Federal SSRC-7752 Handleiding
Lees hieronder de 📖 handleiding in het Nederlandse voor Federal SSRC-7752 (37 pagina's) in de categorie Koelkast. Deze handleiding was nuttig voor 80 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld
Pagina 1/37
- 1 -
E3091-3
Revised 1/21/2014
INSTALLATION & OPERATIONS INSTRUCTIONS
REFRIGERATED SSRC MODELS
KEEP THIS MANUAL FOR FUTURE REFERENCE
Engineering and technical data are subject to change without notice.
FEDERAL INDUSTRIES 215 FEDERAL AVE Belleville, WI 53508
Toll Free 1(800) 356-4206 WI Phone (608) 424-3331 Fax: (608) 424- 3234
- 2 -
CONTENTS
INTRODUCTION ....................................................................................................................................... 3
WARNING LABELS & SAFETY INSTRUCTIONS .............................................................................. 4
PRE-INSTALLATION PROCEDURES................................................................................................... 5
Inspection For Shipping Damage ..................................................................................................... 5
GENERAL ELECTRICAL & GROUNDING ......................................................................................... 5
Permanent Connected ...................................................................................................................... 5
Cord Connected (Option) ................................................................................................................. 5
INSTALLATION INSTRUCTIONS ......................................................................................................... 6
Locating The Display Case .............................................................................................................. 6
Removing Case From Shipping Skid ............................................................................................... 6
Cleaning ........................................................................................................................................... 6
Refrigeration Installation .................................................................................................................. 6
REFRIGERATION ................................................................................................................................. 7-8
Self Contained Models ..................................................................................................................... 7
Self Contained Refrigeration Operation ...................................................................................... 7
Remote Models ................................................................................................................................ 8
Remote Refrigeration Operation ................................................................................................. 8
Remote Refrigeration Instruction ................................................................................................ 8
SHELVING INSTALLATION & REMOVAL .................................................................................. 9-11
Shelf Brackets & Supports ......................................................................................................... 9-10
Wire Shelves .................................................................................................................................. 10
Glass Shelves (Option) ................................................................................................................... 11
REAR DOORS ................................................................................................................................... 12-13
Top Section Rear Doors ................................................................................................................. 12
Bottom Section Rear Doors (Option) ............................................................................................. 13
NIGHT CURTAIN (OPTION) ................................................................................................................. 14
SECURITY NIGHT COVER (OPTION) ............................................................................................... 15
OPERATING INSTRUCTIONS ....................................................................................................... 16-17
Controls .......................................................................................................................................... 16
Top Section Refrigeration Louver Control..................................................................................... 20
Placing Product In Case ................................................................................................................. 20
MAINTENANCE ...................................................................................................................................... 21
Top Light Bulb Replacement ......................................................................................................... 21
Shelf Light Bulb Replacement ....................................................................................................... 21
PERIODIC MAINTENANCE ................................................................................................................. 22
Cleaning Condenser Coil................................................................................................................ 22
CLEANING INSTRUCTIONS ................................................................................................................ 23
Daily Cleaning ................................................................................................................................ 23
Weekly Cleaning ............................................................................................................................ 24
Weekly Top Section Cleaning ........................................................................................................ 24
Weekly Bottom Section Cleaning .................................................................................................. 25
Weekly Exterior Cleaning .............................................................................................................. 26
SERVICE INFORMATION .................................................................................................................... 27
Special Service Situations .............................................................................................................. 27
Pre-Service Checklist ..................................................................................................................... 28
Electronic Control Operation ......................................................................................................... 29
SALE & DISPOSAL ................................................................................................................................. 32
Owner Responsibility ..................................................................................................................... 32
REFRIGERATION & ELECTRICAL DATA ....................................................................................... 32
WIRING DIAGRAMS .............................................................................................................................. 33
Self Contained ................................................................................................................................ 33
Remote ........................................................................................................................................... 34
REPLACEMENT PARTS ........................................................................................................................ 35
- 3 -
INTRODUCTION
Thank you for purchasing a Federal Industries display case. This manual contains important instructions for
installing and servicing the Refrigerated Self-Service Merchandisers. A repair parts list and wiring diagram
are also included in the manual. Read all of these documents carefully before installing or servicing your
case.
NOTICE
Read this manual before installing your case. Keep this manual and refer to it before doing any
service on the equipment. Failure to do so could result in personal injury or damage to the case.
NOTICE
Installation and service of the electrical components in the case must be performed by a licensed
electrician.
The portions of this manual covering components contain technical instructions intended only for persons
qualied to perform electrical work.
DANGER
Improper or faulty hookup of electrical components in the case can result in severe injury or death.
All electrical wiring hookups must be done in accordance with all applicable local, regional, or
national standards.
SERIAL NUMBER
Record the model and serial numbers of the case for easy reference. Always refer to both model and serial
numbers in your correspondence regarding the case.
Case Model__________________________ Serial Number______________________
Condensing Unit Model________________ Serial Number______________________
This manual cannot cover every installation, use, or service situation. If you need additional information,
call or write us:
WARRANTY/TECHNICAL SERVICE DEPARTMENT
Federal Industri es
P.O. Box 290
Belleville, WI 53508
Toll Free (800) 356-4206 / WI Phone (608) 424-3331
