Table of Contents
Welcome to Club GTi ............................................3
About this Manual .................................................3
Autosound at its Best ............................................3
Designing Your System .........................................5
Coupled ComponentTM Placement.........................5
Installation Warnings and Tips ..............................6
Mounting Instructions ............................................6
Installing the GTi System Crossover .....................6
Woofer/Midrange Driver Mounting ........................7
Mounting Speakers in Custom Locations..............8
Wiring ..................................................................10
System Connections ...........................................10
Crossover Tweeter Level Adjustment..................12
Speaker Break-In ................................................12
A Note on Power Handling ..................................12
In Case of Diculty .............................................13
Specications ......................................................14
Thiele-Small Specications .................................15
2
Welcome to Club GTi
Thank you for purchasing the nest
Automotive Coupled ComponentTM
Systems JBL has ever produced. As a
GTi Competition Series owner, you are a
member of a select group of people who
enjoy the most advanced mobile audio
products available. We call this group
“Club GTi.” By sending in the customer
information card, which you will nd
attached to your warranty, we will
automatically register you as a Club GTi
member which will give you access to
exclusive Club GTi apparel and other
special oers we will make available from
time to time. We suggest you ll the card
out at your earliest convenience.
Also, be sure to save your sales
receipt in a safe place. It will be necessary
to use this document as proof of purchase
in the event that you ever need warranty
service. It is also useful for insurance
purposes and for establishing value when
you re-sell your vehicle.
About This Manual
Because of the performance capability
of your GTi Competition Series product,
and the variety of potential system
congurations, we strongly recommend
that you have the system professionally
installed. You will also get a better warranty
if your equipment is professionally installed
by an authorized GTi dealer and you have
your warranty card stamped. This manual
provides information on installation and
usage to help a skilled technician get the
most from your GTi Competition Series
product. This manual does not cover basic
information about installation which is
common knowledge to a professional
installer, except for information which is
unique to the 404 and 504GTi systems.
If you feel you possess the necessary
skills, and prefer to install the equipment
yourself, this manual will provide you with
the necessary specics to properly use the
404 or 504GTi in typical installations.
Consult your JBL dealer, or a qualied
technician, for more information.
Autosound at its Best
The 404 and 504GTi Coupled
ComponentsTM are built to meet the same
rigorous standards of construction and
performance that have long established
JBL’s renowned home and professional
speaker systems. Coupled Components
TM
are the rst to provide true component
driver quality in a format which mounts
in a single hole. The GTi Coupled
ComponentsTM combine the reference
standard 400 and 500GTi Woofer/Midrange
Drivers with a cantilever mounted 20mm
Pure Titanium tweeter and outboard
2-way crossover. The tweeter is mounted
at a 15° angle which, combined with the
exclusive IntermountTM mounting system,
allows orientation of the speaker for
optimum imaging in any vehicle. The
near-coincident mounting provides the
considerable advantages of equal sound-
path length from the woofer and tweeter to
your ear, but without the horn loading
eects that create a distorted midrange in
designs with apex-mounted tweeters.
3
