Pagina 1/122

Version 1.0

Published October 2019

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see ww w.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

Product specificaties

Merk:	Asrock
Categorie:	Moederbord
Model:	X299 Creator
Breedte:	305 mm
Diepte:	244 mm
Productnaam:	X299 Creator
Gebruikershandleiding:	Ja
Bluetooth:	Ja
Wi-Fi-standaarden:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth-versie:	5.0
Ethernet LAN:	Ja
Type stroombron:	ATX
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	2
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	2
Hoofdtelefoonuitgangen:	1
Certificering:	FCC, CE, ErP/EuP ready
Aantal DisplayPorts:	2
Meegeleverde software:	ASRock Motherboard Utility (A-Tuning), ASRock \nPolychrome SYNC, ASRock XFast LAN, ASRock Instant Flash, ASRock Internet Flash AS, ASRock EZ Mode, ASRock Full HD UEFI, ARock Easy RAID Installer, ASRock My Favorites in UEFI
Processor socket:	LGA 2066 (Socket R4)
Processorfabrikant:	Intel
Maximum intern geheugen:	256 GB
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:	2
Compatibele besturingssystemen:	Microsoft® Windows® 10 64-bit
Audio-uitgangskanalen:	7.1 kanalen
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C:	2
Snelle installatiehandleiding:	Ja
Ethernet interface type:	10 Gigabit Ethernet
Chipset moederbord:	Intel® X299
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC1220
Meegeleverde drivers:	Ja
S/PDIF-uitgang:	Ja
Type koeling:	Actief
Geheugen kanaal:	Achtkanaals
PCI Express x16 (Gen 3.x) slots:	4
PCI Express x1 (Gen 3.x) slots:	1
Ondersteunde opslagstationinterfaces:	M.2, SATA III
Component voor:	PC
LAN controller:	Intel® I219-V
Aantal SATA III connectors:	10
Non-ECC:	Ja
Compatibele processors:	Intel Core i5, Intel Core i7, Intel Core i7 Extreme Edition, Intel Core i9, Intel Xeon W
Intel® Xeon series:	W3500, W5500
Ondersteunde geheugen types:	DDR4-SDRAM
Max. aantal SMP-processoren:	1
Wifi:	Ja
Code geharmoniseerd systeem (HS):	84733020
Moederbord chipset familie:	Intel
Moederbord form factor:	ATX
Aantal geheugenslots:	8
Supported memory clock speeds:	2133,2400,2666,2800,2933,3200,3600,3733,3800,4000,4200,4266,4300,4333,4400,4466,4500,4533,4600,4666,4700,4733,4800 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	128000 Mbit
ACPI version:	6.1
Systeem Management BIOS (SMBIOS) versie:	3.0
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	1
ATX Power connector (24-pin):	Ja
Aansluiting voor ventilator van voeding:	Ja
USB 2.0 aansluitingen:	2
PC gezondheids monitor:	CPU, FAN, LED, Power supply, Temperature, Voltage
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
Peripheral (Molex) power connectors (4-pin):	6
Supported processor sockets:	LGA 2066
RGB LED-aansluitrail:	Ja
Audioconnector:	Ja
M.2-kaartsleuf (opslag):	3
USB 3.2-connectoren (3.1 Gen 2):	2
Inclusief hulpprogramma's:	Ja
Geïntegreerde LAN:	Ja
