This Fan is for residential use only.

It is not intended to be used in commercial or industrial settings.

IMPORTANT INSTRUCTIONS - OPERATING MANUAL

1700 Meacham Boulevard

Fort Worth, Texas 76106

ASSEMBLY OF 12" and 16" OSCILLATING FANS

Rev. P 9/17

82084537

Rev. P 9/17

READ AND SAVE THESE INSTRUCTIONS

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE,

INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED.

PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY

INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD

RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE!

Have a Question? Need a Part?

Please Do Not Return Product to Store!

Contact Lasko Customer Service:

1-800-233-0268 Monday-Friday 8AM - 5PM EST.

NOTES

Manual printed in USA

Rev. P 9/17 2 2084537 Rev. P 9/17 72084537

SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

When using electrical appliances, basic precautions should always be followed to reduce

the risk of fire, electrical shock and injury to persons, including the following:

Read all instructions before using this Fan.

TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR PERSONAL INJURY, ALWAYS

FOLLOW THESE IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS:

DO NOT use this fan to ventilate areas where flammable liquids or vapors are used, stored or are present, including paints,

gasoline, varnishes, floor refinishing products or solvents. ALWAYS read and follow all warnings and instructions on the

containers for these products!

ALWAYS be sure the plug fits tightly into the outlet. When plugs fit loosely into outlets, they may slip partially out of the

outlet and create a poor connection. This may cause outlets to overheat and create a potential fire hazard. Outlets in this

condition should be replaced by a qualified electrician.

ALWAYS unplug the power cord when servicing, cleaning or moving the Fan. DO NOT use the ON/OFF switch as the sole

means of disconnecting power. NEVER leave children unattended when the Fan is on or plugged in. ALWAYS turn off and

unplug the Fan when not in use.

BE CERTAIN that the power source for the Fan is 120V AC. DO NOT plug the Fan into 240V or other power source.

The Blue Plug™ on your Lasko fan is a safety feature. It contains a non-replaceable safety device (fuse) that should not be

removed or tampered with. To reduce the risk of fire, electric shock and personal injury, attempt to remove, replace, DO NOT

repair or tamper with the originally supplied plug. If the Fan has stopped functioning, it may be due to the safety device

incorporated in this plug.

THIS FAN HAS A POLARIZED PLUG (one blade is wider than the other). This plug is designed to fit into the outlet only one

way. Match the wide blade to wide slot in outlet and FULLY INSERT. DO NOT attempt to bypass or defeat this safety fea-

ture. If the plug does not fit in the outlet, consult a qualified electrician. The outlet may need to be replaced.

• AVOID the use of extension cords, power strips, power taps, outlet style air fresheners or other cord connected device, as these

devices may overheat and cause a fire hazard.

•DO NOT route power cord under rugs, carpets, runners or furniture. This may damage the cord or cause it to overheat creating a fire hazard.

•ALWAYS place the Fan on a stable, flat, level surface while in operation to prevent the Fan from overturning.

• cur.NEVER insert or allow fingers or objects to enter grill openings while Fan is in operation or injury and/or damage to the Fan may oc

• block, cover or obstruct air flow to or from the fan while in operation.DO NOT

• use this Fan outdoors or near water or wet locations such as a bath tub, pool or hot tub. Use of this Fan in a wet location DO NOT

may create a shock hazard.

• run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord under furniture DO NOT

or appliances. Arrange cord away from traffic area and where it will not be tripped over.

• use a single extension cord to operate more than one Fan or other electrical device.NEVER

• use this Fan if it has been damaged or is not functioning properly. DO NOT

•Remote controls for other appliances or electronic equipment can sometimes interfere with the operation of this Fan. If this occurs,

move the Fan to another location.

•Keep Fan remote control unit away from chairs and your bed where it may be sat or laid upon and inadvertently turn on the Fan.

•THIS FAN DOES NOT MEET THE REQUIREMENTS OF NEC ARTICLE 547-7 (2008).This Fan is not suitable for use in agricultural

facilities including areas where livestock, poultry or other animals are confined. Please refer to National Electric Code (NEC) Article

547-7 (2008), or applicable state or local codes or standards relating to electrical requirements for agricultural buildings.

