Pagina 1/6
Other functionsCautionsCautions
FULLY AUTOMATIC WASHING MACHINE
Operation Manual
It is most important that this instruction book should be retained with the
appliance for future reference. Should the appliance be sold or transferred
to another owner, or should you move house and leave the appliance, always
ensure the book is supplied with the appliance in order that the new owner
can get to know the functioning of the appliance and the relevant warnings.
These warnings have been provided in the interest of safety. You must read
them carefully before installing or using the appliance.
12.0kg
WTL120G
Use of detergent
S f tpeci ica ion
Weight
220-240V~ 50Hz
Rated voltage and
frequency
Rated capacity of wash
and spin
Water level/water volume
( )about
Inlet pressure
WTL120GModel
Rated input power
Product Dimensions
Wash 540W ：
spin 560W：
0.05MPa-0.85MPa
12.0kg
10/80L 9/75L 8/70L 7/65L
6/60L 5/55L 4/50L 3/45L
2/41L 1/37L
About 43kg
W600mm D622mm H970mm
Please insert the plug into the power socket
with rated voltage 240V A/C.
Do not make the electric cable bended,
stretched, twisted, strapped or changed,
pressed or nipped. If the supply cord is
damaged, it must be replaced by the
manufacturer,its service agent or similarly
qualified persons in order to avoid a
hazard. The pin of the
plug must remain clean.
Please clean it carefully
with dry cloth if it is dirty.
Do not use water hotter than 50℃
Ventilation holes
at the bottom
Soft item
Do not share the same socket with other electric
appliances. Do not use the damaged plug or loose
socket.
Warning
Symbol definition
Always unplug the appliance and turn off
the water when the power is cut, moving or
cleaning the washing machine, or it is not in
use. Do not insert or pull off the plug with
wet hand.
Do not wash raincoat, bike cover, feather
dress and waterproof laundries, which will
caused the washing machine to have
abnormal vibrations during spinning.
If the machine is situated on a carpeted
floor, please adjust the feet in order to allow
air to circulate freely.
Forbidden
Pay special attention to the
warning symbols. There may be
serious risks to personal body
safety or damages to the washing
machine if not follow.
Please stop doing the contents with
this symbol, otherwise it will damage
the appliance or injure your personal
body.
Do not put hands into the working machine.
It is dangerous even if the speed is very slow.
Take special care of the children, and forbid
them to climb on the washing machine.
It is dangerous to alter the specifications or
attempt to modify this product in any way.
Do not overload the appliance or put any
hotgoods(such as the kettle with hot water)
on thewashing machine.
Garments which have been in contact with
volatile petroleum products should not be
machine washed.
Keep the appliance away from direct
sunlight and heat sources like the heater.
This appliance is not intended for use by
persons(including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that
they do not play with the appliance.
Preparation before operation
Preparation before washing
1. Connect the inlet hose and open the tap.
2. This appliance must be earthed. Confirm
the socket is earthed reliably and insert the
power plug. The earth terminal should not
link to gas pipeline, tap pipeline etc.
3. Hang up the drainpipe.
Warning: the temperature of the water should be less than 50℃！
Before washing the laundries, please pay attention to the
followings:
Make sure if
there is special
requirements for
the laundries
Before washing,
empty all pockets of
small objects which
may have been left
inside(coins, keys,
screws etc.).
Knot the long
band, fasten the
buttons and close
the zippers.
Do not overload
the machine.
Load the laundry
loosely alternating
large items with
small ones.
Sort the laundry
according to the
type of fabric,
color-fastness and
how dirty it is. Put
thin laundries,
woolens and such
prone to wear and
tear laundries into
washing bag.
A. Make sure the laundries are washable.
B. It is essential to wash new colored items separately when washing for the first time. White
items should not be washed with colored items.
C. Please immerge the non-absorbable laundries by hand.
D. Some stains such as fruit, wine, grass, rust etc. are difficult to remove and should be treated
before washing with specific products, which can be found in most household shops.
In some cases it may help to soak the stain before washing with a special pre-soak product
or biological detergent.
E. Overturn the nap fabric and long floss laundries before putting them into the machine.
F. Do not put the laundries polluted by chemicals into the machine directly.
G.Very small item(handkerchiefs, ribbons, socks etc) should be washed in a washing bag or a
pillow case.
Load laundries
The capacity of washing and spinning of the machine is refer
to the largest weight of the standard laundries under dry
condition. Washing quantity shall be lower than the rated
capacity. The maximum capacity of this machine is 12.0kg.
Different thickness, size and type of the laundries will
influence the actual washing capacity.
Do not select high water level when laundries are less than
1.5kg to avoid water splashing.
Remarks avoid splashing of water and waste of washing powder, water level should not ：
be too high if laundries are too small.
Error Code Error Code explanation Solution
E1 After draining for 5 minutes,it still
does not reach to the minimum
of water level
Please refer to Page 8 for troubleshooting
E0 The top lid is opened
when preset is started Close the top lid and clear the alarm
E2 The top lid open when spinning Close the top lid and clear the alarm
E4 After inflow of water for 20
minute, it still does not reach to
