Pagina 1/5
E Q 9 . 0
U s e r M a nu a l
EQ9.0
USER MANUAL
EQ9.0, 9 band graphic equalizer. Precision tuning
perfectionists. EQ9.0 gives you 9 bands/frequencie
tweak your car audio system, delivering your music
EQ9.0
//////////
SPECIFICATIONS
- Low output impedance
- High input impedance
- Flat frequency response
- High output voltages
- Excellent signal to noise ratio
- Panel mount RCAs
- Poly caps and low tolerance resistors in
signal path circuits
- Removable terminal block for all input c
FEATURES:
featuring:
0.01%
13V
9V
20KΩ
50Ω
>94dB
Maximum Input Voltage
Input Impedance
Maximum Output Voltage
THD
Output Impedance
Signal to Noise
±10dB
Band Adjustment
12dB
Crossover Slope (Per Octave)
1. for input power, chassis ground, and remote turn-on, use a Power Connections
minimu f 18 gauge copper wire for power and ground connections; power wire
used with 1 Amp fuse
RCA output jacks provide a fadeable-full range signal nt & Rear Outputs
t and rear ampliers
allow for a normal stereo signal input from various sourcesInputs
provides a low pass signal to your bass amplier Sub Output
is used to match the input level with the output leve Input Gain Adjustment
urce unit connected to the AUX input. When properly adjusted both sources
nd Main) should play at the same volume level. The adjustments are individ
with one for the left and one for the right channel
6 controls the cuto frequency of the LPF on.Low Pass Frequency (LPF) Adjustment
the “Sub Out” channels, the crossover lter is switchable from 45Hz to 60Hz.
7 raises and lowers the level of just the “Sub Out”.Subwoofer Level Adjustment
channels to ne tune level based on musical content
8 raises and lowers the volume on all of the outputs simultaneously.Volume Control
9. allows you to adjust the level between the Front and Rear Fader Adjustment
channels
10 selects the Main/Aux .Input Selector Switch
11. 9 individual controls at set at xed frequencies of Equalizer Level Adjustment
50Hz, 125Hz, 250Hz, 500Hz, 1KHz, 2KHz, 4KHz, 8KHz and 16KHz with ±10dB of
adjustment one each
EQ9.0 USER MANUAL