•THIS FAN DOES NOT MEET THE REQUIREMENTS OF NEC ARTICLE 500 (2008).This Fan is not suitable for use in hazardous loca-

tions. Please refer to National Electric Code (NEC) Article 500 or applicable state or local codes or standards relating to electrical

requirements for hazardous locations.

CAUTION

LASKO PRODUCTS, LLC LIMITED WARRANTY VALID IN THE USA, ITS TERRITORIES, AND CANADA ONLY) (

WHAT THIS WARRANTY COVERS: This product is warranted against defects in workmanship and/or materials.

HOW LONG THIS WARRANTY LASTS: This warranty extends only to the original purchaser of the product and lasts for

one (1) year from the date of original purchase or until the original purchaser of the product sells or transfers the product,

whichever first occurs.

WHAT LASKO WILL DO: Lasko will, at its sole option, repair or replace any part or parts that prove to be defective or

replace the whole product with the same or comparable model. For all warranty claims, the product must be returned

to Lasko Products, LLC at customer expense with proof of purchase within the warranty period. Contact the Lasko

customer service department to obtain a Return Authorization ("RA"). DO NOT return products without an RA or the

warranty claim will not be processed.

WHAT THIS WARRANTY DOES NOT COVER: This warranty does not apply if the product was damaged or failed

because of accident, improper handling or operation, shipping damage, abuse, misuse, unauthorized repairs made or

attempted. This warranty does not cover shipping costs for the return of products to Lasko for repair or replacement.

Lasko will pay return shipping charges from Lasko following warranty repairs or replacement.

ANY AND ALL WARRANTIES, EXPRESSED OR IMPLIED (INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY

OF MERCHANTABILITY), LAST ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE OR UNTIL THE ORIGINAL

PURCHASER OF THE PRODUCT SELLS OR TRANSFERS THE PRODUCT, WHICHEVER FIRST OCCURS AND IN NO

EVENT SHALL LASKO’S LIABILITY UNDER ANY EXPRESS OR IMPLIED WARRANTY INCLUDE (I) INCIDENTAL OR

CONSEQUENTIAL DAMAGES FROM ANY CAUSE WHATSOEVER, OR (II) REPLACMENT OR REPAIR OF ANY HOUSE

FUSES, CIRCUIT BREAKERS OR RECEPTACLES. NOTWITHSTANDING ANYTHING TO THE CONTRARY, IN NO

EVENT SHALL LASKO’S LIABILITY UNDER ANY EXPRESS OR IMPLIED WARRANTY EXCEED THE PURCHASE PRICE

OF THE PRODUCT AND ANY SUCH LIABILITY SHALL TERMINATE UPON THE EXPIRATION OF THE WARRANTY

PERIOD.

Some states and provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation

of incidental or consequential damages, so these exclusions or limitations may not apply to you. This warranty gives you

specific legal rights. You may also have other rights which vary from state to state and province to province.

Proof of purchase is required before a warranty claim will be accepted.

CUSTOMER SERVICE:

Toll-Free (800) 233-0268. Email: producthelp@laskoproducts.com

Our Customer Service team is available to assist you with product questions, service center locations, and replacement parts. They can be

reached Monday through Friday, 8am-5pm Eastern. Please have your model number available, as well as the type and style (located on the

underside of your product). Please do not return product to place of purchase.

Customer Service Dept., 820 Lincoln Ave., West Chester, PA 19380

(Please do not send product to this location) www.laskoproducts.com

SERVICING: All other servicing, with the exception of general user maintenance, should be performed by an authorized

service representative. Call 1-800-233-0268, Monday through Friday, between the hours of 8:00 a.m.and 5:00 p.m. EST for

the location of your nearest service center.

LUBRICATION: Motor is permanently lubricated.

STORAGE: Store the Fan with these instructions, in the original carton in a cool, dry place.

DISPOSITION: Corrugated packaging materials are recyclable. For environmentally responsible disposal of this product,

contact your local waste service provider or visit www.1800recycling.com®.