the water level set
Please refer to Page 8 for troubleshooting
E3 Spin is not balance Open the top lid, place the laundries equally,
then close it and clear the alarm
E5
F1
The top lid is opened after setting
child-lock C lose the top lid and cl ear the al a rm
Water Level sensor is abnormal Cut off the power supply to find a professional
staff to process
Notice if there is still fault after check above items, please remove the plug from power supply :
and contact with local service team
Fault explanation
Detergent box
How to use bl ace h How to use the washing powder
Dissolve in the machine directly not suitable （
for preset program）
1. Low water level.
2. Add the washing powder, and run for 30
seconds to dissolve it completely.
3. Put laundries in and select suitable water
level.
The instant dissolving of the washing powder
1. Prepare warm water of 30 in a container.℃
2. Pour the powder while stirring to fully
dissolve it.
Washing powder with poor quality or not used
for a long period may get blocked, please clean
the detergent box in time.
Withdraw the dispenser box before adding
detergent
Pour concentrated synthetic washing powder
into the box directly as shown in the left
illustration.
The dosage of the washing powder, please
refer to below.
It is suggested to use low sud washing powder.
Fill water to the selected level,
dilute the bleach in the container,
and pour it slowly into the washing
tub.
Do not use bleach for colored or
figured laundries as they are prone
to lose colors.
Do not put bleach to laundries
directly.
Refer to the manual for the usage
and quantity of the bleach.
Please dissolve powder bleach
before use.
Before washing, please ensure the tap is
openand the inlet hose is installed properly.
It is suggested to use low foam washing
powder.
Any objects such as coins, safety pins, nails,
screws, stones or any other hard, sharp
material can cause extensive
damage and must not be
placed into the machine.
To prevent the lint from blocking cascade
outlet during washing, please keep the lint
filter in good condition, install it to proper
position and clean it in time.
Dismantle Fit on
Don t install the washing machine in
bathroom or damp places. Do not wash the
machine with water, do not put wet clothes
on the control panel film.
this machine has two feed valves ,when you use
only one feed valve, must put the inlet cap on
the other feed valve.
Inlet cap
Notice:
1.Imbalance adjustment:
During spinning, if the laundries are not placed equally in the tub, it would cause Violent
vibration. This machine has imbalance adjustment function, and the vibration testing system
will supervise the running. Once vibration is beyond certain level, the adjustment system will
start automatically to adjust the imbalance.
2.Power supply is cut off automatically:
1) If you did not start the program in 10 minutes after pressing the power supply button, the
power supply will be cut off automatically.
2) After the washing is finished, alarm buzzes and the power supply will cut off automatically.
3.Child lock function:
1)When child lock function is set, all the buttons will be locked including POWER. If the top lid
is opened during the washing machine working, the washing will be stopped and give an alarm.
But if you can close the top lid in 5 seconds, the alarm will stop and the washing machine will
continue working. If cannot close the top lid in 5 seconds, the washing machine will begin
draining if there is water in the inner tub, even closing the top lid is not valid. During the
draining, alarm will buzz every 10 seconds, when the water in the inner tub is about 5cm
higher, alarm will buzz every 10 minutes.When the draining is finished, the washing machine
will be in the state of waiting, if close the top lid, the washing machine is unlocked and start
working as previous setting.
2)Once child lock is set, if top lid is opened over 5 seconds during washing or rinse(there is
water in the inner tub), washing machine will drain and alarm will buzz. If you unlock the
function during draining, the washing machine will add water to water level set and continue
working.
4.Water recycle function
When water recycle function is set, after the last rinse finished, the washing machine will not drain
and spin.SPIN and WATER RECYCLE indicator light will be flashing and alarm will be given,the
washing machine will stop working (if nobody operate, the alarm will be given every 10 minutes,
in 1 hour, power supply will be cut off automatically). When press START/PAUSE, WATER
RECYCLE indicator light is on and the washing machine begin to drain and spin, the user can
reuse the water.
Water inlet installation
Maintenance
Maintenance methods
Parts name
How to use drainpipe
Installation and adjustment
P se lea ins all and adjus het t t machine cording ac to the requirements o . f the manual
Correc opera iont t is y ver impor ant t for your safety.
Unp ingack
Unpack the c ton ar and take out the bottom c r.ove
O n the top pe lid of wa his ng ma hinc e and take out all of the a s es.cces ori
Remove all wrappers, in ludic ng the pol yreyst ne base.
You are advised to k p ee all the pa agick ng for reuse in c the ase ma hic ne is to be
t s ted ran por again.
Pos ngitioni
The di anst ce be weet n the wa his ng ma hinc e and the wall should be t n more ha 50mm,
and t x m he ma imu allowed angle of the shank base he of t machine is 1°.
The s t g lan in or rough ground ma ausy c e operating st ed opp or uns ablt e, please adjust it
with the f ing tollow me hods:
Hori onz tal c ingheck
Obs ve the er water bubble in bala innc g apparatus
is in red c e or ircl not. In red c cleir , it is horizontal.
A st the t le footdju adjus ab
1) Li ft up the adj abust le f oot gently, loose the adju ablst e nut
