Candy CS C8LF-80 Handleiding

Candy Wasdroger CS C8LF-80

Lees hieronder de 📖 handleiding in het Nederlandse voor Candy CS C8LF-80 (11 pagina's) in de categorie Wasdroger. Deze handleiding was nuttig voor 70 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/11

Do not install the product in a

low temperature room or in a

room where there is a risk of frost

occurring. At temperature around

freezing point the product may

not be able to operate properly:

there is a risk of damage if the

water is allowed to freeze in the

hydraulic circuit (valves, hoses,

pumps). For a better product

performance the ambient room

temperature must be between

5-35°C. Please note that

operating in cold condition

(between +2 and +5°C) might

simply some water condensation

and water drops on floor.

Check frequently the fluff filter

after use, and clean, if

necessary.

Prevent items from falling or

collecting behind the dryer as

these may obstruct the air inlet

and outlet

NEVER install the dryer up

against curtains.

In cases where the dryer is

installed on top of a washing

machine, a suitable stacking kit

must be used according to the

follow configuration.

Stacking kit Mod 35100019: for

minimum washing machine

depth 49 cm

Stacking kit Mod 35900120: for

minimum washing machine

depth 51 cm

The stacking kit shall be one of

that above, obtainable from our

spare service.

The instructions for installation

and any fixing attachments,

are provided with the staking

kit.

●

DRAIN HOSE : FITTING INSTRUCTIONS

FOR TANK IN DOOR DRAWER

To avoid emptying the water container after

each drying cycle, the water can be discharged

directly to a waste water drain pipe (the same

drainage system as household sinks). Water

Bye-Laws prohibit connection to a surface

water drain. The waste water drain pipe should

be located adjacent to the tumble dryer.

The kit consists of:1 hose and 1 tap.

tumble dryer plug from the electricity supply

before carrying out any work.

Fit he s Follows:t Hose a

1.Tilt the machine

backwards.

2. The waste water

pipe is situated at the

right-hand side of the

machine (see the

picture). A grey hose

connects to the bridge

at the left hand side of

the machine. Using

pliers, remove the

pipe retaining clip

from the bridge.

3. Pull the hose off the

bridge connection.

4. Attach the black

hose from the kit,

( using the connector

a n d p i p e c l i p s

supplied , to the hose )

removed from the

bridge connection.

5 . P l a c e t h e t a p

supplied by the kit to

close the remaing

hose.

Connect the new drain

hose to the waste

black w ater pipe .

6. Once the machine is

in place, check the

bottom to ensure that

the new hose does not

kink when pushing the

tum bl e drye r int o

position.

Connect to the mains

electricity supply.

WARNING

water kit is suitable only on models with the

water tank on the door.

NOTE:

The direct drain condensed

Switch off and remove the

Product specificaties

Merk:	Candy
Categorie:	Wasdroger
Model:	CS C8LF-80
Apparaatplaatsing:	Vrijstaand
Soort bediening:	Buttons, Rotary
Kleur van het product:	Wit
Deurscharnieren:	Links
Ingebouwd display:	Nee
Warmtebron:	Electrisch
Gewicht:	32300 g
Breedte:	596 mm
Diepte:	585 mm
Hoogte:	850 mm
Type stekker:	Type G
Type lader:	Voorbelading
Droogsysteem:	Condensatie
Deurstijl:	Ondoorzichtige deur
Deurkleur:	Wit
Materiaal trommel:	Gegalvaniseerd
Trommelinhoud:	115 l
Uitgestelde start timer:	Ja
Startvertraging:	24 uur
Wi-Fi-besturing:	Nee
Aantal droogprogramma's:	16
Droogklasse:	C
Duur cyclus:	157 min
Geluidsniveau:	69 dB
Vochtsensor:	Ja
Energie-efficiëntieklasse:	B
Energie consumptie:	4.7 kWu
Jaarlijks energieverbruik:	561 kWu
Gewicht verpakking:	33800 g
Breedte verpakking:	650 mm
Diepte verpakking:	620 mm
Hoogte verpakking:	890 mm
Near Field Communication (NFC):	Ja
Verstelbare voeten:	Ja
Gebruiksklaar-indicatielampje:	Ja
Certificering:	Woolmark
Smartphone ondersteuning op afstand:	Ja
Bedieningsapps ondersteund:	Candy simply-Fi
LED programmavoortgangsindicator:	Ja
Energieverbruik per cyclus (gedeeltelijke belasting):	2.56 kWu
Water reservoir locatie:	Bodem
Droogrek inbegrepen:	Nee
Nominale capaciteit:	8 kg
AC-ingangsspanning:	220 - 240 V
Energie-efficiëntieschaal:	A+++ tot D
Uitgang waterslang:	Nee