TROUBLE SHOOTING TIPS

If your Fan fails to operate, see below for a list of probable causes and solutions:

1. Be sure the power cord is plugged into a working electrical outlet.

MAINTENANCE

To reduce the risk of electrical shock and fire please observe the following instructions:

WARNING

- Always unplug the cord before moving, servicing or cleaning.

- place the Fan in or near water.NEVER

- Disassembled grills may be immersed to be cleaned with a mild detergent and water. Wipe all other parts with soft

cloth moistened with water and mild detergent only. DRY ALL PARTS COMPLETELY BEFORE REASSEMBLING.

After any maintenance or servicing, completely reassemble unit as described in this instruction manual before

reconnecting to the power supply.

- NEVER use ALCOHOL or SOLVENTS such as gasoline, benzene, paint thinner, or other harsh cleaners.

Rev. P 9/17 6 2084537 Rev. P 9/17 3 2084537

1. Tilt Fan Head Plastic Rear Grill back. Place on Motor.

(Figure 1)

2. Align tab of Plastic Rear Grill with groove on top of front

Motor cover. (Figure 2)

3. Fully seat Plastic Rear Grill Plastic Nut and secure with

turning . CLOCKWISE (Figure 3)

Figure 4A

Groove

4. Slide Blade Groove onto motor shaft. (Align (Figure 4) on

blade hub with on motor shaft. )Pin Figure 4A

Figure 4

Blade

Plastic Rear

Grill

Motor

Figure 2

Figure 1

Motor

Plastic Rear

Grill

Fan Head

Figure 3

Plastic Nut

Plastic Rear

Grill

ASSEMBLY

5. To secure , screw onto Shaft Blade Spinner

Counter Clockwise until tight on Blade hub.

(Figure 5)

Figure 5

Fan Spinner

6. Install Ornament into Metal Front Grill if not already at-

tached to the Grill. Insert Tabs Slots into rectanglar . Snap

into place. (Figure 6)

Slot

Figure 6

Ornament

Side View

Tab

7. With Fan Head tilted back and centered, align Ornament of

Front Grill Front Grill so it is horizontal. Insert bottom of

into Rear Grill. Tabs at the bottom of should be Rear Grill

between two wires of . Snap into the Front Grill Front Grill

Rear Grill beginning at the top and working down both

sides. (Figure 7)

Tab Tab

Snaps

Ornament

Figure 7

1 2011212 2011200M Rear Grill

2 2010361P 2010361P Plastic Nut (Large)

3 2010093 2010093 Spinner

4 2010380L N/A Ornament

5 02096217 02096222 Front Grill

6 2010008 2011013 Blade

7 2060090 2060090 Elevation Washer

8 02090585 02090585 Elevation Spring

9 2060071 2060071 Elevation Range Plate

10 02090033 02090033 Hex Nut

11 02090521 02090521 Elevation Shaft

12 02010110A 02010110A Small Adjustment Knob

13 02010109A 02010109A Large Adjustment Knob

14 2010533 2010533 Stand

15 2009224 2009224 Knob

16 02055087 02055087 Switch

17 2010415 2010415 Rubber Feet (4)

18 02065457 02065458 Stand Ornament

19 02090038 02090038 Screw #8 x 9/16 PPH Type 25

20 2010343 2010343 Bottom Plate (Plastic)

21 2060012 2060012 Bottom Plate (Metal)

22 2091145 2091145 Screw #8 x 1.5 Type A POH

23 7091854 7091854 Crimp Connect

24 02050104 02050104 Power Supply Cord w/Plug

25 2084537 2084537 Instruction Sheet (Not Shown)

26 02035057 02035058 Motor Head Assembly

KEY 12" OSC 16" OSC DESCRIPTION

21 20

REPLACEMENT PARTS LIST

* Parts described in the Replacement Parts List may not reflect the

exact part supplied with your product.

* The ornament may already be attached to the grill.

* Parts 2-4 ordered as a Bagged Assembly

Product specificaties

Merk:	Lasko
Categorie:	Ventilator
Model:	3150G
