Saros® Pendant Speakers

quickstart guide

SAROS_PD4T/PD6T/PD8T/PDS8T

www.crestron.com

Specifications subject to

change without notice.

SAROS_PD4T/PD6T/PD8T/PDS8T

Install/Remove Grille

The zero-bezel frameless grille is held in place by powerful magnets. A safety tether is

included to prevent any possibility of the grille falling from the ceiling. Attach the tether to the

baffle using the supplied screw, cover the screw with the rubber boot provided, and place the

grille in position on the speaker. To remove the grille, insert the supplied pick accessory in

one of the side edge grille holes and pull the grille away from the speaker. To remove the

grille completely, disconnect the monofilament tether from the speaker baffle.

Set the Transformer Tap Selector Switches

The speakers are equipped with a 70V/100V matching transformer for distributed audio

systems. The transformer tap selector switch on the front panel is used to set the speaker

power level. Use a flat-head screwdriver to adjust the switch.

• For SAROS_PD4T 70V systems, use the left-side settings and select from 1.88, 3.75,

7.5, 15, or 30 watts.

• For SAROS_PD4T 100V systems, use the right-side settings and select from 3.75,

7.5, 15, or 30 watts. The X position should not be used.

• For SAROS_PD6T, SAROS_PD8T and SAROS_PDS8T 70V systems, use the

left-side settings and select from 3.75, 7.5, 15, 30, or 60 watts.

• For SAROS_PD6T, SAROS_PD8T and SAROS_PDS8T 100V systems, use the

right-side settings and select from 7.5, 15, 30, or 60 watts. The X position should not

be used.

The switch may also be set to 8 Ω operation, bypassing the transformer completely. This

setting should be used only for 8 Ω audio systems.

QUICKSTART DOC. 7488B (2037418) 10.15

1Installation

Saros® speakers by Crestron® deliver professional grade

performance and flexible installation in a range of popular

sizes for demanding commercial applications. Solid

construction and high-end components are hallmarks of the

complete Saros speaker line.

Ideal for use in background or foreground music, paging,

and sound reinforcement systems, Saros speakers are

engineered to achieve smooth, even coverage, high output,

and clear, natural sound quality through the employment of

horn-loaded titanium dome tweeters, high-efficiency

damped cone woofers, ported enclosures, and precisely

tuned crossovers.

Front View - Grille Removed

Install Speaker Cable

Observe all local codes and install speaker cable from the audio source location to the

closest ceiling truss location where a speaker will be suspended, allowing sufficient length to

hang down slightly below the planned speaker height. If the speakers are to be connected in

parallel, install a second cable at that location and route it to the next speaker location.

Repeat this process at each speaker location.

Install Wire Rope

1. For each speaker to be installed, remove the top cover and route

the free end of one of the 15 ft (~5m) wire ropes supplied in the

SPKA-ST-15 Safety Tether/Tie Down Kit up through the top cover.

Connect the attached hook assembly to secure the wire rope to the

speaker rigging point.

2. Attach the free end of the wire rope to the ceiling truss, adjust the

length so the speaker is at the desired height, and secure it using

the supplied Gripple® wire rope grip. (Refer to the supplied

instructions for proper use of the Gripple.)

1. Refer to the illustration to the right, with the top cover off to expose the supplied

terminal block.

2. At each speaker location, route the speaker cable(s) hanging from the ceiling area

through the top cover, and dress the cables to the wire rope using plastic cable ties.

3. If using a supplied weather boot, slide the speaker cables through the weather boot.

Strip the ends of the cables approximately 1/8" to 3/16" (~3 mm to ~5 mm) and, if the

wire is stranded, twist the strands.

4. Connect the wires from the amplifier (or the previous speaker) to the supplied terminal

block, using the IN terminals; red to + and black to –. Use the THRU + and – terminals

to connect the speaker wires to the next (parallel) speaker.

5. Speaker removal is accomplished by reversing steps 1 through 4 above.

Paint the Speaker and Grille

Speaker and grille painting should be done prior to mounting.

1. Carefully remove the material on the underside of the grille, and set it aside for

reinstallation. It may be necessary to use a knife or other sharp instrument to free an

edge of the material so it can be peeled away. Use care to avoid cutting or tearing the

material.

2. Dry brush or lightly spray the surface to be painted. Use care to avoid clogging the

holes in the grille.

3. Once the paint is dry, reinstall the material to the underside.

4. Remove the speaker top cover and paint the top cover and main speaker assembly

separately, being careful to mask areas that should not be painted.

