Asrock Z270M-ITX/ac Handleiding

Asrock Moederbord Z270M-ITX/ac

Lees hieronder de 📖 handleiding in het Nederlandse voor Asrock Z270M-ITX/ac (162 pagina's) in de categorie Moederbord. Deze handleiding was nuttig voor 29 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/162

Version 1.0

Published October 2016

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

English

Z270M-ITX/ac

PCIE1

DDR4_A1 (6 4 bit, 288-pi n modu le)

DDR4_B1 (6 4 bit, 288-pi n modu le)

CPU _FA N1

CHA _FA N1/W _P UMP

RoHS

Z c270M-ITX/a

US 2.B 0

T: 1USB

B: U SB 2

PS2

Ke ybo a rd

/M ou s e

18 17 16 15

AUDIO

CODEC

HD_AUDIO1

SPE AKER1

Intel

Z270

ATXPWR1

USB3 _ 6_7

HDMI2

PANEL 1

HDL ED RES ET

PLE D P WRBT N

TPMS 1

CI 1

HDMI1

DVI1

Top :

LINE IN

Center:

FRONT

Botto m:

MI C IN

SAT A3 _3

SAT A3 _2

CL RM OS1

SAT A3 _1

SAT A3 _0

USB _3_4

SAT A3 _5

SAT A3 _4

M2_1

C 4C 3C 2C 1T T T T

Top:

RJ-45

US 3.B 0

T: USB4

B: USB5

Top:

RJ-45

US 3.B 0

T: USB2

B: USB3

US 3.B 0

T: USB0

B: USB1

BIOS

ROM

M2_WIFI1

Motherboard Layout

Product specificaties

Merk:	Asrock
Categorie:	Moederbord
Model:	Z270M-ITX/ac
Breedte:	170 mm
Diepte:	170 mm
Gebruikershandleiding:	Ja
Bluetooth:	Ja
Wi-Fi-standaarden:	Wi-Fi 5 (802.11ac)
Bluetooth-versie:	4.0
USB-connectortype:	USB Type-A
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2160 Pixels
Type stroombron:	ATX
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	2
Aantal HDMI-poorten:	2
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	2
Hoofdtelefoonuitgangen:	1
Certificering:	FCC, CE, WHQL, ErP/EuP
HDCP:	Ja
DVI-D poorten:	1
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	6
Processor socket:	LGA 1151 (Socket H4)
Processorfabrikant:	Intel
Maximum intern geheugen:	32 GB
Intel® Smart Response Technology:	Ja
Intel® Turbo Boost Technology:	2.0
Intel® Quick Sync Video Technology:	Ja
Intel® InTru™ 3D Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® Insider™:	Ja
Audio-uitgangskanalen:	7.1 kanalen
Snelle installatiehandleiding:	Ja
ECC:	Ja
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	Intel® Z270
Trusted Platform Module (TPM):	Ja
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC892
Meegeleverde drivers:	Ja
Intel® Rapid Storage Technology:	Ja
Type koeling:	Passief
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	1
Intel® Optane™ Memory Ready:	Ja
PS/2 poort(en):	1
Component voor:	PC
LAN controller:	Intel I211, Intel I219V
Soorten RAID:	0, 1,5, 10
DirectX versie:	12.0
Aantal SATA III connectors:	6
Non-ECC:	Ja
Wake-on-LAN:	Ja
Compatibele processors:	Intel Celeron, Intel Pentium
Ondersteunde geheugen types:	DDR4-SDRAM
Max. aantal SMP-processoren:	1
Wifi:	Ja
Code geharmoniseerd systeem (HS):	84733020
Moederbord chipset familie:	Intel
Moederbord form factor:	mini ITX
Aantal geheugenslots:	2
Supported memory clock speeds:	2133,2400,2800,2933,3200,3600,3733 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	128 Mbit
ACPI version:	6.0
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	1
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
Aansluiting voor ventilator van voeding:	Ja
USB 2.0 aansluitingen:	1
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	CPU, FAN, Temperature, Voltage
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
Chassis intrusion aansluiting:	Ja
Intel® Rapid Storage Technology enterprise:	Ja
EPS power connector (8-pin):	Ja
Intel® Core i3/i5/i7/i9 series:	i3-6xxx, i5-6xxx, i7-6xxx
Discrete grafische ondersteuning:	Ja
Peripheral (Molex) power connectors (4-pin):	1
WiFi-AP antenna jack:	2
Dual Link DVI:	Ja
Intel® Extreme Memory Profile (XMP):	Ja
Aantal M.2 (M) slots:	1
12V vermogen-connector:	Ja
Audioconnector:	Ja
Intel® Quiet System Technology (QST):	Ja
