Asrock B150M-HDV Handleiding

Asrock Moederbord B150M-HDV

Lees hieronder de 📖 handleiding in het Nederlandse voor Asrock B150M-HDV (69 pagina's) in de categorie Moederbord. Deze handleiding was nuttig voor 89 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/69

Version 1.0

Published June 2015

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

English

B150M-HDV

Motherboard Layout

Intel

B150

DDR4_B1 (64 bit, 288-pin module)

DDR4_A1 (64 bit, 288-pin module)

USB 3.0

T: USB0

B: USB1

ATXPWR1

PCIE1

Top:

RJ- 45

USB 2.0

T: USB0

B: USB1

HDL ED RES ET

PLE D PWRBT N

PANEL1

USB 2_ 3

SPK _C I1

COM 1

HD_ AU DI O1

B150M-HDV

RoHS

HDMI1

DVI1

USB 3.0

T: USB2

B: USB3

PS2

Keyb oard

/Mouse

CMOS

Bat tery

CLR MO S 1

USB 3_ 4_5

CPU _FA N1

USB _4 _5

TPM S 1

PCI Expres s 3.0

Front USB 3.0

Top :

LINE IN

Cente r:

FRONT

Bot tom:

MIC IN

SATA3 _2 _3

CHA _ FAN 1

PCIE2

PCIE3

AT X1 2V1

SATA3 _4 _5

SATA3 _0SATA3 _1

VGA1

Product specificaties

Merk:	Asrock
Categorie:	Moederbord
Model:	B150M-HDV
Breedte:	231 mm
Diepte:	188 mm
Ethernet LAN:	Ja
Type stroombron:	ATX
Aantal USB 2.0-poorten:	2
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	1
Aantal Ethernet LAN (RJ-45)-poorten:	1
DVI-D poorten:	1
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	4
Processor socket:	LGA 1151 (Socket H4)
Processorfabrikant:	Intel
Maximum intern geheugen:	32 GB
Intel® Turbo Boost Technology:	2.0
Audio-uitgangskanalen:	7.1 kanalen
Ethernet interface type:	Gigabit Ethernet
Chipset moederbord:	Intel® B150
Geheugen slots type:	DIMM
Audiochip:	Realtek ALC887
PCI Express x16 (Gen 3.x) slots:	1
PCI Express x1 (Gen 3.x) slots:	2
Ondersteunde opslagstationinterfaces:	SATA III
PS/2 poort(en):	1
Component voor:	PC
LAN controller:	Realtek 8111E X2
Aantal SATA III connectors:	6
Non-ECC:	Ja
Compatibele processors:	Intel Celeron, Intel Pentium
Ondersteunde geheugen types:	DDR4-SDRAM
Moederbord chipset familie:	Intel
Moederbord form factor:	micro ATX
Aantal geheugenslots:	2
Supported memory clock speeds:	2133 MHz
BIOS type:	UEFI AMI
Grootte BIOS-geheugen:	16 Mbit
ACPI version:	5.0
ATX Power connector (24-pin):	Ja
USB 2.0 aansluitingen:	2
Aansluiting voor audiopaneel aan voorzijde:	Ja
Aantal COM-poorten:	1
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:	1
TPM connector:	Ja
Chassis intrusion aansluiting:	Ja
Peripheral (Molex) power connectors (4-pin):	3
Aansluitingen voor EATX voedingen:	1
Intel® Extreme Memory Profile (XMP):	Ja