100V

70V

For SAROS_PD6T/PD8T/PDS8T

100V70V

For SAROS_PD4T

100V70V

THRU

Terminal

Block

Connect Speaker Cables

Speaker

Cables

Top

Cover

Speaker

Rigging Point

(Wire Rope Not

Shown)

Speaker

Rigging Point

Connect or Disconnect Speakers

NOTE: If the speakers are to be connected in parallel, the sum of the power settings

for all speakers must be less than the power amplifier’s power/channel rating.

Attach grille safety

tether with supplied

screw. Cover screw

with supplied rubber

plug.

Saros Pendant speakers include a top cover that conceals the wiring connections and suspension

hardware for a very clean, contoured appearance. The speakers are available in white or black and can

be painted to blend with the surrounding architecture.

Saros® Pendant Speakers

quickstart guide

SAROS_PD4T/PD6T/PD8T/PDS8T

www.crestron.com

Specifications subject to

change without notice.

SAROS_PD4T/PD6T/PD8T/PDSS8T

The specific patents that cover crestron products are listed at patents.crestron.com.

Certain Crestron products contain open source software. For specific information, please visit

www.crestron.com/opensource.

Crestron, the Crestron logo, and Saros are either trademarks or registered trademarks of Crestron

Electronics, Inc. in the United States and/or other countries. Gripple is either a trademark or

registered trademark of Gripple Limited in the United States and/or other countries. Other trademarks,

registered trademarks, and trade names may be used in this document to refer to either the entities

claiming the marks and names or their products. Crestron disclaims any proprietary interest in the

marks and names of others. Crestron is not responsible for errors in typography or photography.

This document was writtren by the Technical Publications department at Crestron.

QUICKSTART DOC. 7488B (2037418) 10.15

3Specifications

SPECIFICATION

SAROS_PD4T, PD6T, PD8T, PDS8T

SAROS PD4T SAROS_PD6T_SAROS_PD8T The following table provides corrective action for possible trouble situations.

If further assistance is required, please contact a Crestron customer service

representative.

Further Inquiries

To locate specific information or resolve questions after reviewing this

guide, contact Crestron's True Blue Support at 1-888-CRESTRON

[1-888-273-7876] or, for assistance within a particular geographic region,

refer to the listing of Crestron worldwide offices at www.crestron.com/offices.

To post a question about Crestron products, log onto Crestron’s Online Help

at www.crestron.com/onlinehelp. First-time users must establish a user

account to fully benefit from all available features.

Future Updates

As Crestron improves functions, adds new features, and extends the

capabilities of the SAROS_PD4T/PD6T/PD8T/PDS8T, additional

information may be made available as manual updates. These updates

are solely electronic and serve as intermediary supplements prior to the

release of a complete technical documentation revision.

Check the Crestron website periodically for manual update availability

and its relevance. Updates are identified as an “Addendum” in the

Download column.

TROUBLE

POSSIBLE CAUSE(S)

CORRECTIVE ACTION

No sound or

intermittent

sound is

coming from

the speakers.

There is a cable

connection error.

Verify the cable connections

between the amplifier and

speakers.

The amplifier is not

receiving an input signal,

or there is a malfunction.

Verify that the amplifier is

functioning correctly, that it is

receiving an input signal, and

that the correct input source

is selected.

Verify that all devices in

system are functioning

properly.

Verify system grounding.

Verify speaker connection

polarity ( on amplifier to + +

on speaker).

4Problem Solving

Troubleshooting

2Physical Views

Rear and Side View (Typical)

TH RU

Recommended

Cutout Diameter

Diameter

Minimum

Mounting Depth

Front View - Grille Removed (Typical)

Connections

Input 4-pin 5 mm detachable terminal block with screw-down flanges;

Speaker input with parallel pass-through;

Maximum wire size: 12 AWG

Controls

Transformer Tap Recessed 5-position screwdriver-adjustable rotary switch on baffle;

Used to select 70/100V tap settings or 8 Ω (bypass)

Environmental

Temperature -2° to 120° F (-19° to 49° C)

Humidity 5% to 95% RH (non-condensing)

Splash Resistance IPx4 rated per IEC 60529

100V70V

8.0 in (203 mm)

polypropylene with ring

mode decoupled cloth

surround and steel basket

0.98 in (25 mm) titanium

dome, horn-loaded

2.5 kHz

8 Ω nominal with

transformer set to 8Ω

3.75, 7.5, 15, 30, 60 watts

at 70 V; 7.5, 15, 30, 60

watts at 100 V

50 Hz to 20 kHz (±3 dB)

40 Hz to 20 kHz (-10 dB)

50 watts program, (8 Ω)

90 dB @ (1W/1m)

95° conical (nominal)