t st the and wi adj abust le f .oot
2) Fasten the nut a er ft adj menust t.
3) Set the machine flat, and observe again. If the water
bubble is not in red circle, repeat the above procedure,
till the water bubble is in red circle.
Installing the bo om co rtt ve
Le het t back of washing ma hinc e c ein lin forward,
make the side of ttbo om cover wi th ick st er des rip ionc t
bac wak to shing ma hinc e, in ers t to the bo om tt of
washin maching e galon the ct odire ion f arrow.
Remove two fixing clamp by scissors, insert to the
accordingly holes black lines indicating ( gently pull
fixing clamp should not be pulled out ), make the
bottom cover fixed on the base.
1°
A e dju ablst nut
A e dju ablst
foot
Fixing clampScissors
Bottom cover
The base
Troubleshooting
Notes If there is still a fault after the above checks, please pull out the plug and ：
contact the seller right away. It is dangerous to repair this product by
yourself.
Normal
Normal
Close the top lid
Close the top lid
Control panel has
no display
Plug is not inserted tightly
No electricity in the socket
Power switch is not turned on
Power supply is cut off
Inlet hose leaks
Inlet hose connector(connecting
with the tap)is not fixed tightly
Inlet hose and washing machine
connector is loose
Before contacting the technicians, please make the following checks:
Phenomena Possible reason
It does not drain
Water outlet of drainpipe is higher
than 1.2m
Drainpipe is bended or get blocked
No inflow of water
No water supply
Tap is not open
Inlet hose gets blocked
Spin stops and
water inflow begins
during spin program
Laundries is too much or too little
or the Machine is not place stably
Press the program
button to select
SPIN, but It does
not spin
Top lid was not closed when drain
is finished
Top lid was open when drain is
started
The spin is intermittent
when spin starts
Balance the laundries to reach to
the best spin effect
First time use, some
water flows out from
the drainpipe
The remaining water from factory’s
testing
Insert the plug tightly
Check the socket or change to
another socket
Press power switch
Check power supply
Install the inlet hose again
Tighten the connector of the
machine
The height of the drainpipe
should be less than 1.2m
Straighten or clean the drainpipe
Restart when water supply is
resumed
Open the tap
Clean the filter according to
before“clean inlet gate”
The machine is adjusting
automatically
Troubieshooting
Bottom cover
(1pc)
Accessories
1. After using the machine, you are advised to turn off the water taps. (if necessary, pull out
the inlet hose).
2. Do not keep water in tub for a long time. When washing is finished, drain it right away.
3. Once you have finished using the machine, you are advised to unplug it.
4. Put the electric cable and the drain hose in order.
5. Wipe the water on the surface and in the tub with soft cloth and keep the top lid opening for a
while. It helps to prevent mold and smell forming inside the appliance.
If the water in the inner tub has possibility to freeze, please do like below:
1. In winter, if remaining water freeze can cause the washing machine trouble, please take off the
water inlet hose and drain out the water in the hose and inner tub.
2. If the water freeze, please don't operate the washing machine. Put 40 hot water in the tub, ℃
the hot water should submerge the pulsator, after a few minutes, rotate the pulsator by hand
gently, then you can operate the washing machine.
Control panel instructionsControl panel instructions
After the end of the programme Clean the lint filter
Clean the lint filter
The machine stops automatically, and
music buzzer will remind you to take out
the laundries or start again.
Once you have finished using the machine,
you are advised to unplug it and turn off the
water taps to avoid unexpected leak or fire.
External cleanin g
Clean the exterior cabinet of the appliance with
soft cloth. Do not use cleanser, volatile chemical
materials to clean the machine, which will
damage plastic parts and the surface.
It is necessary to use lint filter during
washing.
After washing, please clean the lint
filter in time.
Clean the lint filter according
to the following steps:
1. Pull out the lint filter.
2. Turn the filter net inside out
and wash it.
3. Reverse back the filter net
and remount it.
1. pull out magic filter
2. open the box and clean it
3. close it and reinstall it
4. check if the lint block part is in good
condition
Magic filter cleaning
press this part and pull out to take
out the magic filter
lint block part (black rubber)
It is possible that the inlet filter net can be blocked by
the dust, please clean it according to the following
steps:
1. Close the tap and turn on the power switch.
2. Start the washing machine for 5 seconds(make
the water in the inlet hose flows to the tub), and
cut off the power supply.
3. Pull off the inlet hose, remove and clean the inlet
valve and the inlet net, and install again.
Groove
Drainpipe
Top lid Hot Water inlet valve
Cold Water inlet valve
Power cord
Back cover
Foot wheel ( 2pcs )
Fixing foot ( 2pcs )
Top frame
Detergent box
Lint filter
Control panel
Inner tub
Pulsator
balancing
apparatus
Body
Base
Adjustable foot
1.the drainpipe must be hanged during use, the height is
not more than 1.2m to avoid leakage or stop, if drain a
long time, the machine will stop running.
2.You can adjust the situation of the elbow bend pipe to
change the height of the drainpipe.
3.Do not extrude the drainpipe to ensue drain smoothly.
Drainpipe
Elbow
Less than 1.2 m
Cautions:When install the washing machine, please use the new hose assy along with
the washing machine, old hose assy can not reuse.
Tap selection
Check the connection between inlet
