RM2453
RM2553
FOR YOUR SAFETY
If you smell gas:
1. Open windows and door.
2. Don’t touch electrical switches.
3. Extinguish any open ame.
4. Turn off the Gas supply at the source.
FOR YOUR SAFETY
Do not store or use gasoline or other am-
mable vapors and liquids in the vicinity of
this or any other appliance.
822 70 36-04 MO-M 0911
RA/RM-1D
INSTALLATION
&
OPERATING
INSTRUCTIONS
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information consult
a qualied installer, service agency or the
gas supplier.
wARNING
6
!
5 . Contact a qualified person.
5
2
InstallatIon InstRuctIons ____________ 3
General information . . . . . . . . . . . . . . . . . . . . . . . . . 3
PackaGinG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Ventilation requirements . . . . . . . . . . . . . . . . . . . . 3
clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
installinG the refriGerator . . . . . . . . . . . . . . . . .
securinG the refriGerator . . . . . . . . . . . . . . . . . .
connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
chanGinG Door sWinG . . . . . . . . . . . . . . . . . . . . . . . . 7
mountinG the Door Panel . . . . . . . . . . . . . . . . . . . . . 7
refriGerator remoVal . . . . . . . . . . . . . . . . . . . . . . . 7
opeRatIng InstRuctIons ______________
Gas anD ac oPeration . . . . . . . . . . . . . . . . . . . . . . . . . 8
reGulatinG the temPerature . . . . . . . . . . . . . . . . . 9
turninG off the refriGerator . . . . . . . . . . . . . . . . 9
storaGe comPartments . . . . . . . . . . . . . . . . . . . . . . 9
ProDuct care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
MaIntenance & seRvIce _______________ 10
rePlacinG the heater . . . . . . . . . . . . . . . . . . . . . . . .10
PerioDic maintenance . . . . . . . . . . . . . . . . . . . . . . . .10
troubleshootinG . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
appendIx ____________________________ 12
rearVieW equiPment . . . . . . . . . . . . . . . . . . . . . . . . . 2
WirinG DiaGram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
contents IntRoductIon
We are pleased that you have chosen this refrigerator and
hope you will derive much satisfaction from using it.
The refrigerator is designed for storage of foods and storage
of frozen foods and making ice.
The installation and servicing should only be carried out by
an authorized/qualied person and conform to all relevant
local authorities.
It is important to read through these instructions carefully
before using the refrigerator. To ensure good refrigeration and
economical operation, the refrigerator must be installed and
used as described in these instructions.
Follow the instructions in this manual. The refrigerator is
quality guaranteed. However, we are not responsible for any
failures caused by improper adjustments and unfavourable in-
stallation conditions. Please contact service point or distribu-
tor service dept. for assistance.
data plate
Check the data plate, located inside the refrigerator, to ensure
that you have received the right model and that it is suitable
for the available gas supply and pressure.
The right gas pressure is . . . . . . . . . . . . . . . . . . 2.72 kPa
The right voltage is . . . . . . . . . . . . . . . . . . 230 - 240 volt
The right gas consumption is . . . . . . . . . . . . . . 1.24 MJ/h
The data plate contains e. g. the following details:
Model designation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Since these details will be needed if you have to contact serv-
ice personnel, it is a good idea to make a note of them here.
syMbols
The following symbols are used throughout the manual:
Indicates a potentially hazardous
situation, which, if not avoided,
could result in death or serious
injury.
Indicates a potentially hazardous
situation, which, if not avoided,
may result in minor or moderate
injury.
Used without the safety alert
symbol indicates, a potentially
hazardous situation which, if not
avoided may result in property
damage.
Step-by-step instructions
CAUTION
!
WARNING
!
CAUTION
5
5
5
8
12
12
3
technIcal data
ventIlatIon heIghts
cleaRances
MInIMuM cleaRances to coMbustIble MateRIal (MM)
Top g0
Side k0
Bottom l0
Rear M125
G
KK
L
RM2453 RM2553
oveRall dIMensIons
Height(mm) 948 1104
Width(mm) 632 632
Depth(mm)
627 627
Recess dIMensIons
Height(mm) 928 1083
Width(mm) 607 607
Depth(mm)
610 610
capacIty
Gross(litres) 121 150
weIght
without pack ing(kg) 39 44.5
electRIcal data (watt)
Input
Input, max(MJ/h)
ulp gas
240V 195 195
12V 175 175
1.16 1.16
INSTALLATION INSTRUCTIONS
GENERAL INFORMATION
The refrigerator is intended for installation in caravans&motor
lation is important for correct operation of the appliance.
The refrigerator must be installed on a solid floor and must
be level. With the vehicle levelled, the refrigerator
should be level both ways in the freezer compartment.
Free air circulation over the fins of the cooling unit is essential.
instal
omes
h
VENTILATION OF ThE UNIT
VENTILATION GRILLES
We recommend fitting the Dometic ventilation system
is specially developed by Dometic for this purpose. The
Dometic ventilation grilles permit inspection and small repairs
to be carried out without the necessity of removing the refrig-
erator from the recess.
If the grille not at floor level where leaking gas can
escape,
floor of the recess to drain any unburned gas to the outside.
which
appropriate
is lower
a hole a minimum of 40 mm diameter should be made
in the
SIDE VENTILATION
The refrigerator unit is ventilated via two openings in the wall
of the , Fresh air enters through the lower opening
and warm air is discharged through the upper
The lower opening should be located at floor level to allow
any leaking gas to escape to the outside. The upper ventilation
opening should be located above the condenser, as high as pos-
sible, to ensure good ventilation.
vehicle
vent.
ROOF VENTILATION
The ventilation of the cooling unit can also be done via one
opening in the wall of the and one on the roof for
the roof vent.
Fresh air enters through the lower opening and warm air is
discharged through the roof vent. The lower opening should be
located at floor level to allow any leaking gas to escape to the
outside.
REMOVAL OF FLUE GASES
The ventilation passage at the rear of the recess, between the
outer wall of the vehicle and the refrigerator must be sealed
off against the living space, so cold draughts are excluded
(winter camping) and no flue gases can penetrate into the
ve .
vehicle
ic e h l
The exhaust gases must be directed through the wall to
discharged through the roof vent. The lower opening should be discharged through the roof vent. The lower opening should be
the outside of lue exhaust
fitting,[part number 3776 (see the following d
iagrams)
the vehicle using a separate gas f
only perform adequately when proper
In hig h ambient temperatures the refrigerat
ion unit will
ly ventilated
