Instruction Manual
Model: ThermoCal
Professional Testing Device
for Thermometer
www.rossmax.com
OBM_IB_ThermoCal_
220240V_EN_ver2111
Manufacturer: Rossmax Swiss GmbH,
Widnauerstrasse 1, CH-9435 Heerbrugg, Switzerland
2. Heating indicator of the water bath does not light up after the calibration temperature is set
Possible causes Actions to take
Water temperature is higher than the set
temperature Cool down the water in the bath
Defective heating indicator Contact Rossmax for service
Defective temperature controller Contact Rossmax for service
Set temperature is too low Set temperature should be at least 5°C higher
than operating temperature
3. Heating indicator of water bath lights up, whereas the water temperature remains low
Possible causes Actions to take
Defective heater circuit Contact Rossmax for service
Defective temperature controller Contact Rossmax for service
4. Water temperature continues to rise and exceed the set temperature
Possible causes Actions to take
Defective temperature controller Contact Rossmax for service
5. Large uctuation in water temperature
Possible causes Actions to take
Water temperature is not stable yet Wait for temperature to stabilize
Set temperature is too close to ambient
temperature Lower the ambient temperature
Defective temperature controller Contact Rossmax for service
Defective water heater Contact Rossmax for service
6. Power and power indicator are both on, whereas the water circulating pump does not start
Possible causes Actions to take
Foreign object clogs inside the pump Remove the foreign object
Loose screw used to secure the propeller Tighten the screw
Defective motor Contact Rossmax for service
7. Noise generated by the stirrer motor
Possible causes Actions to take
Bearing ball oxidation Replace bearing
Bearing aging Replace bearing
Trouble shooting
1. Power is switched on but the power indicator does not light up
Possible causes Actions to take
No power input Check the power source
Loose plug Insert the plug into the socket securely
Device is powered and running but the power
indicator does not light up Replace the power switch
Power wire broke or loose connection Replace the power wire(s)
Tripped fuse Check the fuse and replace it if needed
WARNING: The symbol on this product means that it’s an
electronic product and following the European directive
2012/19/EU the electronic products have to be disposed
on your local recycling centre for safe treatment.
Accuracy is always the biggest concern of a thermometer user. Rossmax ThermoCal is a portable
and convenient device that allows the user to easily check the accuracy of a thermometer in just a
few seconds. The innovative design of the adjustable blackbody cavity applies to all three types of
Rossmax thermometer products - pen type, ear and temple thermometer.
Parts name/location
Control panel Back view
Introduction
Instructions for installation
Cautions and maintenance
Speciîž‚cations
Operation procedures
1. Check the accuracy
Step 1: Check water level of the bath.
Step 2: Turn on the device.
Step 3: Select a testing temperature on the control panel (default at 37°C).
Step 4: Wait for the water to reach the desired temperature.
Step 5: Choose the blackbody cavity corresponding to the thermometer types.
Step 6: Set the thermometer into the calibration mode.
Step 7: Insert the probe/tip into the cavity.
Step 8: Start the measurement.
Step 9: Thermometer will beep when the measurement is completed.
Step 10: Compare the reading given by the thermometer to the calibration temperature.
The acceptable allowance is within ±0.2°C.
2. Drain the water bath
Step 1: Make sure the device is off.
Step 2: Remove the tube from the upper end.
Step 3: Empty the water bath by lowering the upper end of the tube.
Step 4: Plug the tube back in after the draining is completed.
1. Install the device on a solid surface.
2. Make sure the power is off before plugging in the device.
3. Keep the device away from the environment with direct sunlight, high temperature, high
humidity or severe change in temperature.
4. Make sure the AC power and its grounding plug are properly connected.
5. Do not use power extension cords.
6. Use pure water or distilled water only for the water bath to avoid contamination or water
heater breakdown.
7. Pay attention to the water level to avoid overspill.
8. The water bath is to remain 90% full at all times to reach water temperature stability.
1. Make sure the device, AC power and its grounding plug, is plugged in properly.
2. Change water periodically, once a month is suggested.
3. Use pure water or distilled water only for the water bath. Other water sources might increase
the chance of calcium carbonate formation on the outside of the water heater.
4. Make sure there is enough water in the water bath every time before using the device. Please
constantly pay attention to the water level and hygiene when/if the device runs for over 6 hours
or the water temperature exceeds 40°C.
5. Keep the device away from physical impact.
6. Unplug the device and empty the water bath if the device is going to be inactive for a long
time.
7. Unplug the device before moving it or draining the water bath.
8. Clean the water bath with a 3M scrub sponge if any signs of iron oxidization appear.
9. Pay attention to the water temperature to avoid scald.
Power source AC 220-240V 50/60 Hz
Power of water heater 255W
Testing temperature Ambient temperature + 5°C to maximum 45°C
Ambient temperature 16 ~ 30°C
Stability of water bath temperature ± 0.02°C
Diameter of
blackbody cavity
Pen type 15 mm
Ear 12.5 mm
Temple 55 mm
Capacity 5.39 Liters
Weight 9.69 kgs
Dimension 180(W) x 350(H) x 320(D) mm
Control
panel
Ventilation
holes
Water
bath actual
temperature
Water bath set
temperature
Heating
indicator
Temperature up
Temperature down
Digit selecting key
Temperature setting key
Socket
and fuse
Power
switch
Cooling
fan
Overheating
protection
setting knob
Drain
tube
Removable
bath cover Blackbody
cavity
Computer