hose connector and the tap
Connect the inlet hose with the washing machine
1. Swing the inlet hose gently to confirm if it is
fastened.
2. After installation,open the tap and check if
it leaks.
3. Do not bend the inlet hose with overstrain.
4. Before each usage,check the connection
between inlet hose connector and the tap.
Make sure they are firmly fitted to prevent
dropping from improper installation position.
1. Do not take off the water absorption cushion. Please
check if the cushion is dropped or damaged before
each usage. If it is, contact the seller immediately.
2. Put the inlet hose nut on the inlet valve connector.
3. Fasten the inlet hose nut and swing it gently to make
sure if it is suitable.
Inlet valve connector
Inlet hose nut
Water absorption cushion
Suitable tap
The front end should be longer than 10mm. The tap exit end
face should be flat and smooth, if not file it to avoid leakage.
Not suitable tap
At the beginning of start, pressing WATER LEVEL, at the same time press
PRESET, you can select WATER RECYCLE, LOW NOISE, LOW NOISE-WATER
RECYCLE. Only both RINSE and SPIN are selected, WATER RECYCLE can be
selected. Once LOW NOISE is selected, program default setting is NORMAL and
PROGRAM button is locked.
During working, press WATER LEVEL and PRESET to set CHILD LOCK, press
again to unlock this function.
Before washing, the Digital Timer shows the set time, unit is Hour.
If selecting AIR DRY, the Digtal Timer displays air dry time, unit is
Minutes.
When washing, the Digital Timer shows the remaining time of
washing, unit is Minutes
When trouble encountered, the Digital Timer shows trouble code.
When it is ON and if with Fuzzy logic,the Digital Timer shows "--".
To switch on the Washing Machine to working state or waiting state.
Select one program form NORMAL, HEAVY, SOFT, STANDARD, FAST, WOOL,
CHILD, FOAM CLEAN, TUB CLEAN and AIR DRY.
If choose "STANDARD" program, the wash time is "9 minutes", spin times is "2",
spin time is "5 minutes", you can cancel one of the process .
If choose "FAST" program, the wash time is "9 minutes", spin times is "1", spin time
is"3 minutes", you can cancel one of the process (but if you choose "SOAK", the
wash time can not be cancelled)
If no selection is selected, the process will start with the NORMAL program when the
"START/PAUSE" button is pressed.
After selecting the PROGRAM, PROCESS and WATER LEVEL, press this button
to start. Press this button to pause during working, press again to continue.
Press "TEMP SELECT" to select "HOT" "COLD" or "WARM" water for wash.、
During the rinse process, it will inlet cold water.
At the beginning of start, if with FUZZY logic and do not select water level, the
digital timer shows "- -". At this time, before press START/PAUSE, If select
NORMAL or HEAVY, with fuzzy logic. When select STANDARD, no fuzzy logic,
the water levelis "10" When select FAST, no fuzzy logic, water level is "2". If no ；
WASH process, no fuzzy logic.
At the beginning of start, press WATER LEVEL to select water level, at this time,
no fuzzy logic function, you can select appropriate water level. According to your
laundries quantity.1-2 is low water level, 3-6 is middle water level,7-10 is high
water level.
During wash (including rinse), if need to add water, press WATER LEVEL button
to add water, un-press will stop adding. Or PAUSE the washing machine and
press WATER LEVEL to select higher water level, then press START/PAUSE
button, The washing machine Will add the water to setting level automatically and
continue working. If your resetting water level is lower than present water level,
the lower water Level will valid in next water inlet.
Automatically add water: during SOAK, WASH and RINSE process, if the washing
machine check the water level is lower than setting water level, The washing
machinewill pause and add water to setting water level automatically.
DIY (Do it yoursef) program---- you can set spin time.
At the beginning of start, the spin time setting is "7 minutes".
At the beginning of start, you can press "SPIN" to set spin process only, press
"SPIN" again to set spin time.
DIY (Do it yoursef) program---- you can set rinse times.
At the beginning of start, the rinse times setting is "2 times".
DIY (Do it yoursef) program---- you can choose soak function and wash time.
Pressing "WASH" button for 2 seconds to choose soak function, pressing for 2
seconds again to cancel soak function.
Under "NORMAL", " HEAVY" programs to choose soak function, the soak is
before wash.
At the beginning of start, the wash time is "15 minutes".
Put through the power, press POWER button, the machine is in the state of beginning of start:
1.If there is no water in inner tub, washing machine is in " FUZZY" condition, washing time is
"15 minutes", rinse time is "2 times", spin time is "7 minutes", water level and preset are
displayed "--", program is "NORMAL" If press "START/APAUSE" button (or press
"PROGRAM" to select "HEAVY" ), the washing machine will start to sense and
automatically sense the weight of laundries and set water level.
2.If there is water in inner tub, the washing machine is not in "FUZZY" condition, washing time
is"15minutes", rinse time is "2 times", spin time is "7 minutes", water level is "7", program is
"NORMAL", digital time displays the time to finish washing.
At the beginning of start, press this button to select preset time from 2-24 hours.
If want to cancel preset time, press POWER to make the washing machine in
waiting state.
If need to select air dry, please press "PROGRAM" button to select airy dry, then
press this button to set air dry time.
Outfall stopper
(1pcs)
The end connect to
the appliance
Water inlet hose (2pc)
The end connect to
water inlet hose connector

