows:
TROUBLESHOOTING:
Check the following before requesting service:
GENERAL SPECIFICATIONS:
PACKAGE INCLUDES:
1 x Owner’s Manual
1 x USB Connection Cable (For Charging only)
1 x Audio Connection Cable with 3.5 mm plugs
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT
TO CHANGE WITHOUT NOTICE
Built-in DC 3.7V, 1200mAh (4.44WH) rechargeable
Li-ion battery; Recharge by DC 5V through DC 5V
Jack (Micro USB Port)
8W; 3Ω
5W (RMS)
87.5 - 108MHz
4.1
≤ 32 Feet in open area
Power Source
Impedance of Speakers
Audio Power
FM Radio Frequency:
BT Version
BT Operation Distance
FM Radio:
1. Power on the unit and enter to radio mode as previously
instructed. Indicator “FM” on the display will illuminate
and radio frequency will appear on the display.
2. In first time use (or relocated the unit to a new location),
search and store the available FM stations by press the
Button. The unit will automatically to search and
store all available FM radio stations then play the 1st
stored FM station. Press the or buttons repeatedly
to select and plays the desired stored radio station.
3. During playback, turn the Power On-Off/Volume Control
Knob to adjust volume level as desired.
4. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound is
heard to shut off the unit. The blue lights inside the knob
will not illuminate.
Antennas:
This unit has a built-in FM antenna, which provides
adequate reception in most areas. If reception is weak,
reassemble the other direction/location to improve
reception.
LINE IN (AUX IN):
Listen from an external Audio Player such as MP3 Player,
Discman…etc.
1. In power off mode, connect one end of the supplied
Audio Connection Cable to the AUX Out/Line
Out/Phone Jack on the external Audio Player.
2. Connect the other end of the cable to the LINE IN (AUX
IN) Jack on the front of unit as illustrated below:
To AUX Out/Line Out/
Phone Jack on the
external Audio Player
To LINE IN Jack
3. Power on the unit and enter to LINE IN mode as
previously instructed. “Ll E” will appear on the display.
4. Play the music on the connected Audio Player as usual.
(Make sure the volume level of the connected Audio
Player is turned to high level.)
5. During playback:
● Turn the Power On-Off/Volume Control Knob to adjust
volume level as desired.
● Press the Button on the unit to mute, press again to
turn the sound back.
3 4 6
BT (Bluetooth)
Showing on Display:Playback Modes:
“bLUE” will appear on the display and indicator
“BT” on the display will illuminate and blink
Line In
USB
FM Radio
5
Built-in battery drained
The unit in power off
mode
Volume of the unit was
set to minimum position
Volume level of paired/
connected device is in
low level
Volume level too high
Volume level of the
paired/connected
device too high
The external BT device
had NOT paired to the
unit
The external BT device
too far from the unit
The location not good
for radio reception
The unit was moved in a
new location or the
available FM stations had
not stored into the unit
Recharge the battery as page 2
Turn the Power On-Off/Volume Control
Knob clockwise until “Click” sound was
heard to power on the unit. The Blue
LED lights inside the knob will illuminate
Increase the volume level by turn the
Power On-Off/Volume Control Knob
clockwise
Rise the volume level of the paired/
connected device
Reduce the volume level by turn the
Power On-Off/Volume Control Knob
counterclockwise
Reduce the volume level of the
paired/connected device
Pair the external BT device to the
unit as page 4
Place the external BT device close to
the unit
Reassemble the unit to other
direction/location to improve
reception
Press the Button to search and
store all the available FM stations
again
9
TF (Micro SD) Card
Indicator “FM” on the display will illuminate
and radio frequency will appear on the display
“LI E” will appear on the display
“USb” will appear on the display and indicator
“USB” on the display will illuminate; music in
the USB Device will start playback automatically
“Sd” will appear on the display and indicator
“SD” on the display will illuminate; music in
the card will start playback automatically
Display shows: Sound Effect:
POP
CLA
JAZ
CUt
rOC Rock
Pop music
Classic
Jazz
Country
NOr Normal
7
To Computer or any
USB Charger
No radio station
received
Radio reception
not good
To sing with playing music:
To sing while music is playing:
1. Power on the unit and plays music in any modes as
instructed earlier.
2. Connect the plug from the Microphone (not included)
into the MIC (Microphone Input) Jack on the front of
unit.
3. Turn the Power On-Off/Volume Control Knob to adjust
the sound level of microphone and music.
Note:
If feedback noise (high audio frequency noise) is hearing
from the speaker, turn the Power On-Off/Volume Control
Knob counterclockwise to reduce the microphone/music
level or moving the Microphone away from the speaker.
8
n
Notes:
● When the external BT Device searches for the unit, our
model number “MHT860” will appear on the display of
external BT Device.
● If while pairing you are asked for a code please try "0000"
or "1234".
Normal operation after pairing:
1. Power on the external BT Device and enter to BT
playback mode.
2. Power on the unit and enter to BT mode as previously
instructed. “bLUE” will appear on the display and indicator
“BT” on the display will illuminate and blink.
3. Wait a few seconds until the unit is automatically paired to
the external BT Device. The indicator BT on the display
will stop blinking.
4. After pairing is complete you may now play music with
your external BT Device.
n
To DC 5V
(Micro USB)
Port
SIZE: 70x158mm
Craig Electronics warrants this product to be free from
manufacturing defects in material and workmanship
under normal use for a period of 180 days from date of
purchase. If service is required, please return the product
to the store where it was purchased for exchange; or,
pack the unit in the original packing material with all
accessories if applicable, a copy of your sales receipt and
a Cashier’s check or Money Order for $12 (to cover
shipping and handling costs) payable to Craig Electronics
Inc. For consumers in Canada, please make sure that the
cashier check or money order is redeemable through a
U.S. bank. Ship your product freight pre-paid. Your unit
will be repaired, replaced or if the unit cannot be repaired
or replaced, a refund will be forwarded to you within four
weeks of receipt of your unit. Please ship your unit to:
Craig Electronics Inc.
1160 NW 163 Drive
Miami, Fl 33169
This warranty is void if the product has been: a) Used in a
commercial application or rental. b) Damaged through
misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d)
Damaged because it is improperly connected to any other
equipment.
Note: This warranty does not cover: a) Ordinary
adjustments as outlined in the Owner’s Manual which can
be performed by the customer. b) Damage to equipment
not properly connected to the product. c) Any cost
incurred in shipping the product for repair. d) Damage to
the product not used in the USA.
This warranty is not transferable and only applies to the
original purchase. Any implied warranties, including the
warranty of merchantability, are limited in duration to the
period of this expressed warranty and no warranty
whether expressed or implied shall apply to the product
thereafter.
Under no circumstance shall Craig be liable for any loss or
consequential damage arising out of the use of this
product. This warranty gives specific legal rights.
However, you may have other rights which may vary from
state to state. Some states do not allow limitations on
implied warranties or exclusion of consequential damage.
Therefore, these restrictions may not apply to you.
This product has been manufactured by and is sold under
the responsibility of Craig Electronics Inc, and Craig
Electronics Inc is the warrantor in relation to this product.
MAGNAVOX and SMART. VERY SMART are registered
trademarks of Koninklijke Philips N.V. and are used under
license from Koninklijke Philips N.V.
To Obtain Service on your Product
email:service@craigelectronics.com
Printed in China MHT860_WC_E0FK1_B0US
LIMITED WARRANTY
DC 5 V

