ADDERLinkâ„¢ XD612 and XD614
User Guide
INSTALLATION
1
CONFIGURATIONOPERATION
FURTHER
INFORMATION
INDEX
Introduction
Welcome 2 ................................................................................................................
CATx Link Cable Recommendations 3 ........................................................
Multi-display support using MST 4 .......................................................................
AdderLink XD612 features 6 ................................................................................
AdderLink XD614 features 7 ................................................................................
Technical specications .......................................................................................8
Supplied items 9 .......................................................................................................
Optional extras 10 ...................................................................................................
Installation
Locations 11 ..............................................................................................................
Connections 11 ........................................................................................................
Transmitter video link(s).............................................................................12
Transmitter audio links 12 ...............................................................................
Transmitter USB links 13 ..................................................................................
Transmitter Remote port 13 ...........................................................................
Transmitter power connection 14 .................................................................
Linking 15 .............................................................................................................
CATx link 15 .......................................................................................................
Fiber optic link 16 ..............................................................................................
Receiver video display(s) 17 ............................................................................
EDID management 17 .................................................................................
Receiver audio devices 17 ................................................................................
Receiver USB devices 18 ..................................................................................
Receiver Remote port 18 ................................................................................
Receiver power connection 19 .......................................................................
Conguration
Accessing the Dashboard 20 .................................................................................
Choosing RX video mode (XD614 models only).......................................20
Resetting a module 21 ............................................................................................
Upgrading Firmware 21 ..........................................................................................
Operation
Indicators 22 .............................................................................................................
Further information
Getting assistance 23 ..............................................................................................
Appendix 1 - Remote port pin-out 24 ................................................................
Index
Contents
INSTALLATION
2
CONFIGURATIONOPERATION
FURTHER
INFORMATION
INDEX
ADDERLink XD
Transmitter
module
ADDERLink XD
Receiver
module
Fiber optic link
(up to 4km)
OR
CATx link
(CAT5e up to 50m)
(CAT6 up to 100m)
ADDERLink
â„¢
XD
PWR STS VID LNK
R X
RE C E I V E
ADDERLink
â„¢
XD
PWR
LINK
LINK
STS VID LNK
T X
TRANSMIT
Introduction
WELCOME
Thank you for choosing the ADDERLink® XD612 (dual head) or XD614 (quad head)
extender modules. Using either ber optic or CATx links, these compact modules
allow you to extend KVM connections over long distances from a host computer (see
Transmission distances when using ber on the right).
The high-grade screening employed within the metal cased enclosures, particularly when
combined with the immunity from interference of the ber optic links.
AdderLink XD61x extender modules provide support for:
• High quality single-, dual-, triple- or quad- digital video
• Video resolutions up to 4K 4096 x 2160 @60Hz (XD614 models),
• USB keyboard and mouse plus two other USB devices (up to USB 2.0),
• An RS232 serial device at speeds up to 115200 baud,
• Mono microphone,
• Stereo speakers, digital stereo audio out
• Line-level audio in/out connections.
Transmission distances when using ber
The choice of ber used with the ADDERLink XD61x modules has a considerable effect
on the distance over which operation can take place. Using multi-mode ber you can
achieve distances up to 400m (1,312 feet); whereas, by using single-mode ber (and
accompanying SFP+ modules), the achievable maximum distance is increased to 4km (2.5
miles):
Distance Fibertype Fibercolorcode SFP+module
70m OM1 (TIA-492AAAA) Orange SFP-MM-LC-10G
150m OM2 (TIA-492AAAB) Orange SFP-MM-LC-10G
380m OM3 (TIA-492AAAC) Aqua SFP-MM-LC-10G
400m OM4 (TIA-492AAAC) Aqua SFP-MM-LC-10G
4km OS1 (TIA-492C000) Yellow SFP-SM-LC-10G
OS2 (TIA-492E000) Yellow SFP-SM-LC-10G
The ADDERLink extender modules are
totally transparent in operation, leaving you
free to use your computer as though you’re
still sitting next to it.
SFP+
module
Fiber
color
Up to 4 DisplayPort® video displays (see page 4)
Four USB devices
One RS232 serial device
Stereo speakers plus microphone
