Dracast DRX Series LED Smart Panel Light
The DRX Series LED Smart Panel Light uses high power LEDs, giving it advantages such as high luminous ed
efficiency, long life, high CRI & TLCI, etc. The solid aluminum housing allows efficient heat dissipation, while still
enabling it to be ultra-thin, stable and easy to carry. It can be controlled manually, or via Bluetooth with a smart phone APP.
This light can be used in a wide variety of applications such as digital or film photography, videos, film and TV
shooting, studio photography, and much more.
â… . in Light StructureMa
(1)
Three-Way Power Switch
(2)
Power Input
(3)
Dual-NPF Battery Plate
(4)
LCD Display
(5)
Power/Color Temperature Button
(6)
LED Surface
(7)
Side Yoke Knob
(8)
Accessory Mounting Hole
(9)
Holder
(10)
Bottom Yoke Knob
II. In The Box
1.
Light body with yoke
Power cable
3.
DC15V power adapter
Manual
III. Digital Display Features
â‘  CCT: (corrected color temperature )
② DIM: (light intensity/brightness)
③ Light No.
â‘Ł Group No.
⑤ Master/Slave Indicator
â‘Ą Battery indicator
IV. Light Operation
a) Powering up the light
Connect the power adapter to an AC power outlet, insert the adapter cable end into to the power input (2), turn
on the power switch (1) to DC port, adjust brightness and color.
The light can also use 2 x NP-F batteries to power up. When using batteries , insert batteries fully into the battery
plate, turn on the power switch (1) to BATT port, adjust brightness and color.
Note: If don't use the original light power adapter, and the third-party adapter doesn't match the light’s A/C you
power adapter output specifications (see “Product Specifications”), it can cause problems with the light itself. If the
power adapter output is too low, it can cause the LED’s to flicker or not come on at all (the digital display may still
come on), or the LED’s may not power up to full brightness—possibly being very dim. If the voltage is more or less
than 15 Volts, it will damage the light, and such damage will not be covered under warranty. Too much voltage can
cause sparks, smoke, and possibly start a fire. If you notice any of the above issues, unplug the A/C power adapter
immediately to avoid any further damage to the light or adapter.
b) Power/Color temperature adjustment
Press the power/color temperature button (5) to switch between DIM and CCT modes. The active mode should
be blinking.
In the DIM mode, rotate the power/color temperature button (5) to change the brightness in 1% increments --
clockwise to increase the brightness, and counterclockwise to decrease the brightness. The power range is from 0%
(off) to 100% (full power)
In the CCT mode, rotate the power/color temperature button (5) clockwise to increase the color temperature by
intervals of 50K; rotate counterclockwise to decrease the color temperature by the same intervals.
The CCT range from is from 3200K-5600K.
c) Light No/Group No/Master/Slave Mode setting
Press and hold the power/color temperature button (5) for 2-3 seconds until the Light No. “L” starts blinking. ③
Rotate the knob to change Light No. Press the press power/color temperature button (5) again and the Group No
“G” will blink. Rotate the knob to change the Group No. Press the power/color temperature button (5) a third time ④
and the Master/Slave selection will flicker. Rotate the knob to put the light in either Master or Slave mode. ⑤
Download the “DRACAST DRX to control the light via Bluetooth with a smart phone. You can search for ” app
“DRACAST DRX” on the Apple AppStore or Google Play Store.
d) Master/Slave Mode
This feature allows one “Master” light to control other lights, which are “Slaved” to that light.
MASTER: When the light is in the Master mode, it will operate normally. It will also send out Bluetooth signal a
which can be picked up by any light in the same group that is in the Slave mode. When the brightness or color
temperature are adjusted on the Master light, the slaved light will change in the same way as the Master light.
SLAVE: When the light is in the Slave mode, you will not be able to operate it manually – only by a light in the
same group which is set to the Master mode. A slaved light will respond to the Master light and change in the same
ways the Master light is being changed.
TURN OFF MASTER/SLAVE: When there is no Master/Slave Mode on the LCD display, it indicates the light is
in fully manual mode, and cannot control, nor be controlled by, any other light.
V. Other Operations
1. Power indicator
The LCD display has a power indicator , to show the approximate amount of charge left in the battery. When â‘Ą
there is only one bar left on the indicator, it is time to recharge the battery. If you continue to use the light with only
one power bar on the indicator, the light may shut off without warning.
2. Restore factory setting
Press and hold the power/color temperature button (5) for 8 seconds, or un the LCD display flickers. til
VI. Warnings!
1. While neither the LEDs, nor the light head itself, should become hot enough to cause serious injury, if an unknown
malfunction occurs, they may heat up beyond expectations. Therefore, when the light is being used, or has just
been turned off, please be careful of the LEDs and the lamp head to avoid the possibility of burns.
2. Do not put any ing over the light body, to allow it to properly dissipate heat.cover
3. Keep the light clean, using a soft damp cloth, and make sure to turn off the light before cleaning.
4. When storing the light, keep it in a safe and dry place.
5. Do not use the light for extended periods of time in direct sunlight or in areas with an ambient temperature higher
than 100°F (37.8°C).
6. Do not expose the light to drips, splashes, or any degree of precipitation – it is not water resistant.
7. Do not use solvents, gasoline, paints and pesticides on the product. Clean only with a soft cotton cloth moistened
with warm water. If necessary, moisten a soft cotton cloth with very dilute solution of dishwashing detergent.a
8. Do not insert metal objects into the lamp housing.
9. Do not touch the power cord with wet hands.
10. When removing the power plug, always pull the plug rather than the power cord.
11. Do not attempt to repair the light. If there are problems, turn off the light and contact Draco Broadcast.any
V .II Product SpecificationS
Model
DRX500BN
DRX1000BN
Max output (W)
35W
70W
Illuminance (Lux@1m)
1100
2100
CCT(K)
3200-5600K
CRI
95%
TLCI
95%
Beam angle
100°
Smartphone control
Yes
Yes
Master/Slave
Yes
Yes
Remote distance
10m
10m
Power adapter input
AC 90-240V~ 50/60Hz
Power adapter output
DC 15V / 3A
DC 15V / 5A
Housing size (mm / in.)
282 52 277 ď‚´ ď‚´ mm
11.1 x 2.05 x 10.9 in
492 52 277 ď‚´ ď‚´ mm
19.37 x 2.05 x 10.9 in
Weight (kg / lb)
1.1 kg / 2.4 lb
1.8 kg / 3.9 lb