Product specificaties

Merk: Magnavox
Categorie: Speaker
Model: MHT860

Heb je hulp nodig?

Als je hulp nodig hebt met Magnavox MHT860 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden


Handleiding Speaker Magnavox

Magnavox

Magnavox MD6924 Handleiding

7 Januari 2025
Magnavox

Magnavox MD6920 Handleiding

7 Januari 2025
Magnavox

Magnavox MSH315V Handleiding

7 Januari 2025
Magnavox

Magnavox MSH317 Handleiding

7 Januari 2025
Magnavox

Magnavox MMA3626 Handleiding

7 Januari 2025
Magnavox

Magnavox MD6972 Handleiding

7 Januari 2025
Magnavox

Magnavox MD6923 Handleiding

7 Januari 2025
Magnavox

Magnavox MMA3628 Handleiding

7 Januari 2025
Magnavox

Magnavox MHT833 Handleiding

7 Januari 2025
Magnavox

Magnavox MHT913R Handleiding

7 Januari 2025

Handleiding Speaker

Nieuwste handleidingen voor Speaker

Electro-Voice

Electro-Voice Sx600 Handleiding

8 Januari 2025
Electro-Voice

Electro-Voice XLE191-FG Handleiding

8 Januari 2025
Sonance

Sonance MAG6R Handleiding

8 Januari 2025
Sonance

Sonance MAG5.1R Handleiding

8 Januari 2025
Duronic

Duronic BX48 Handleiding

8 Januari 2025
Sonance

Sonance Visual Performance VP38R Handleiding

8 Januari 2025
Sonance

Sonance Visual Performance Extreme VPXT8R Handleiding

8 Januari 2025
Definitive Technology

Definitive Technology Dymension LS-80 Handleiding

7 Januari 2025
Definitive Technology

Definitive Technology Dymension Outdoor LS- Handleiding

7 Januari 2025
Definitive Technology

Definitive Technology Dymension LS-400 Handleiding

7 Januari 2025
