KVM SWITCH, 2- PORT,

SINGLE DISPLAY, 4K, HDMI

User Manual

DS-12870

User consideration

The manufacturer has the right to modify and change the information, documents

and specifications contained in the manual without prior notice. The manufacturer

does not warrant, express, imply or statutorily declare its contents or specifically

disclaims its merchantability and fitness for a particular purpose. Any of the

manufacturer's software described in this manual that is sold and licensed. If the

software program is found to be defective after purchase, the purchaser (and non-

manufacturer, its distributor or its purchaser) will be responsible for all necessary

services, repairs and any accidental or consequential damages caused by the

software.

The manufacturer is not responsible for any unauthorized adjustments to the radio

and / or television interference caused by this equipment, and the user must correct

the interference.

If the operating voltage setting is not correctly selected before operation, the

manufacturer will not be liable for any damage caused.

Be sure to confirm that the voltage is set correctly before use. This product does

not have a power supply. If the power supply is required in a special environment,

the customer can configure it according to the product power interface (power

supply socket specification 5.5 mm x 2.1 mm) and the power socket printing

parameters.

Package Contents

The multi-computer KVM switch package includes the following:

 1 x KVM Switch, 2- Port, Single Display, 4K, HDMI®

 2 x KVM cable (HDMI®, USB, Audio)

 1 x Manual

Check that all parts are in place and that they are not damaged in transit. If you

encounter problems, please contact your dealer.

To prevent damage to the machine or equipment connected to the machine, please

read this manual carefully and follow the instructions for installation and operation.

∗ Since the publication of this manual, there may be new product features. Please

visit our website to download the latest version of the user manual.

Contents

About manual ........................................................................................................4

Product information ..............................................................................................4

CHAPTER 1 ................................................................................................................ 5

I NTRODUCTION ..............................................................................................................5

Product description ...............................................................................................5

Product features ....................................................................................................5

Operating system ..................................................................................................6

CHAPTER 2 ................................................................................................................ 8

HARDWARE INSTALLATION................................................................................................8

Cable connection and installation .........................................................................8

CHAPTER 3 ................................................................................................................ 9

BASIC OPERATION ...........................................................................................................9

Overview 9...............................................................................................................

Manual switching method ....................................................................................9

Hotkey switching method ......................................................................................9

Power off and restart ............................................................................................9

CHAPTER 4 .............................................................................................................. 10

K EYBOARD OPERATION ..................................................................................................10

Overview .............................................................................................................10

Hotkey setting: ....................................................................................................10

APPENDIX ............................................................................................................... 13

S I AFETY NSTRUCTIONS...................................................................................................13

General ................................................................................................................13

PRODUCT SPECIFICATION ................................................................................................15

Product specificaties

Merk:	Digitus
Categorie:	Schakelaar
Model:	DS-12870
Ingebouwd display:	Nee
Gewicht:	465 g
Breedte:	132 mm
Diepte:	92 mm
Hoogte:	44 mm
Materiaal behuizing:	Metaal
LED-indicatoren:	Status
USB-connectortype:	USB Type-B
Maximum resolutie:	3840 x 2160 Pixels
Meegeleverde kabels:	KVM
Land van herkomst:	China
Aantal HDMI-poorten:	2
Hoofdtelefoonuitgangen:	1
Aansluiting voor netstroomadapter:	Ja
HD type:	4K Ultra HD
HDMI versie:	1.4b
Temperatuur bij opslag:	-20 - 60 °C
USB-hub:	Ja
Snelle installatiehandleiding:	Ja
Aansluiting video:	HDMI
Bedrijfstemperatuur (T-T):	0 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 80 procent
Code geharmoniseerd systeem (HS):	85176200
Aantal microfooningangen:	1
Aansluiting toetsenbord:	USB
Aansluiting muis:	USB
Aantal computers:	2
Console-poorten:	3.5mm headphone, 3.5mm mic, HDMI, USB A
Aantal USB 2.0-Type-A-hubpoorten:	1
Videobandbreedte:	30 Hz
Audio-aansluitingen:	Ja
Aantal USB-poorten console:	2
