Pagina 1/79
Owner's Manual
Multimedia Projector
MODEL LC-XB250
Network Supported
Wired LAN
Refer to the Owner's Manuals
below for details about network
function.
Network Set-up and Operation
PJ Network Manager
2
Features and Design
This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use.
This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display
(LCD) technology.
Compact Design
This projector is designed compact in size and weight.
It is easy to carry and installed anywhere you wish to
use.
Simple Computer System Setting
The projector has the Multi-scan system to conform to
almost all computer output signals quickly (p.29). Up to
WUXGA resolution can be accepted.
Useful Functions for Presentations
- The digital zoom function allows you to focus on the
crucial information during a presentation (p.36).
- Blackboards* can be used as a projection screen.
*The board color is limited to Green (pp.33, 41).
Lamp Control
Brightness of the projection lamp can be selected
(pp.25, 54).
Direct OFF Function
With the Direct OFF function, you can disconnect the
power cord from the wall outlet or turn off the breaker
even during projection (p.20).
Logo Function
The Logo function allows you to customize the screen
logo (pp.48-50). You can capture an image for the
screen logo and use it for the starting-up display or
between presentations.
Multilanguage Menu Display
Operation menu is available in 21 languages: English,
German, French, Italian, Spanish, Portuguese, Dutch,
Swedish, Finnish, Polish, Hungarian, Romanian,
Cz ech , Russi an, Tur ki sh, K azakh, Vi etnamese,
Chinese, Korean, Japanese and Thai (p.46).
Note:
 •TheOn-ScreenMenuandfiguresinthismanualmaydifferslightlyfromtheproduct.
 •Thecontentsofthismanualaresubjecttochangewithoutnotice.
Security Function
The Security function helps you to ensure security
of the projector. With the Key lock function, you can
lock the operation on the top control or remote control
(p.55). PIN code lock function prevents unauthorized
use of the projector (pp.19, 55–56).
Helpful Maintenance Functions
Lamp and filter maintenance functions provide for
better and proper maintenance of the projector.
LAN Network Function
This projector is loaded with the Wired LAN network
function. You can operate and manage the projector
via network. For details, refer to the owner’s manual
“Network Set-up and Operation.”
Auto Setup Function
This function enables Input search, Auto Keystone
correction and Auto PC adjustment by simple pressing
the AUTO SETUP button on the top control (p.47).
Colorboard Function
At the time of simple projection on the colored wall,
you can get the close color image to the color image
projected on a white screen by selecting the similar
color to the wall color from the preset four colors.
Power Management
The Power management function reduces power
consumption and maintains the lamp life (p.51).
Closed caption
Closed caption is a function that displays the audio
portion of a TV program as text on the screen. The
closed captioning service is available mainly in the U.S
(p.53).
3
Table of Contents
Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its respective
corporation.
Features and Design . . . . . . . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . . . . . . . .3
To the Owner. . . . . . . . . . . . . . . . . . . . . . . . . .4
Safety Instructions . . . . . . . . . . . . . . . . . . . . .5
Air Circulation 6
Installing the Projector in Proper Position 6
Moving the Projector 6
Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Part Names and Functions . . . . . . . . . . . . . .8
Front 8
Back 8
Bottom 8
Rear Terminal 9
Top Control 10
Remote Control 11
Remote Control Battery Installation 12
Remote Control Operating Range 12
Remote Control Code 12
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . .13
Positioning the Projector 13
Adjustable Feet 13
Connecting to a Computer 14
Connecting to Video Equipment 15
Connecting to Component Video Equipment 16
Connecting the AC Power Cord 17
Basic Operation . . . . . . . . . . . . . . . . . . . . . .18
Turning On the Projector 18
Turning Off the Projector 20
How to Operate the On-Screen Menu 21
Main Menu 22
Zoom and Focus Adjustment 23
Auto Setup Function 23
Keystone Correction 23
Sound Adjustment 24
Remote Control Operation 25
Computer Input . . . . . . . . . . . . . . . . . . . . . .27
Input Source Selection
{(RGB: Computer 1/Computer 2(Analog)} 27
Input Source Selection
{Computer2: RGB(PC digital), RGB(AV HDCP)}
28
Computer System Selection 29
Auto PC Adjustment 30
Manual PC Adjustment 31
Image Mode Selection 33
Image Adjustment 34
Screen Size Adjustment 35
Video Input . . . . . . . . . . . . . . . . . . . . . . . . . .38
Input Source Selection (Video, S-video) 38
Input Source Selection (Component, Scart) 39
Video System Selection 40
Image Mode Selection 41
Image Adjustment 42
Screen Size Adjustment 44
Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Setting 46
Information . . . . . . . . . . . . . . . . . . . . . . . . . .59
Input Source Information Display 59
Maintenance and Cleaning . . . . . . . . . . . . .60
WARNING indicator 60
Replacing the Filters 61
Resetting the Filter Counter 61
Attaching the Lens Cap 62
Cleaning the Projection Lens 62
Cleaning the Projector Cabinet 62
Lamp Replacement 63
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Troubleshooting 65
Menu Tree 68
Indicators and Projector Condition 70
Compatible Computer Specifications 71
Technical Specifications 73
Optional Parts 74
PJ Link Notice 75
Attaching the Filter Cover to the projector 75
Configurations of Terminals 76
PIN Code Number Memo 77
Dimensions 78
