Pagina 1/4
SPECIFICATION:
MODEL NO. : - DD 585
RATED VOLTAGE : Va.c. 60Hz 230
POWER CONSUMPTION : 0 Watts 30
BOX DIMENSION : * *445mm 550 440
UNIT DIMENSION : * *378mm 480 375
GROSS WEIGHT : 5.5kg
NET WEIGHT : 4.1kg
INSIDE TEMPERATURE : 70±10°C
IMPORTANT SAFEGUARDS:
1. Read all instructions carefully.
2. Before using the unit, check if the voltage indicated in this unit corresponds with the convenience outlet
(230Va.c.).
3. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should be replaced
with the same type and size or bring the unit to the nearest Imarî‹Šex Authorized Service Center.
4. Keep curtains, furniture, î‹Šammable materials, etc. away from the unit and from the convenience outlet.
5. ildren should be supervised to ensure that they do not play with the appliance. Ch
6. This appliance is not intended to be used by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning the use of the appliance by a person responsible for their safety.
7. Do not block the steam vent.
8. Do not put anything on top of the Dish Dryer.
9. Do not use the Dish Dryer other than its intended use.
10. To protect against electric shock or short circuit, do not immerse power cord, plug or the unit in water.
11. Do not exceed the maximum plate diameter size ( cm/11 ) as it may cause damage to the unit. 29 .5in
12. Maintenance other than cleaning should be performed by a qualied technician from an Imarex
Authorized Service Center.
13. For household use only; not intended for any business purposes.
14. Save this instruction manual for future reference.
DESCRIPTION OF PARTS:
CONTROL PANEL:
PARAMETER TABLE:
FUNCTION
TOTAL TIME
(mins.)
HEAT
(mins.)
AIR CIRCULATION
(mins.)
60 mins.
55 mins.
5 mins.
50 mins.
45 mins.
5 mins.
40 mins.
35 mins.
5 mins.
10 mins.
-
10 mins.
HOW TO ASSEMBLE:
1. For rst time use, remove all packaging materials before use.
2. Make sure to cut all cable ties and remove the plastic sticker located in front of the large storage
box of the unit body (on the top of the microswitch).
*Note: Failure to remove the plastic sticker, the unit will not work.
3. Place the storage boxes accordingly. Refer to the photo
below.
*NOTE: Make sure to properly clip the storage boxes into the
Dish Rack.
4. Insert the Dripping Tray on the bottom of the unit. (Located
below the Power/Function button).
HOW TO USE:
1. Assemble the unit properly. Please refer to (HOW TO ASSEMBLE).
2. Place the unit on a at surface. The unit needs at least 10cm clearance space on all sides and
at least 30 cm above. This is to allow adequate air circulation. Never place the unit near the
stove.
3. Plug the unit into the convenience outlet. A beep sound will be heard.
4. Put the clean dinnerware, silverware, etc. inside the dish dryer. Then pull down the cover. *Note:
Maximum plate diameter is 29cm / 11.5in only. Do not exceed the maximum plate diameter size
( cm/11.5in) as it may cause damage to the unit Do not place any plastic ware that is not heat 29
resistant.
5. Press button to turn ON the unit and indicator light will be ashing.
6. Press button to select the desired function.
- Press button for function. The default time is 60 minutes and it cannot be adjusted. once
It is 55 minutes Heat and 5 minutes Air Circulation.
- Press button for function. The default time is 50 minutes and it cannot be adjusted. It twice
is 45 minutes Heat and 5 minutes Air Circulation.
- Press button for function. The default time is 40 minutes and it cannot be three (3) times
adjusted. It is 35 minutes Heat and 5 minutes Air Circulation.
- Press button for function. The default time is 10 minutes and it cannot be four (4) times
adjusted. It is 10 minutes Air Circulation.
7. The selector indicator light will be ashing, then wait for about 3 seconds for the function to start.
The selector indicator light will be solid.
Note: To cancel and change the function, press button.
8. When the timer is up, a beep sound will be heard.
9. Press and hold button for 3 seconds to turn OFF the unit.
10. Unplug the unit from the convenience outlet after every use.
*Note Do not block the steam vent or touch the heater during or after use. :