6.5 in (165 mm)

polypropylene with ring

mode decoupled cloth

surround and steel basket

0.98 in (25 mm) titanium

dome, horn-loaded

2.5 kHz

8 Ω nominal with

transformer set to 8Ω

3.75, 7.5, 15, 30, 60 watts

at 70 V; 7.5, 15, 30, 60

watts at 100 V

55 Hz to 20 kHz (±3 dB)

45 Hz to 20 kHz (-10 dB)

50 watts program (8 Ω)

88 dB @ (1W/1m)

90° conical (nominal)

4.0 in (102 mm)

polypropylene with ring

mode decoupled cloth

surround and steel basket

0.79 in (20 mm) titanium

dome, horn-loaded

2.0 kHz

8 Ω nominal with

transformer set to 8Ω

1.875, 3.75, 7.5, 15, 30

watts at 70 V; 3.75, 7.5,

15, 30 watts at 100 V

60 Hz to 20 kHz (±3 dB)

45 Hz to 20 kHz (-10 dB)

50 watts program, (8 Ω)

85.0 dB @ (1W/1m)

90° conical (nominal)

Woofer

Tweeter

Crossover Frequency

Impedance

Transformer Taps

Frequency Response

Frequency Range

Power Handling

Sensitivity

Coverage

8.0 in (203 mm)

polypropylene with rubber

surround steel basket and

phase plug

N/A

8 Ω nominal with

transformer set to 8Ω

3.75, 7.5, 15, 30, 60 watts

at 70 V; 7.5, 15, 30, 60

watts at 100 V

45 Hz to 125 Hz (±3 dB)

35 Hz to 125 Hz (-10 dB)

100 watts program, (8 Ω)

90 dB @ (1W/1m)

N/A

SAROS_PDS8T

There is a faulty device in

the system.

There is a system

grounding fault.

There is an incorrect

polarity connection at the

speaker or amplifier.

Constant noise

such as buzz,

hum, or hiss is

coming from

the speakers.

Poor low

frequency

output.

Construction

Enclosure Glass fiber reinforced ABS plastic, textured finish, paintable, removable top cover

Baffle Glass fiber reinforced ABS plastic

Grille Steel with textured finish, paintable, magnetically held, zero-bezel frameless, safety tether

Mounting Single rigging point beneath top cover for suspension; Gripple 15 ft (4.57 m) wire rope (aka, aircraft cable) with

attached snap hook and self-locking wire rope grip included

8.33 in (212 mm)

9.02 in (223 mm)

7.0 lb (3.2 kg)

Dimensions

Height

Diameter

Weight

10.49 in (267 mm)

11.07 in (282 mm)

9.8 lb (4.5 kg)

10.58 in (269 mm)

12.57 in (320 mm)

11.1 lb (5.1 kg)

10.58 in (269 mm)

12.57 in (320 mm)

13.1 lb (6.0 kg)

Product specificaties

Merk:	Crestron
Categorie:	Speaker
Model:	Saros PD8T-B-T-EACH

Heb je hulp nodig?

Als je hulp nodig hebt met Crestron Saros PD8T-B-T-EACH stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Speaker Crestron

Crestron ULTIMATE IC3-SA-WOOFER Handleiding

27 December 2023

Crestron ULTIMATE IC3-AW-SA-BOX-WOOFER Handleiding

27 December 2023

Crestron ULTIMATE IC3-AW-SA-TWEETER Handleiding

27 December 2023

Crestron ULTIMATE IWS82-AW-W-T-EACH Handleiding

6 September 2023

Crestron ULTIMATE IWLCR62-W-T-EACH Handleiding

6 September 2023

Crestron SAROS IC8T-W-T-EACH Handleiding

30 Augustus 2023

Crestron ULTIMATE ICS8-AW-W-T-EACH Handleiding

30 Augustus 2023

Crestron ULTIMATE IC8-DT-AW-W-T-EACH Handleiding

30 Augustus 2023

Crestron SAROS ICT5T-22 Handleiding

30 Augustus 2023

Crestron ULTIMATE IC6-AW-W-T-EACH Handleiding

30 Augustus 2023

Handleiding Speaker

Nieuwste handleidingen voor Speaker

Extron SM 28 Handleiding

21 November 2024

JBL RM10 Handleiding

20 November 2024

JBL Performance IS6 Handleiding

20 November 2024

JBL Power P-Kit Handleiding

20 November 2024

JBL Performance P941 Handleiding

20 November 2024

JBL Performance P52OWS Handleiding

20 November 2024

JBL Performance PC600 Handleiding

20 November 2024

JBL Performance IS6DT Handleiding

20 November 2024

JBL Performance IS8 Handleiding

20 November 2024

JBL Performance IS5 Handleiding

20 November 2024
