Product specificaties

Merk:	Asrock
Categorie:	Moederbord
Model:	X570 Phantom Gaming-ITX/TB3
Breedte:	170 mm
Diepte:	170 mm
Bluetooth:	Ja
Wi-Fi-standaarden:	802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth-versie:	5.0
USB-connectortype:	USB Type-A, USB Type-C
Ethernet LAN:	Ja
Maximum resolutie:	4096 x 2160 Pixels
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
Hoofdtelefoonuitgangen:	3
Certificering:	FCC, CE, ErP/EuP ready
HDCP:	Ja
Aantal DisplayPorts:	1
Ondersteunt Windows:	Windows 10
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Processor socket:	Socket AM4
Processorfabrikant:	AMD
Maximum intern geheugen:	64 GB
Audio-uitgangskanalen:	7.1 kanalen
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C:	1
ECC:	Ja
Ethernet interface type:	Fast Ethernet, Gigabit Ethernet
Chipset moederbord:	AMD X570
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:	2
DisplayPort versie:	1.4
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC1220
S/PDIF-uitgang:	Ja
Type koeling:	Passief
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	2
Ondersteunde opslagstationinterfaces:	M.2, SATA III
PS/2 poort(en):	1
Hoeveelheid Thunderbolt ports:	1
Component voor:	PC
Geheugen voltage:	1.2 V
LAN controller:	Intel® I211-AT
Soorten RAID:	0, 1,10
Aantal SATA III connectors:	4
Non-ECC:	Ja
Wake-on-LAN:	Ja
Compatibele processors:	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Ondersteunde geheugen types:	DDR4-SDRAM
Wifi:	Ja
Code geharmoniseerd systeem (HS):	84733020
Ondersteunde types opslag-drives:	HDD & SSD
Moederbord chipset familie:	AMD
Moederbord form factor:	mini ITX
Aantal geheugenslots:	2
Supported memory clock speeds:	2133,2400,2667,2933,3200,3466,4133,4200,4266,4300,4400,4533 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	256 Mbit
ACPI version:	5.1
Ondersteuning voor parallel processing:	Niet ondersteund
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	1
ATX Power connector (24-pin):	Ja
Voorpaneel-connector:	Ja
Aansluiting voor ventilator van voeding:	Ja
USB 2.0 aansluitingen:	1
Aansluiting voor audiopaneel aan voorzijde:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
EPS power connector (8-pin):	Ja
Clear CMOS knop:	Ja
Discrete grafische ondersteuning:	Ja
Ondersteunde geheugenmodule capaciteiten:	4GB, 8GB, 16GB, 32GB
Supported processor sockets:	Socket AM4
Aantal M.2 (M) slots:	1
RGB LED-aansluitrail:	Ja
PCI Express x16 (Gen 4.x) sleuven:	1
Ondersteund processorsockets (koeler):	LGA 115x
UEFI-versie:	2.3.0
