Installationandoperationmanual

DaikinAlthermasimplifieduserinterface English

Installationandoperation

manual

DaikinAlthermasimplifieduserinterface

EKRUCBS

TableofContents

Installationandoperationmanual

EKRUCBS

DaikinAlthermasimplifieduserinterface

4P3822511–2014.06

TableofContents

Fortheuser 2

1 Buttons 2

2 Statusicons 2

Fortheinstaller 3

3 Overview:Installationandconfiguration 3

4 Toconnectthesimplifieduserinterface 3

5 ToupdatethesoftwarewithUpdater 3

6 Toupdatethesoftwaremanually 4

Fortheuser

1 Buttons

aSPACEHEATING/COOLINGCONTROL

Gototheroomtemperaturehomepage,whereyoucan:

▪ Readouttheactualroomtemperature.

▪ Press or toadjustthedesiredroomtemperature.

▪ Press toturnONorOFFtheroomtemperaturecontrol.

bDOMESTICHOTWATERCONTROL

Gotothedomestichotwaterhomepage,whereyoucan:

▪ Read out the actual domestic hot water tank temperature

(onlyifthesystemcontainsadomestichotwatertank).

▪ Read out the desired instant domestic hot water

temperature (only in case of instant domestic hot water

productionbyaboiler).

▪ Press  to turn ON or OFF the domestic hot water

control.

cDHWTANKBOOSTERMODE

Activate the DHW tank booster mode (only if the system

contains a domestic hot water tank, and provided that the

domestichotwatercontrolisturnedON).

dON/OFF

Turn ONorOFF thespace heating/coolingor domestichot

watercontrol(ontherespectivehomepages).

e NAVIGATIONBUTTONS

Adjust the desired room temperature (on the room

temperaturehomepage).

2 Statusicons

Icon Description

Spaceoperationmode=Heating.

Spaceoperationmode=Cooling.

Domestichotwateroperation.

TheDHWtankboostermodeisactive.

Unitisoperating.

Actualtemperature.

Desiredtemperature.

Amalfunctionoccurred.

Emergencyoperationisactive.

If  or  is displayed, check the main user interface for more

informationor,ifnecessary,contactyourinstaller.

3Fortheinstaller

Installationandoperationmanual

EKRUCBS

DaikinAlthermasimplifieduserinterface

4P3822511–2014.06

Fortheinstaller

3 Overview:Installationand

configuration

Installation

▪ Thesimplifieduserinterfacecanonlybeusedincombinationwith

themainuserinterface.

▪ The main user interface acts as control centre and needs to be

installedneartheunit.

▪ The simplifieduser interfaceacts as roomthermostatandneeds

tobeinstalledintheroomthatyouwantittocontrol.

Configuration

Itisrequiredthatthesimplifieduserinterfacehasthesamesoftware

versionasthemainuserinterface.Ifnecessary,updatetheleastup

todate interface. You can find the software version on the box of

eachinterface.

Therearetwowaystoupdatethesoftware:

▪ ByusingtheUpdatersoftware.

▪ Bymanuallyupdatingthesoftware.

INFORMATION

Toupdatethesoftware,itisrecommendedtouseUpdater.

Updatingthesoftwaremanuallycantakeupto2.5hours.

4 Toconnectthesimplified

userinterface

1Connect thecableofthe simplifieduserinterface totheindoor

unit.

X2M

X5M

A2P A2P

a b

aMainuserinterface

bSimplifieduserinterface

2Fixthecablewithcabletiestothecabletiemountings.

5 Toupdatethesoftwarewith

Updater

Prerequisite: PC with Updater (contact your dealer for the correct

versionofthesoftware)

Prerequisite:PCUSBcableEKPCCAB3orhigher(includesaUSB

cableandadditionalconnectioncables)

1MakesurethattheindoorunitispoweredOFF.

2ConnecttheuserinterfacetothePC.

X1A

ab c

aPCwithUpdater

bUSBcable

cUserinterfacePCB

dToindoorunit

3PowerONtheindoorunit.

4OpenUpdater.

5InUpdater,goto"Updateprocedure".

6Type in the name of the interface (EKRUCBL* or EKRUCBS,

dependingonwhichyouareupdating).

7Selectthedesiredlanguagepack(onlyforEKRUCBL*).

8Followtheonscreeninstructions.
