Asrock Fatal1ty B250M Performance Handleiding

Asrock Moederbord Fatal1ty B250M Performance

Lees hieronder de 📖 handleiding in het Nederlandse voor Asrock Fatal1ty B250M Performance (82 pagina's) in de categorie Moederbord. Deze handleiding was nuttig voor 19 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/82

Version 1.0

Published October 2016

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Product specificaties

Merk:	Asrock
Categorie:	Moederbord
Model:	Fatal1ty B250M Performance
Breedte:	244 mm
Diepte:	244 mm
Ethernet LAN:	Ja
Type stroombron:	ATX
Meegeleverde kabels:	SATA
Aantal USB 2.0-poorten:	1
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
Hoofdtelefoonuitgangen:	1
Certificering:	FCC, CE, WHQL, ErP/EuP ready
DVI-D poorten:	1
Ondersteunt Windows:	Ja
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	3
Processor socket:	LGA 1151 (Socket H4)
Processorfabrikant:	Intel
Maximum intern geheugen:	64 GB
Audio-uitgangskanalen:	7.1 kanalen
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C:	1
ECC:	Ja
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	Intel® B250
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC892
Geheugen kanaal:	Dubbelkanaals
PCI Express x16 (Gen 3.x) slots:	2
PCI Express x1 (Gen 3.x) slots:	2
Intel® Optane™ Memory Ready:	Ja
Ondersteunde opslagstationinterfaces:	SATA III
PS/2 poort(en):	2
LAN controller:	Intel® I219-V
Maximum geheugen grafische adapter:	1024 MB
DirectX versie:	12.0
Aantal SATA III connectors:	6
Non-ECC:	Ja
Wake-on-LAN:	Ja
Compatibele processors:	Intel Celeron, Intel Pentium
Ondersteunde geheugen types:	DDR4-SDRAM
Code geharmoniseerd systeem (HS):	84733020
Moederbord chipset familie:	Intel
Moederbord form factor:	micro ATX
Aantal geheugenslots:	4
Supported memory clock speeds:	2133,2400 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	16 Mbit
ACPI version:	6.0
COM aansluitingen:	2
Aansluiting voor CPU koeler:	Ja
Aansluitingen voor behuizingsventilatoren:	2
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
Chassis intrusion aansluiting:	Ja
Intel® Core i3/i5/i7/i9 series:	i3-6xxx, i3-7xxx, i5-6xxx, i5-7xxx, i7-6xxx, i7-7xxx
Clear CMOS jumper:	Ja
Intel® Extreme Memory Profile (XMP):	Ja
Aantal M.2 (M) slots:	2
12V vermogen-connector:	Ja