Product specificaties

Merk: BEKO
Categorie: Wasmachine
Model: WTL120G

Heb je hulp nodig?

Als je hulp nodig hebt met BEKO WTL120G stel dan hieronder een vraag en andere gebruikers zullen je antwoorden


Handleiding Wasmachine BEKO

BEKO

BEKO BM1WFU37225WPB Handleiding

18 November 2024
BEKO

BEKO URBWU59AS Handleiding

18 November 2024
BEKO

BEKO WRE 7512 XSS Handleiding

15 November 2024
BEKO

BEKO BFLB1020W Handleiding

14 November 2024
BEKO

BEKO B3WFU48415WB2 Handleiding

10 November 2024
BEKO

BEKO B3WFU48415WBPB Handleiding

10 November 2024
BEKO

BEKO HITY 854310F Handleiding

5 November 2024
BEKO

BEKO WUE7746XW0 Handleiding

5 November 2024
BEKO

BEKO WUE6512BWW Handleiding

5 November 2024
BEKO

BEKO WUE6512XWST Handleiding

5 November 2024

Handleiding Wasmachine

Nieuwste handleidingen voor Wasmachine

Otsein

Otsein LB LTO129A Handleiding

21 November 2024
Otsein

Otsein LB LTO109A Handleiding

21 November 2024
Otsein-Hoover

Otsein-Hoover LB HV16ESALU Handleiding

21 November 2024
Sangiorgio

Sangiorgio ST6512EL Handleiding

21 November 2024
Sangiorgio

Sangiorgio FS614D9 Handleiding

21 November 2024
Sangiorgio

Sangiorgio PROGETTO F4 Handleiding

21 November 2024
Sangiorgio

Sangiorgio SG710 Handleiding

21 November 2024
Sangiorgio

Sangiorgio F814DIBC Handleiding

21 November 2024
Sangiorgio

Sangiorgio F812D Handleiding

21 November 2024
Sangiorgio

Sangiorgio F812L Handleiding

21 November 2024
