Pagina 1/20

Productcode:

D3630

D3631

D3632

D3633

D3643

D3644

D3645

Productname:

DRX-8

DRX- 10

DRX- 12

DRX- 15

DRX-10B

DRX-12B

DRX-15B

DRX Passive Series

Highlite International B.V. Vestastraat 2 6468 EX Kerkrade the Netherlands – – – –

MANUAL

ENGLISH

DRX Passive Series

Table of contents

Warning ............................................................................................................................................................................... 2

Unpacking Instructions ..................................................................................................................................................... 2

Safety Instructions .............................................................................................................................................................. 2

Connection with the mains ............................................................................................................................................. 4

Return Procedure .............................................................................................................................................................. 4

Claims .................................................................................................................................................................................. 4

Features ............................................................................................................................................................................... 5

Accessories ......................................................................................................................................................................... 5

Rear Panel Description ..................................................................................................................................................... 6

DRX-1OB/12B/15B SUB .................................................................................................................................................. 6

DRX-8/10/12/15 7 .............................................................................................................................................................

Connection Examples ...................................................................................................................................................... 8

Two Passive Subwoofers & Two Passive Satellite Speakers ................................................................................... 8

One Passive Subwoofer & Two Passive Satellite Speakers .................................................................................... 9

Two Passive Satellite Speakers ..................................................................................................................................10

Frequency Response Diagram .....................................................................................................................................11

DRX-10B/12B/15B .........................................................................................................................................................11

DRX-8/10/12/15 ...........................................................................................................................................................12

Connection Cables ........................................................................................................................................................13

Technical Specifications ................................................................................................................................................14

DRX- 10B......................................................................................................................................................................14

DRX- 12B......................................................................................................................................................................14

DRX- 15B......................................................................................................................................................................15

DRX-8 ..........................................................................................................................................................................15

DRX- 10........................................................................................................................................................................16

DRX- 12........................................................................................................................................................................16

DRX- 15........................................................................................................................................................................17

Troubleshooting ...............................................................................................................................................................17

Notes ..................................................................................................................................................................................18

DRX Passive Series

Warning

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure

that all parts are present, and have been received in good condition. Notify the dealer immediately and

retain packing material for inspection if any parts appear damaged from shipping or the carton itself

shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be

returned to the factory, it is important that the fixture be returned in the original factory box and packing.

Safety Instructions

Every person involved with the installation, operation and maintenance of this device have to:

- be qualified

- follow the instructions of this manual

Before your initial start-up, please make sure that there is no damage caused by transportation. Should

there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to

follow the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the device are not subject to

warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

IMPORTANT!

The manufacturer will not accept liability for any resulting damages caused by the non-

observance of this manual or any unauthorized modification to the system.

 Avoid flames and do not put close to flammable liquids or gases.

 Before changing your grounds around, always turn your amplifiers down.

 Before switching on or off make certain the sound system’s amplifiers are off or turned down: this will

avoid signal peaks, which are annoying and sometimes dangerous (particularly for speaker

enclosures).

 Do not drive the inputs with a signal level bigger, than required to drive the equipment to full output.

 Do not open this device.

 Extreme frequency boosts in connection with a high input signal level may lead to overdriving your

equipment. Should this occur, it is necessary to reduce the input signal level by using the INPUT

control.

 If device is dropped or struck, disconnect mains power supply immediately. Have a qualified

engineer inspect for safety before operating.

 In system setup, the amplifier's output power must be 50%-100% more than the loaded loudspeakers

rated power.

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

CAUTION! Be careful with your operations.

With a dangerous voltage you can suffer

a dangerous electric shock when touching the wires!

Product specificaties

Merk:	DAP Audio
Categorie:	Speaker
Model:	DRX-12
Kleur van het product:	Zwart
Gewicht:	14500 g
Breedte:	353 mm
Diepte:	360 mm
Hoogte:	584 mm
Materiaal behuizing:	Acrylonitrielbutadieenstyreen (ABS)
Connectiviteitstechnologie:	Bedraad
Gemiddeld vermogen:	150 W
Aanbevolen gebruik:	Universeel
Impedantie:	8 Ohm
Audio-uitgangskanalen:	- kanalen
Woofer:	Ja
Peak Music Power Output (PMPO):	300 W
Frequentiebereik:	- Hz
Gevoeligheid:	95.6 dB
Luidspreker soort:	2-weg
Diameter woofer:	12 "
Crossover frequentie:	2800 Hz
