M10 / M12 / M15 Active monitor

Highlite International B.V. Vestastraat 6468 EX Kerkrade the Netherlands –2 – – –

Ordercode: D D3661 D3662 3660 – –

MANUAL

ENGLISH

M10 M12 M15 – –

Ordercode: D3660 D3661 D3662 – –

Table of contents

Warning ............................................................................................................................................................................... 2

Safety Instructions ......................................................................................................................................................... 2

Connection with the mains 4 .........................................................................................................................................

Return Procedure .......................................................................................................................................................... 4

Claims .............................................................................................................................................................................. 4

Description of the device ................................................................................................................................................. 5

Features .......................................................................................................................................................................... 5

Optimized soundfield projection ............................................................................................................................... 5

Panel Description ............................................................................................................................................................... 6

Connection Cables ........................................................................................................................................................... 6

Connection Example ........................................................................................................................................................ 7

Frequency Response Diagram ....................................................................................................................................... 8

Technical Specifications .................................................................................................................................................. 9

M10 M12 M15 – –

Ordercode: D3660 D3661 D3662 – –

Warning

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure

that all parts are present and have been received in good condition. Notify the dealer immediately and

retain packing material for inspection if any parts appear damaged from shipping or the carton itself

shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be

returned to the factory, it is important that the fixture be returned in the original factory box and packing.

Safety Instructions

Every person involved with the installation, operation and maintenance of this device have to:

- be qualified

- follow the instructions of this manual

Before your initial start-up, please make sure that there is no damage caused by transportation. Should

there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to

follow the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the device are not subject to

warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

IMPORTANT!

The manufacturer will not accept liability for any resulting damages caused by the non-

observance of this manual or any unauthorized modification to the system.

 Always disconnect power from the mains, when system is not used. Only handle the power-cord by

the plug. Never pull out the plug by tugging the power-cord.

 Always operate the unit with the AC ground wire connected to the electrical system ground.

 Avoid flames and do not put close to flammable liquids or gases.

 Avoid ground loops! Always be sure to connect the power amps and the mixing console to the

same electrical circuit to ensure the same phase!

 Avoid installing your equipment very near radio or TV sets, mobile phones, etc., as these can cause

RF (radio frequency) interference.

 Before changing your grounds around, always turn your amplifiers down.

 Before connecting or disconnecting the power cord, make certain the ON / OFF switch is in the OFF

position.

 Before switching on or off make certain the sound system’s amplifiers are off or turned down: this will

avoid signal peaks, which are annoying and sometimes dangerous (particularly for speaker

enclosures).

 Do not connect this device to a dimmer pack.

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

CAUTION! Be careful with your operations.

With a dangerous voltage you can suffer

a dangerous electric shock when touching the wires!

Product specificaties

Merk:	DAP Audio
Categorie:	Speaker
Model:	M10
Kleur van het product:	Zwart
Gewicht:	11400 g
Breedte:	351 mm
Diepte:	323 mm
Hoogte:	363 mm
Materiaal behuizing:	MDF
Gemiddeld vermogen:	- W
Versterker output power:	415 W
Impedantie:	- Ohm
Frequentiebereik:	- Hz
Diameter woofer:	10 "
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Type product:	Vloermonitor
Versterker klasse:	D
Bi-amping:	Ja
