Version 1.0

Published July 2015

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

Product specificaties

Merk:	Asrock
Categorie:	Moederbord
Model:	Z170 OC Formula
Breedte:	305 mm
Diepte:	244 mm
Ethernet LAN:	Ja
Type stroombron:	ATX
Aantal USB 2.0-poorten:	2
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
Hoofdtelefoonuitgangen:	1
Certificering:	FCC, CE, WHQL, ErP/EuP
HDCP:	Ja
Duurzaamheidscertificaten:	RoHS
Aantal DisplayPorts:	1
Meegeleverde software:	ASRock Formula Drive, \nASRock Disk Health Report, \nASRock Fine-Tuning V-Controller, \nASRock Timing Configurator, \nASRock USB Key, \nASRock APP Charger, \nASRock XFast LAN, \nASRock XFast RAM, \nASRock Fast Boot
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	4
Processor socket:	LGA 1151 (Socket H4)
Processorfabrikant:	Intel
Maximum intern geheugen:	64 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	1
Audio-uitgangskanalen:	7.1 kanalen
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	Intel® Z170
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	1
DisplayPort versie:	1.2
Geheugen slots type:	DIMM
Meegeleverde drivers:	Ja
S/PDIF-uitgang:	Ja
Type koeling:	Actief
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	4
PCI Express x1 (Gen 3.x) slots:	1
Ondersteunde opslagstationinterfaces:	M.2, SATA, SATA III
PS/2 poort(en):	1
Component voor:	PC
LAN controller:	Intel® I219-V
Mini PCI Express slots:	1
Soorten RAID:	0, 1,5, 10
Aantal SATA III connectors:	10
Non-ECC:	Ja
Wake-on-LAN:	Ja
Compatibele processors:	Intel Celeron, Intel Pentium
Ondersteunde geheugen types:	DDR4-SDRAM
PCI Express x1 (Gen 2.x) slots:	1
Moederbord chipset familie:	Intel
Moederbord form factor:	ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	4500,4300,4400,4200,4266,2133,2400,2600,2666,2800,2933,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866,4000,4133 MHz
BIOS type:	UEFI AMI
ACPI version:	5.0
COM aansluitingen:	1
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	4
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
PC gezondheids monitor:	FAN, Temperature, Voltage
Niet gebufferd geheugen:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	2
TPM connector:	Ja
EPS power connector (8-pin):	Ja
Peripheral (Molex) power connectors (4-pin):	1
Intel® Extreme Memory Profile (XMP):	Ja
Aantal M.2 (M) slots:	3
Thunderbolt-headers:	2
Aantal SATA Express-connectors:	13
