Pagina 1/74

User Manual

EVO Nano Series

V1.0 2021.12

Terms for Usage

Thank you for your interest in the industry aircraft products provided by Autel Robotics Co.,

Ltd (hereinafter referred to as “Autel Robotics”). Please read the following terms carefully

and acknowledge that you have understood and agreed the following terms, conditions and

safe operation guide.

Trademark Information

The trademarks EVO Nano™, EVO Nano+™, Autel Sky™, Autel SkyLink

TM and Autel

Robotics® are the registered trademarks of Autel Robotics in China and other

countries/regions. All other products and company name mentioned in this Manual are the

registered trademark of their respective owners.

Without the explicit consent of Autel Robotics, do not copy or forward any part of the Manual

in or by any form (electronic, mechanical, reproducing, recording or other forms).

Disclaimer

In order to ensure safety and successfully operate your EVO Nano aircrafts, please abide by

the operating instructions and procedures of this Manual. Users under 16 years must use the

aircraft under the supervision of a professional adult. The aircraft shall be kept out of the

reach of children when it is not used.

If user fails to abide by the safe operating instructions, Autel Robotics will assume no

responsibility for any product damage or loss--direct or indirect, legal, special or economic

loss (including but not limited to profit loss) during use, and will not provide warranty service.

Never modify your product by using any incompatible component or any method that is not

required in Autel Robotics official description. This Manual will show you the safe operating

procedures of aircrafts. Please acknowledge that your operation will not endanger your and

other personal and property safety. This Manual will update without a fixed schedule. In order

to ensure your use of the latest version, please visit: www.autelrobotics.com

Data Storage and Use

The backup service function of this product is disabled by default, so user and flight

information will not be uploaded or propagated through mobile device. When Autel Sky APP

is connected with an aircraft, the flight log including the flight remote sensing data will be

uploaded and saved in the Autel Robotics data server. All remote sensing data and flight logs

are stored in the data server in the United States, but the data can be uploaded automatically

only when the flight log backup option is enabled. Without the explicit authorization of user

through APP, Autel Robotics customer service team has no right to access to the flight log

data. With the authorization, it is only allowed to access to the flight logs within the selected

time.

Various still images, motion images and data from the aircraft sensor will be stored in the

internal drive of aircraft. If your UAV needs repair, then the information stored in the internal

memory unit can be used for problem diagnosis. This information will not be retained, unless

for processing service or repair. Never delete or change any data stored in the internal

memory unit in any form, otherwise Autel Robotics will not provide warranty.

The data collected by Autel Robotics are for providing support and service and improving

product performance. We will seriously treat your privacy like ourselves. We can agree to

disclose any uploaded data only when the law requires.

Product specificaties

Merk:	Autel
Categorie:	Drone
Model:	EVO Nano+
Kleur van het product:	Wit
Gewicht:	249 g
Soort:	Quadcopter
Aantal snelheden:	3
Capaciteit van de accu/batterij:	2250 mAh
AC-adapterfrequentie:	50/60 Hz
AC-adapter ingangsspanning:	100 - 240 V
Maximale capaciteit van de geheugenkaart:	256 GB
Ondersteunde videoformaten:	H.264, H.265, MOV, MP4
Field of view (FOV) hoek:	84 °
Meegeleverde kabels:	USB Type-C
Compatibele geheugenkaarten:	SD
Maximale beeldsnelheid:	30 fps
Accu/Batterij voltage:	7.7 V
Maximale gewichtscapaciteit:	- kg
Omvang optische sensor:	1/1.28 "
AC-adapter, vermogen:	30 W
Megapixels:	50 MP
Maximale beeldresolutie:	8000 x 6000 Pixels
Type beeldsensor:	CMOS
Camera sluitertijd:	1/8000 - 8 s
Maximale videoresolutie:	3840 x 2160 Pixels
Videoresoluties:	1920 x 1080,3840 x 2160 Pixels
Ondersteund beeldformaat:	DNG, JPG
Geheugenkaart slot(s):	Ja
Accu gestuurd:	Ja
Geschikt voor buitengebruik:	Ja
AC-adapter, uitgangsspanning:	5/9/12 V
AC-adapter, uitgangsstroom:	3 A
Maximale afstand:	10000 m
Afstandsbediening inbegrepen:	Ja
Wifi:	Ja
Bedrijfstemperatuur (T-T):	0 - 40 °C
Batterijtechnologie:	Lithium-Polymeer (LiPo)
Aantal propellers:	4 propellers
Maximale snelheid:	- m/s
Maximum vlieghoogte:	4000 m
Maximale tilt-hoek:	33 °
Maximale stijgsnelheid:	5 m/s
Maximale daalsnelheid:	4 m/s
Maximale windweerstand:	15 m/s
Maximale vliegtijd:	28 min
Bitrate by maximale video resolutie:	100 Mbit/s
Batterijcapaciteit:	17.32 Wh
Zweeftijd:	26 min
Equivalent Isotropically Radiated Power (EIRP):	30 dBmW
Reservepropeller(s) inbegrepen:	Ja
Inclusief schroevendraaier:	Ja
